VIGO INDUSTRIES INSTALLATION GUIDE FOR
SHOWER ENCLOSURE (MODEL VG06073)
!
SAFETY PRECAUTIONS
This Installation Guide uses the following symbols to indicate important information.
Always observe the instructions indicated by these symbols.
!
WARNING
Instructions that, if ignored, could result in death or serious personal injury caused by
incorrect handling or installation of the product. These instructions must be observed for
safe installation.
IMPORTANT
Maintenance and other important non-personal injury and non-material damage instructions
or statements that should be observed.
It is highly advised to dry fit the unit prior to any installation.
1
Advertisement
Table of Contents
Related Manuals for VIGO VG06073
Summary of Contents for VIGO VG06073
- Page 1 VIGO INDUSTRIES INSTALLATION GUIDE FOR SHOWER ENCLOSURE (MODEL VG06073) SAFETY PRECAUTIONS This Installation Guide uses the following symbols to indicate important information. Always observe the instructions indicated by these symbols. WARNING Instructions that, if ignored, could result in death or serious personal injury caused by incorrect handling or installation of the product.
- Page 2 8. White plastic anchor (4pc) 9. Phillips screw 1 1/4" (4pc) 10. Door magnetic seal strip (2pc) 11. Green plastic anchor (4pc) 12. Screw covers (8pc) GLASS THICKNESS:8mm NOTE: INSTALLATION MUST BE DONE BY A QUALIFIED, LICENSED CONTRACTOR. MODEL VG06073...
- Page 3 70 5/8" 22 1/4" X 70" 26X70 26" - 26 1/2" 70 5/8" 24 1/4" X 70" 28X70 28" - 28 1/2" 70 5/8" 26 1/4" X 70" 30X70 30" - 30 1/2" 70 5/8" 28 1/4" X 70" MODEL VG06073...
-
Page 4: Before Starting
GLASS BREAKAGE AND, CONSEQUENTLY, CAUSE PERSONAL INJURY OR DEATH. BEFORE STARTING Compare items on your invoice with what you have received. Carefully review the Packing List on page 2. If any items are missing contact Vigo Industries at 1-866-591-7792. REQUIRED TOOLS Square and/or Phillips #1 and #2 screwdriver Flat head screwdriver Electric drill plus 1/8", 5/16", 1/4"... - Page 5 If there is insufficient support, then reinforce the shower walls with wooden studs prior to shower door installation. [SEE FIG.1B] STUD FIG.1B CAUTION GASKETS NEED TO BE IN BETWEEN ALL GLASS AND METAL CONTACT. FAILURE TO DO SO CAN LEAD TO BREAKAGE AND POTENTIAL BODILY HARM. MODEL VG06073...
- Page 6 NOTE: If the seal strips are not flat, use a hair dryer to apply minimal heat and press the seal strip back into position. MAKE SURE THE FLANGE IS ON THE INSIDE OF THE SHOWER HINGE OUTLINE FIG.1 MODEL VG06073...
-
Page 7: Hinge Installation
There is a 1/2" adjustment in the glass holes where the hinges are installed. You may need to adjust your hinges more than once to close your unit opening properly. THIN GASKETS PLATE HEX SCREWS SCREW COVERS THIN GASKETS PLATE HEX SCREWS SCREW COVERS VIEW FROM INSIDE OF THE CABIN FIG.2 MODEL VG06073... -
Page 8: Installing The Door
Replace the door (#1) back on the shim and place it in the open position.Screw the door securely to the wall with 1 5/8" screws (#7). [SEE FIG.3A] LEVEL FIG.3 5/8" SHIM (NOT PROVIDED) MODEL VG06073... - Page 9 OPEN POSITION 5/8" SHIM (NOT PROVIDED) FIG.3A MODEL VG06073...
- Page 10 NOTE: If the seal strips are not flat, use a hair dryer to apply minimal heat and press the seal strip back into position. FLOOR FLOOR FIG.4 MAGNETIC SEAL STRIP SHOULD SIT 1/16" OFF OF THE FLOOR AT THE FINAL INSTALLATION "B" side "A" side FIG.5 MODEL VG06073...
- Page 11 Drill the vertical track (#6) to the wall with the 1 1/4" phillips screws (#9), making sure it is level and true. [SEE FIG.8] Install the magnetic seal strip (#10) back onto the vertical track (#6), making sure that it complements the door magnetic seal strip. [SEE FIG.7] LEVEL FIG.6 HOW MAGNETIC SEAL STRIPS SHOULD MEET FIG.7 MODEL VG06073...
-
Page 12: Handle Installation
LEVEL VERTICAL TRACK SHOULD REST ON THE FLOOR FIG.8 HANDLE INSTALLATION Assemble the door handles (#5) to the door (#1). [SEE FIG.9] FIG.9 MODEL VG06073... - Page 13 NOTE: If the seal strips are not flat, use a hair dryer to apply minimal heat and press the seal strip back into position. FIG.10 IMPORTANT WAIT 24 HOURS BEFORE USING SHOWER DO NOT ALLOW WATER TO DIRECTLY HIT DOOR SEAL STRIPS MODEL VG06073...
- Page 14 Do NOT use abrasive cleaners, scrapers, metal brushes, or any items/products that would scratch and/or dull surface. Do NOT allow surface to come into contact with acetone (nail polish remover), dry cleaning solution, lacquer thinner, gasoline, or any other similar product. MODEL VG06073...
- Page 15 Subject to the Warranty Service provision below, any product reported to the authorized dealer or to VIGO as being defective within the warranty period will be repaired or replaced (with a product of equal value) at the option of VIGO. This warranty extends to the original owner or end-user and is not transferable to a subsequent owner.
