LCP locking screws
X02.214–260 LCP Locking Screw
(head LCP 2,4), length 14–60 mm,
self-tapping, with Stardrive
X12.102–124 LCP Locking Screw
length 12–60 mm, self-tapping,
with Stardrive
X13.012–060 LCP Locking Screw
length 12–60 mm, self-tapping
with hexagonal recess
Standard screws
X01.764–790 Cortex Screw
self-tapping with Stardrive
X04.814–860 Cortex Screw
self-tapping, with hexagonal recess
All screws are available sterile packed.
X-ray template
034.000.450 Distal Humerus Plate, dorsolateral,
with support
034.000.451 Distal Humerus Plate,
dorsolateral
034.000.452 Distal Humerus Plate,
medial
4
2.7 mm
® recess
3.5 mm,
® recess
3.5 mm,
2.4 mm, length 14–40 mm,
recess
®
3.5 mm, length 14–60 mm,
LCP Distal Humerus Plates
Implants
