- Page 1 User Manual Operator Chair Carl - Model - Carl Foot R6 Rilis - Model - Carl Heel R6 Rilis - Model - Carl Foot R7 OneGrip - Model - Carl Heel R7 OneGrip Heel R7 Heel R6 Foot R7 Foot R6 2007-0004 v7...
-
Page 2: Table Of Contents
Operator Chair Carl Foot and Heel Table of content Operator chair Carl ................3 Important - Before use ..............3 Unpacking and installation ............. 3 Intended areas of use ..............4 Product identification label ............. 4 Basic adjustmets of the chair ............5 Model R6 - "Rilis"... -
Page 3: Operator Chair Carl
The model R6 is supplied with Rini's patented safety armrest "Rilis" that can be adjusted with high precision to the desired position. The model R7 is equipped with "OneGrip"... -
Page 4: Intended Areas Of Use
Operator Chair Carl Foot and Heel Mount the backrest, the armrests in the back or front bracket and raise the chair to a suitable height. Charge the battery to full capacity. Backrest Armrests 2.2 Intended areas of use The operator chairs Carl Foot and Carl Heel are developed for different types of microsurgery where the operator needs a stable seated work position with flexible relief for the arms. -
Page 5: Basic Adjustmets Of The Chair
Operator Chair Carl Foot and Heel 3. Basic adjustmets of the chair 1. Armrests can be places in two alterative positions, either in front of the seat or towards the back of the seat 2. Adjustment of height of backrest 3. -
Page 6: Model R7 - "Onegrip" Armrest
Operator Chair Carl Foot and Heel Setting 1 (coarse setting) Place the armrest in the front or back bracket and lock the position. Setting 2 (coarse setting) The height of the entire armrest can be adjusted so it is in the center of the work area for subsequent fine tuning. -
Page 7: Tips For Comfortable Position
Operator Chair Carl Foot and Heel Setting 1 (coarse setting) Place the armrest in the front or back bracket and lock the position. Setting 2 (coarse setting) The height of the entire armrest can be adjusted so it is in the center of the work area for subsequent fine tuning. -
Page 8: Replacing The Battery Modules
Operator Chair Carl Foot and Heel Charger inlet It takes approximately 12 hours to fully charge the battery and charging is automatically is switched off to avoid overcharging. The chair shall not be used during charging. Only the dedicated charger must be used for the chair. 4.2 Replacing the battery modules The batteries are mounted inside the control box and to replace them first unplug the control box connectors and remove the four screws. -
Page 9: Maintenance Of The Battery
Water Use damp cloth Repairs The product should only be repaired by Rini or a Rini authorised service centre. Product to be repaired under warranty must be sent to Rini factory or an authorised Rini service centre. Unauthorized repairs and modifications may result in loss of function and void warranty. -
Page 10: Ce Declaration Of Conformance
Atmospheric pressure 700 to 1060hPa Disposal and recycling The product is mainly made from environmentally recyclable materials as steel, stainless steel, aluminum and plastics. Rini recommends that the material be sorted and recycled in connection with the destruction of the product. -
Page 11: Warranty
Electronic parts and cables shall be handled as electronic waste in accordance with local requirements. The battery contains lead and is disposed according to current environmental legislation. Warranty The warranty is valid one year from the date of purchase. Please contact Rini for further information. - Page 12 Rini Ergoteknik AB Fågelsångsvägen 3B SE-186 42 Vallentuna Sweden Phone +46 8 594 77170 Email info@rini.se www.rini.se...
