Removing t he Cont rol Board
Do NOT raise t hese
induct or wires
Figure 32 Lift ing t he Induct or Wires
Figure 33 Sliding t he Cont rol Board Out
A
900-0054-01-00 Rev

Control Board and Power Board

Cont rol Board
2. Pinch the ends of the control board and
3. If the board resists, gradually pull up one
4. Remove the control board by sliding it out
CAUTION! The pins of the control board
should not be obstructed by the components
on the power board.
1. Raise the one set of inductor wires that
passes over the control board, to allow
room for the control board to move.
Do not raise the other set of wires.
Raise t hese induct or wires
pull upward.
end at a time, alternating between the
two ends.
of the power board, avoiding any
components on the board.
