  • Page 1 User’s Model 731010 Manual AE5523 1000BASE-T Unit IM 731010-01E 1st Edition Yokogawa Electric Corporation...
  • Page 2 • Other company and product names are trademarks or registered trademarks of their respective holders. Revisions • 1st Edition: July, 2005 1st Edition : July 2005 (YK) All Rights Reserved, Copyright © 2005 Yokogawa Electric Corporation IM 731010-01E...
  • Page 3: Checking The Contents Of The Package

    Notes 1000BASE-SX SFP TRF2816ANLB OPNEXT LC connector, 0.85 µm, for Module FTRJ8519P1BNL Finisar 1000BASE-LX SFP TRF5836ANLB OPNEXT LC connector, 1.3 µm, for SMF Module FTRJ1319P1BTL Finisar Note Warranty applies only to interface modules that you purchase from YOKOGAWA. IM 731010-01E...
  • Page 4: Safety Precautions

    The general safety precautions described herein must be observed during all phases of operation. If the instrument is used in a manner not specified in this manual, the protection provided by the instrument may be impaired. Yokogawa Electric Corporation assumes no liability for the customer’s failure to comply with these requirements.
  • Page 5: Conventions Used In This Manual

    Calls attentions to actions or conditions that could cause light injury CAUTION to the user or damage to the instrument or user’s data, and precautions that can be taken to prevent such occurrences. Note Calls attention to information that is important for proper operation of the instrument. IM 731010-01E...
  • Page 6: Table Of Contents

    Chapter 1 Functional Overview and Names of Parts Functional Overview ..............1-1 Front Panel .................1-2 PoE Monitor Connector ..............1-3 Chapter 2 Operation Installing the Unit ................2-1 Installing the Interface Module............2-2 Chapter 3 Specifications Interface ..................3-1 Functions ..................3-2 General Specifications..............3-4 External Dimensions..............3-5 IM 731010-01E...
  • Page 7: Chapter 1 Functional Overview And Names Of Parts

    Incorrect operation can result in breakdown or deterioration of network media or related devices. Sufficient care must be taken when performing tests while connected to networks. Yokogawa does not assume any responsibility for damages resulting from incorrect operation.
  • Page 8: Front Panel

    SFP port A port for installing various SFP modules (need to be purchased separately). Attachment screw Used to fix the unit in place after inserting it in the AE5511. Lever Used to remove the unit from the AE5511. IM 731010-01E...
  • Page 9: Poe Monitor Connector

    PoE monitor terminals (V1 and G1, V2 and G2, and so on). Do not short the PoE monitor terminals. Doing so may cause malfunction. Note Cables are not included in the package. Use the following connectors or their equivalents. • Plug: 54306-2619 (by Molex) • Shell: 52370-2670 (by Molex) IM 731010-01E...
  • Page 10: Chapter 2 Operation

    2. Loosen the two attachment screws of the unit. 3. Pull the unit lever slowly toward you. The connectors disengage, and the unit comes out from the AE5511. 4. Hold the attachment screw with each hand, and pull the unit slowly out from the AE5511. IM 731010-01E...
  • Page 11: Installing The Interface Module

    Pull out the lever at the front, top section of SFP module and pull the lever toward you. The connectors disengage, and the SFP module comes out from the unit. Note The SFP module can be installed or removed with the power turned ON. IM 731010-01E...
  • Page 12: Chapter 3 Specifications

    Illuminates during line link up status. Blinks during a self-test. PoE monitor connector 26 pins (PoE voltage of each RJ-45 port can be monitored.) *1: An SFP module option, sold separately, is required. See page ii for the SFP module option. IM 731010-01E...
  • Page 13: Functions

    8 channels channel Statistical Total (frame), total (byte), rate (frame/s), rate (%), and rate (bps) items QoS statistical Two filters each consisting of 32-bit comparison and mask filter patterns and offset can be set. Frame length can be specified. IM 731010-01E...
  • Page 14 Packet error, reception rate error, packet delay error, IFG error, and layer 1 state change No. of recorded logs Up to 1000 events (log recorded at 1-s intervals min.) Transmit clock Range: ±100 ppm. Resolution: 1 ppm. Accuracy: 5 ppm ± 1 variable function digits IM 731010-01E...
  • Page 15: General Specifications

    Voltage 5 VDC or 3.3 VDC Power 47 W or less consumption Dimensions and Dimensions H40 × W200 × D260 [mm] (projections excluded) weight Weight Approx. 1 kg Operating Temperature 5 to 40°C environment Humidity 35 to 85% IM 731010-01E...
  • Page 16: External Dimensions

    External Dimensions Unit: mm Tolerance: ±3% IM 731010-01E...
