Figure 26 Deforming t he Push-nut
Figure 27 Removing Push-nut
Figure 28 Removing t he But t on Board
A
900-0054-01-00 Rev
Fan and But t on Board
2. Slowly close the wire cutters, exerting
enough pressure to crush or deform
the push-nut. The push-nut cannot be
reused after doing this.
3. Once the push-nut is deformed,
push the wire cutters beneath it
and pry it off the peg.
4. Finally, work the button board free of
the four pegs and remove it from the
housing.
Continued on next page.
