VIGO INDUSTRIES INSTALLATION GUIDE FOR
SHOWER ENCLOSURE (MODEL VG06031)
!
SAFETY PRECAUTIONS
This Installation Guide uses the following symbols to indicate important information.
Always observe the instructions indicated by these symbols.
!
WARNING
Instructions that, if ignored, could result in death or serious personal injury caused by
incorrect handling or installation of the product. These instructions must be observed for
safe installation.
!
CAUTION
The instructions for the following unit is based off of the Vigo brand shower base. The
instructions can not be provided for any other installation other than that of the Vigo brand.
The warranty will be voided if the following was not performed properly.
IMPORTANT
Maintenance and other important non-personal injury and non-material damage instructions
or statements that should be observed.
It is highly advised to dry fit the unit prior to any installation.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VG06031 and is the answer not in the manual?

Questions and answers

Related Manuals for VIGO VG06031

Summary of Contents for VIGO VG06031

  • Page 1 CAUTION The instructions for the following unit is based off of the Vigo brand shower base. The instructions can not be provided for any other installation other than that of the Vigo brand. The warranty will be voided if the following was not performed properly.
  • Page 2 Phillips screw 2" (2pc) Phillips screw 1 1/8" (3pc) Plastic anchor green (3pc) Plastic anchor white (2pc) Door threshold clip (2pc) Phillips screw 3/4" (2pc) GLASS THICKNESS 5/16" NOTE: INSTALLATION MUST BE DONE BY A QUALIFIED, LICENSED PROFESSIONAL MODEL VG06031...
  • Page 3 COMPLETELY INSTALLED DEPICTION ABOVE IS ONLY TO BE USED AS A GUIDE. IN NO WAY SHOULD YOU ATTEMPT TO BUILD A BASE OR CUB OFF THIS DIAGRAM. PLEASE CONTACT VIGO INDUSTRIES TECHNICAL SUPPORT FOR ANY FURTHER INFORMATION OR ASSISTANCE. MODEL VG06031...

  • Page 4: Before Starting

    GLASS BREAKAGE AND, CONSEQUENTLY, CAUSE PERSONAL INJURY OR DEATH. BEFORE STARTING Compare items on your invoice with what you have received. Carefully review the Packing List on page 2. If any items are missing contact Vigo Industries at 1-866-591-7792. REQUIRED TOOLS Square and/or Phillips #1 and #2 screwdriver Flat head screwdriver Electric drill plus 1/32", 3/32", 1/8"...

  • Page 5: Pre-Installation

    (#8) to the floor with 1 1/8" screws (#15). 10. Place the fixed panel (#4) back into the proper position by screwing it to the structural rail (#11) with the fixed panel holders (#2). [SEE FIG. 5] MODEL VG06031...
  • Page 6 INSIDE OF THE SHOWER OUTSIDE OF THE SHOWER TOP VIEW FIG. 4 THIS SIDE SHOULD BE FACING INSIDE THE SHOWER. THIS IS THE SIDE THE THE DOOR WILL BE PLACED HERE. FIXED PANEL WILL BE PLACED IN. FIG. 5 MODEL VG06031...

  • Page 7: Installing The Door

    (#11). Adjust the stoppers' position on the structural rail and tighten the hex screws. OUTSIDE OF THE SHOWER INSIDE OF THE SHOWER TOP VIEW FIG. 6 OUTSIDE OF THE SHOWER ROLLER HEIGHT ADJUSTMENT SCREW FIG. 6A MODEL VG06031...
  • Page 8 FIG. 7 FIG. 7A MODEL VG06031...
  • Page 9 Slide the door threshold clip (#18) to the fixed panel (#4). Align the threshold with the door and press down firmly. 4. Screw the door threshold clip (#18) into the base or floor with 3/4" phillips screw (#19). Silicone the cap to part (#18). [SEE FIG. 8] FIG. 8 MODEL VG06031...

  • Page 10: Installing The Handle

    2. Trim the flange on the seal strips (#13) so that there is enough clearance for the door to roll without the seal strips hitting against the rollers or door stopper. ADJUST POSITION TO STOP HANDLE FROM HITTING FIXED PANEL TRIM HERE THIS END MUST LOOK INSIDE THE SHOWER FIG.10 MODEL VG06031...
  • Page 11 APPLYING THE SILICONE 1. Apply clear silicone caulking along the wall and floor of the shower enclosure interior. [SEE FIG.11] FIG.11 NOTE: DO NOT ALLOW DIRECT WATER ONTO DOOR SEAL STRIP. WAIT 24 HOURS BEFORE USING THE SHOWER. MODEL VG06031...
  • Page 12 MODEL VG06031...
  • Page 13 ROLLER (3) 3/8" VARIANCE HEX SCREW FIG. 1 Lowest position Normal position Highest position FIG. 1A IMPORTANT NOTE: These adjustments are approximate. You may need to adjust the direction of the small hex hole to meet your needs. MODEL VG06031...

  • Page 14: Straight Walls

    ROLLER (3) WALL WALL STRAIGHT WALLS ROLLER "A" ROLLER "B" WALL DIRECTION SMALL HEX HOLE SMALL HEX HOLE DIRECTION DIRECTION STRAIGHT WALL FIG. 2 MODEL VG06031...
  • Page 15 TILTS IN AT TOP (EXAGGERATED FOR PURPOSE OF DEPICTION) WALL OUT OF PLUMB WALL TOP ANGLED WALL ROLLER "A" ROLLER "B" WALL DIRECTION SMALL HEX HOLE SMALL HEX HOLE DIRECTION DIRECTION TOP ANGLED ADJUST AS NEEDED FIG. 3 MODEL VG06031...
  • Page 16 WALL OUT OF PLUMB WALL TILTS IN AT BOTTOM (EXAGGERATED FOR PURPOSE OF DEPICTION) BOTTOM ANGLED WALL ROLLER "A" ROLLER "B" WALL DIRECTION SMALL HEX HOLE SMALL HEX HOLE DIRECTION DIRECTION BOTTOM ANGLED ADJUST AS NEEDED FIG. 4 MODEL VG06031...
  • Page 17 - Make sure to regularly inspect your Vigo Brand shower enclosure and tighten any hardware that may have loosened during the use process. Vigo understands that your home is a moving entity and designs the Vigo Brand shower enclosure to adjust to your home needs.
  • Page 18 Subject to the Warranty Service provision below, any product reported to the authorized dealer or to VIGO as being defective within the warranty period will be repaired or replaced (with a product of equal value) at the option of VIGO. This warranty extends to the original owner or end-user and is not transferable to a subsequent owner.
