- Page 1 User Manual Operator Chair Carl - Model - Carl Spring R6 Rilis - Model - Carl Swing R6 Rilis - Model - Carl Spring R7 OneGrip - Model - Carl Swing R7 OneGrip Spring R6 Swing R6 Swing R7 Spring R7 2007-0010 v8...
-
Page 2: Table Of Contents
Operator Chair Carl Spring and Carl Swing Table of content Operator chair Carl ................3 Important - Before use ..............3 Unpacking and installation ............. 3 Intended areas of use ..............4 Product identification label ............. 4 Basic adjustment of the chair ............5 Model R6 - "Rilis"... -
Page 3: Operator Chair Carl
The model R6 is supplied with Rini's patented safety armrest "Rilis" that can be adjusted with high precision to the desired position. The model R7 is equipped with "OneGrip" armrest, popular when small adjustments are required. -
Page 4: Intended Areas Of Use
Operator chair Carl Spring and Carl Swing b) Carl Spring has a cone that shall be placed on the thicker end of the gas spring (see picture below). For all models the seat is then placed on the cone and then the backrest. c) Finally put the armrest into the armrest bracket and tighten. -
Page 5: Basic Adjustment Of The Chair
Operator chair Carl Spring and Carl Swing 3. Basic adjustment of the chair 1. Armrests can be places in two alterative positions, either in front of the seat or towards the back of the seat (shown are R6 armrests). 2. Adjustment of height of backrest 3. -
Page 6: Model R7 - "Onegrip" Armrest
Operator chair Carl Spring and Carl Swing Setting 1 (coarse setting) Place the armrest in the front or back bracket and lock the position. Setting 2 (coarse setting) The height of the entire armrest can be adjusted so it is in the center of the work area for subsequent fine tuning. -
Page 7: Tips For Comfortable Position
Operator chair Carl Spring and Carl Swing Setting 1 (coarse setting) Place the armrest in the front or back bracket and lock the position. Setting 2 (coarse setting) The height of the entire armrest can be adjusted so it is in the center of the work area for subsequent fine tuning. -
Page 8: Disinfection, Cleaning And Repairs
Water and soap Use damp cloth Repairs The product should only be repaired by Rini or a Rini authorised service centre. Product to be repaired under warranty must be sent to Rini factory or an authorised Rini service centre. Unauthorized repairs and modifications may result in loss of... -
Page 9: Safety
700 to 1060 hPa 7. Disposal and recycling The product is mainly made from environmentally recyclable materials as steel, stainless steel, aluminum and plastics. Rini recommends that the material be sorted and recycled in connection with the destruction of the product. - Page 10 Operator Chair Carl Spring and Carl Swing Rini Ergoteknik AB Fågelsångsvägen 3B SE-186 42 Vallentuna Sweden Phone +46 8 594 77170 Email info@rini.se www.rini.se...
