  • Page 1 HD/SD 8/12-CHANNEL OB VAN STUDIO OBV-2850 Instruction Manual...

  • Page 2: Table Of Contents

    Datavideo Technologies will try to give correct, complete and suitable information. However, Datavideo Technologies cannot exclude that some information in this manual, from time to time, may not be correct or may be incomplete. This manual may contain typing errors, omissions or incorrect information.

  • Page 3: Fcc Compliance Statement

    AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company. 8. Do not allow anything to rest on the power cord. Do not locate this unit where the power cord will be walked on, rolled over, or otherwise stressed.

  • Page 4: Warranty

     The product warranty period beings on the purchase date. If the purchase date is unknown, the product warranty period begins on the thirtieth day after shipment from a Datavideo office.  All non-Datavideo manufactured products (product without Datavideo logo) have only one year warranty from the date of purchase.

  • Page 5: Disposal

     The three-year warranty must be registered on Datavideo's official website or with your local Datavideo office or one of its authorized distributors within 30 days of purchase. Disposal For EU Customers only - WEEE Marking This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.

  • Page 6: Introduction

    1. Introduction Datavideo OBV-2850 is designed to fit into the back of a small van to provide complete mobile production facilities. It’s a transportable solution for broadcasters and professionals for both in- studio and on-location productions. Built around the latest HD/SD switcher, it supports up to 12 channels of HD/SD-SDI, HDMI or composite video signals.

  • Page 7: System Diagram

    2. System Diagram OBV-2850A...
  • Page 8 OBV-2850B...
  • Page 9 OBV-2850C...

  • Page 10: Front View

    3. Front View For the operation descriptions, please refer to individual manual of each model. OBV-2850A SE-2850 Ctrl Device Model and Name Product Description The TLM-170VR is a 1920 x 1080 Full HD monitor which integrates TLM-170VR 17" functions including built-in vectorscope and SDI/HDMI signal ScopeView Production converter.
  • Page 11 This Rack Panel provides three HDMI ports and two RJ-45 Ethernet Rack Panel ports for users. SE-2850 is a multi-definition switcher designed for productions requiring 8 to 12 SE-2850 Main Unit channels of HD or SD inputs. SE-2850 Ctrl SE-2850 Ctrl is the control keyboard for the SE-2850. OBV-2850B...
  • Page 12 Device Model and Name Product Description The TLM-170VR is a 1920 x 1080 Full HD monitor which integrates TLM-170VR 17" functions including built-in vectorscope and SDI/HDMI signal ScopeView Production converter. Monitor-Rack Mount x 2 KMU-100 2-channel 4K KMU-100 is an advanced video converter allowing conversion of to 8-channel HD UHD input signals into 4 different streams with resolution up to Full Portable Video...
  • Page 13 OBV-2850C Device Model and Name Product Description The TLM-170VR is a 1920 x 1080 Full HD monitor which integrates TLM-170VR 17" functions including built-in vectorscope and SDI/HDMI signal ScopeView Production converter. Monitor-Rack Mount x 2 HDR-70 HD/SD Digital The HDR-70 is a hard drive based video recorder with removable Video Recorder-1U hard drive enclosure.
  • Page 14 SE-2850 Ctrl SE-2850 Ctrl is the control keyboard for the SE-2850. SE-2850 is a multi-definition switcher designed for productions SE-2850 Main Unit requiring 8 to 12 channels of HD or SD inputs.

  • Page 15: Rear View

    4. Rear View OBV-2850A Device Model and Name Product Description Those Rack Panels allows for connecting for HDMI/BNC/XLR Rack Panels ports. PD-5 AC Power This is an optional AC power distributor. Distributor(Optional) AD-200 Audio Delay Box with Audio input/output interfaces for the RCA audio and XLR Level Adjustment –...
  • Page 16 OBV-2850B Device Model and Name Product Description Those Rack Panels allows for connecting for HDMI/BNC/XLR Rack Panels ports. PD-5 AC Power This is an optional AC power distributor. Distributor(Optional) AD-200 Audio Delay Box with Audio input/output interfaces for the RCA audio and XLR Level Adjustment –...
  • Page 17 OBV-2850C Device Model and Name Product Description Those Rack Panels allows for connecting for HDMI/BNC/XLR Rack Panels input/output ports. PD-5 AC Power This is the optional AC power distributor. Distributor(Optional) AD-200 Audio Delay Box with Audio input/output interfaces for the RCA audio and XLR Level Adjustment –...

  • Page 18: Desktop

    5. Desktop Device Model and Name Product Description SE-2850 HD/SD 8/12- Channel Digital Video The control keyboard allows video switching and video effect Switcher – Control application. Keyboard...

  • Page 19: How To Download User Manual For Each Device

    6. How to Download User Manual for Each Device There are several devices which are integrated in the OBV-2850 including TLM-170VR, HDR-70, ITC-100, SE-2850, NVS-33, AD-200 and KMU-100. For the details about operating those devices, please refer to the manual of each device respectively. Please go to following web pages to download the latest user manuals of those devices.

  • Page 20: Assembly

    7. Assembly 7.1 Assembly of 4U Trapezoidal Steel Frame and Upper and Lower Steel Frames Part No. Descriptions Q’ty G09220588171 4U Trapezoidal Steel Frame (Right) SPCC 2.5t VP-588 Painted Weave Pattern Black G09220588181 4U Trapezoidal Steel Frame (Left) SPCC 2.5t VP-588 Painted Weave Pattern Black G0911D501001 Countersunk Head...
  • Page 21 7.2 Assembly of Diaphragm Panels (Front/Rear/Left/Right) Part No. Descriptions Q’ty G09220588101 Front Upper Diaphragm Panel SPCC 1.2t VP-588 Painted Weave Pattern Black G09220588131 Top Side Panel AL 1.2t VP-588 Painted Weave Pattern Black G09220588141 Top Side Panel AL 1.2t VP-588 Painted Weave Pattern Black G09220588152 Middle Side Panel...
  • Page 22 Weave Pattern Black G09220588162 Bottom Side Panel AL 1.0t VP-588 Painted Black 2- Platen Mold G09220588081 Iron Handle 1 SPCC 1.2t VP-588 Painted Weave Pattern Black G0911D500611 Nylok Screw Flat Head ISO M5*6 Black G0911D501011 Nylok Screw, Round Head with Spring Washer + Washer, M5*10mm Black...

  • Page 23: Dimensions

    8. Dimensions...
  • Page 24 All measurements in millimeters (mm)
  • Page 25 Note...
  • Page 26 Note...
  • Page 27 Note...

  • Page 28: Service And Support

    Dec.-17.2019 Version E1 Datavideo Technologies Co., Ltd. All rights reserved 2020...
