Service Bulletin
Product(s)
Affected
Description
Date
M iT e k
3 0 1 F o u n ta in L a k e s I n d u st r ia l D r .
S t . C h a rle s , M O 6 3 3 0 1
P h o n e (8 0 0 ) 5 2 3 -3 3 8 0
F a x (6 3 6 ) 3 2 8 -9 2 2 2
w w w .m ii.c o m
MiTek Machinery
®
®
Cyber
, Cyber
A/T, SmartSet
®
EasySet
, and CombiSet
Installation of a Wedge Scraper
05/16/2003
®
®
, SmartSet
®
Saws
Rev
Created by
Reviewed by
Approved by
Pro,
SB 133
—
rr
gm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mitek Cyber
Summary of Contents for Mitek Cyber
- Page 1 MiTek Machinery Service Bulletin ® ® ® ® Cyber , Cyber A/T, SmartSet , SmartSet Pro, Product(s) Affected ® ® EasySet , and CombiSet Saws Installation of a Wedge Scraper Description 05/16/2003 Date M iT e k 3 0 1 F o u n ta in L a k e s I n d u st r ia l D r .
-
Page 2: Part Description
Service Bulletin ® ® ® ® Cyber , Cyber A/T, SmartSet , SmartSet Product(s) Affected ® ® Pro, EasySet , and CombiSet Saws Installation of a Wedge Scraper Description 05/15/2003 Date ® MiTek The enclosed wedge scraper assembly is to be installed on quadrant #3 of component cutting ®... - Page 3 Service Bulletin Figure 1: Operator’s View of Quadrant Figure 2: View of Quadrant from the Back Slide Slide Casting Casting Blade Blade Motor Blade Motor Brake Wedge Scraper Wedge Scraper Motor Mounting Mount Bracket Mounting Plate Bracket Installation Instructions If your saw does not have a touch screen, please refer to your equipment manual to determine how to fulfill steps #1-4 manually.
- Page 4 Service Bulletin THE BLADE MUST BE AT 95º TO AVOID HITTING THE SLIDE OR OTHER PARTS WHEN DRILLING THROUGH THE CASTING. CAUTION 5. Adjust the angle of the saw blade on quadrant #3 (the quadrant closest to the operator’s controls) to 95º.
- Page 5 Service Bulletin 10. Ensure that the drill will clearly miss anything located behind the casting before beginning to drill. 11. Drill a pilot hole completely through the slide with the 1/8” drill at each marked location. 12. Using the 5/16” drill, drill holes at the same two (2) locations, using the pilot holes as guides. 13.
- Page 6 Service Bulletin Figure 4: Wedge Scraper Assembly Side View of Wedge Scraper Assembly Front View of Wedge Scraper Assembly Wedge Scraper Bolts to Mount Assembly Wedge Scraper Bolts to Adjust Mounting Angle of Scraper Bracket 20. Using the 9/16” socket, loosen the two (2) hex head 3/8”-20x1/2” bolts (PN327261) on the wedge scraper, labeled “Bolts to Adjust Angle of Scraper”...
