Page 1 OPERATION AND MAINTENANCE MANUAL 001132 BLADE II™ SAW CAUTION: MiTek recommends printing this manual in high resolution using color ink. Many of the graphics may be unclear and may create an unsafe condition if this recommendation is not followed. ®...
Page 2 001132 BLADE II™ SAW Part # and Rev. 001132 rev. A Print Date 15 December 2023 Effectivity Frame 488 Revision Date Revised By Orig. Release Date 15 December 2023 Created By A. McIntire...
Page 3 EGAL OTICE Patents Made and sold under one or more of the following patents: U.S. 4,986,052 U.S. 5,837,014 U.S. 6,219,975 U.S. 5,385,339 U.S. 5,854,747 U.S. 6,260,263 U.S. 5,493,834 U.S. 5,873,567 U.S. 6,317,980 U.S. 5,568,862 U.S. 5,884,448 U.S. 6,389,762 U.S. 5,630,697 U.S.
Page 4 Corrections and Improvements To report errors or recommend improvements to this manual, please complete the Document Evaluation Form in the appendices. Mail or fax the form to: MiTek Machinery Division 301 Fountain Lakes Industrial Drive St. Charles, MO 63301 Attn: Engineering Manager, Fax: 636-328-9218 Use this page to record service bulletins and notices that you receive to keep your manual updated.
Page 5: Table Of Contents
ABLE OF ONTENTS Safety (English) Safety Indicator Signal Words ......... . 1 General Safety &...
Page 6 BLADE II SAW: TABLE OF CONTENTS Zona Restringida ........... 42 Marcar la zona restringida .
Page 7 BLADE II SAW: TABLE OF CONTENTS Software Overview ..........70 Overview of Home Screen.
Page 8 BLADE II SAW: TABLE OF CONTENTS Grease Gun Recommended ........124 Lubrication Amount .
Page 9 BLADE II SAW: TABLE OF CONTENTS Raising the Top Clamp ........152 Adjusting the Outfeed Clamp .
Page 10: Safety (English)
CHAPTER 1 AFETY NGLISH Safety Indicator Signal Words The following signal words and colors are used throughout this document to indicate safety hazards. Pay careful attention when you see them. The level of severity differs for each signal word and color. Refiérase a la Signal words are accompanied by graphics showing what personnel should or página 26 para...
Page 11: General Safety & Equipment Rules
BLADE II SAW: SAFETY General Safety & Equipment Rules Because it is impossible to anticipate every circumstance that might involve a hazard, the safety information provided in this equipment manual and on the machine is not all-inclusive. If this machine is operated or serviced using a...
Page 12 An E-stop may cause components to move without warning. • Only use procedures described in this manual. Any other procedures should be discussed with MiTek to verify it is done safely. For topics not covered in this manual or online, contact MiTek for advice.
Page 13: E-Stop Locations
Never disconnect or bypass any safety device or electrical interlock. • Torque bolts and fasteners to the specifications given by MiTek. If no torque specification is given, use industry standards. • Only qualified maintenance personnel shall make adjustments or remove, repair, or install safety devices.
Page 14: General Warnings
BLADE II SAW: SAFETY General Warnings WARNING HIGH VOLTAGE ELECTRICITY! May cause serious personal injury or death. Ensure only qualified electricians perform electrical service work. WARNING Read the equipment manual, safety labels, and all safety information provided before operating or maintaining this equipment.
Page 15: Lockout/Tagout
BLADE II SAW: SAFETY Lockout/Tagout Lockout/Tagout Guidelines Lockout/tagout all energized systems before performing maintenance on them. All lockout/tagout guidelines must be met according to OSHA 29 CFR 1910.147. A specific procedure should be included in your company’s energy control program. This manual is not intended to replace your company’s de- energizing or lockout/tagout procedure required by OSHA, but merely to provide general guidance.
Page 16 BLADE II SAW: SAFETY Electrical Lockout/Tagout Procedures Working on a Machine Outside the Machine’s Main Electrical Enclosure If you are working on the electrical transmission line to the machine, follow the procedure on page 8. Before performing maintenance on any machine with electrical power, lockout/ tagout the machine properly.
Page 17: Electrical Lockout/Tagout Procedures
BLADE II SAW: SAFETY 3. Attach a lock and tag that meet OSHA requirements for lockout/tagout. Figure 1-2: Sample of a Lockout/Tagout Mechanism on an Electrical Enclosure 4. Restrain or de-energize all pneumatic components, hydraulic components, and other parts that could have live or stored power.
Page 18 BLADE II SAW: SAFETY 1. Engage an E-stop on the Figure 1-3: Sample of a Lockout/ machine. Tagout Mechanism on a Power Source Panel 2. Shut the power to the machine off at the machine’s power source which is usually an electrical service entry panel on the facility wall.
Page 19: Hydraulic Or Pneumatic System Lockout/Tagout Procedure
BLADE II SAW: SAFETY Hydraulic or Pneumatic System Lockout/Tagout Procedure Before working on or near hydraulic or pneumatic components, bleed the lines of pressure. When Lockout/Tagout Is Not Required If working on components other than the hydraulic or pneumatic system that require you to be in the vicinity of movable hydraulic or pneumatic components, you must, at a minimum, physically restrain those components from moving.
Page 20: Troubleshooting With An Energized Machine
BLADE II SAW: SAFETY Troubleshooting with an Energized Machine Only a qualified electrician, using the personal protective equipment and following the procedures recommended in NFPA 70E should ever attempt service or repair of or near an energized area or component of the machine.
Page 21: Treatment For Hazardous Substances
2. Make sure sharp objects are clear of all pneumatic and electrical system cables. 3. Check the BLADE II Saw for debris or tools that would block the path of parts. Remove any that you may find. The following locations are especially important: •...
Page 22: Inspecting Indicators
BLADE II SAW: SAFETY • Infeed Rail • LASM clamp • Infeed and Outfeed clamps • Outfeed component (Skewed Conveyor or CDS) 4. Check saw blade condition (see When to Replace the Saw Blade on page 108) 5. Remove lockout/tagout and return electrical power and pneumatic pressure to the machine.
Page 23: Interlock Door Test
BLADE II SAW: SAFETY 1. Start running the saw and all integrated components: a) Power up the saw using the instructions on Powering Up or Down on page b) Place the machine in MANUAL mode using the switch on the operator interface.
Page 24: Testing Movement While E-Stop Is Active
BLADE II SAW: SAFETY • Other Infeed or Outfeed Component E-stops (will vary depending on setup) 4. Ensure that the blade and integrated components stop motion in a timely manner: • If the saw blade does not stop within 5-10 seconds, contact Automation Support immediately for resolution.
Page 25: Restricted Zone
BLADE II SAW: SAFETY Restricted Zone DANGER Stay out of the restricted zone when equipment is in use. Serious injury or death may result if personnel are in the restricted zone. Always look for personnel in the restricted zone before operating equipment.
Page 26: Safety Symbol Definitions
BLADE II SAW: SAFETY Safety Symbol Definitions The safety symbols shown in this section are found throughout the manual to indicate hazards related to this machine. All personnel expected to operate or maintain this machine should be familiar with these safety symbols and their meanings.
Page 27 BLADE II SAW: SAFETY Slip hazard. Use of appropriate footwear is required. Trip hazard. Pay attention when walking in this area. Kickback hazard. Keep hands clear of cutting parts. Original Instructions: 001132 rev. A...
Page 28 BLADE II SAW: SAFETY Keep hands and body clear. Hot surface. Surface temperature can exceed 158°F (70°C) during normal operation. Do not touch. Ventilate. Slots and openings in the cabinet are provided for ventilation to ensure reliable operating of the equipment. To protect the equipment from overheating, those openings must not be blocked or covered.
Page 29 BLADE II SAW: SAFETY High pressure hose. Use appropriate PPE when working on equipment. Maintain safe pressure level at all times. Equipment has automatic restarting capability. Lockout/tagout on the upstream disconnect before servicing. The operation of this equipment requires the use of PPE.
Page 30 BLADE II SAW: SAFETY Refer to manual. After installation, read the user’s guide carefully before operating. Follow all operating and other instructions carefully. Circuits are live. Lockout/tagout on the upstream disconnect prior to servicing. Lockout in a de-energized state. Lift point. In order to decrease the likelihood of damage to the equipment, use only the lift points indicated in the manual.
Page 31 BLADE II SAW: SAFETY To reduce the risk of equipment damage or injury to personnel, maintain pressure at safe levels. Use of a safety harness is mandatory when working above ground floor. Use of lift equipment is mandatory. Consult material safety data sheet.
Page 32 BLADE II SAW: SAFETY Do not place containers with liquids such as coffee, water, soda, etc. on this equipment. Do not operate this equipment in a wet environment. Do not expose to water. No lift point. Do not lift this device with a hook/crane assembly.
Page 33 BLADE II SAW: SAFETY Do not weld. Do not discard into the municipal waste stream. Indicates notes regarding lubrication. Original Instructions: 001132 rev. A...
Page 34: Declaration Of Safety Conformity
BLADE II SAW: SAFETY Declaration of Safety Conformity Conforms electrically to the following: • NFPA 79 • NEC Electrical Code • Electrical enclosures conform to UL 508A and are labeled for UL/cUL for Canada • Safety circuit conforms to Category 4 redundant monitoring Conforms mechanically to the following: •...
Page 35: Seguridad (Español)
CHAPTER 2 EGURIDAD SPAÑOL Indicadores de seguridad: Palabras de aviso Las siguientes palabras y colores de aviso se utilizan a lo largo de este documento para indicar riesgos de seguridad. Preste suma atención cuando los vea. El nivel de gravedad es diferente por cada palabra o color de aviso. Las palabras de aviso van acompañadas por gráficos que muestran al personal lo que deben y no deben hacer.
Page 36: Reglas De Seguridad Para El Equipo De General
BLADE II SAW: SEGURIDAD Reglas de seguridad para el equipo de general Debido a la imposibilidad de anticipar todas las circunstancias que podrían constituir un riesgo, la información de seguridad suministrada en este manual del equipo y sobre la máquina no es exhaustiva. Si se utiliza o realiza el mantenimiento de esta máquina utilizando un procedimiento no recomendado...
Page 37 • Use solamente los procedimientos descritos en este manual. Cualquier otro procedimiento debe analizarse con MiTek para verificar que sea seguro. Para los temas que no se traten en este manual o en línea, póngase en contacto con MiTek para recibir asesoramiento.
Page 38: Ubicación De Un Paro De Emergencia
No desconecte ni evite nunca ningún dispositivo de seguridad ni interbloqueo eléctrico. • Apriete los pernos y tornillos al par de apriete especificado por MiTek. Si no se especifica el par de apriete, use los estándares de la industria.
Page 39: Advertencias Generales
BLADE II SAW: SEGURIDAD Advertencias generales WARNING ¡ELECTRICIDAD DE ALTO VOLTAJE! Puede causar lesiones personales graves o la muerte. Asegúrese de que solo electricistas calificados realicen trabajos de servicio eléctrico. WARNING Lea el manual del equipo, las etiquetas de seguridad y toda la información de seguridad suministrada antes de operar o hacerle...
Page 40: Bloqueo/Etiquetado
BLADE II SAW: SEGURIDAD Bloqueo/Etiquetado Pautas de bloqueo/etiquetado Deben cumplir con todas las pautas de bloqueo/etiquetado conforme a la norma OSHA 29 CFR 1910.147. El programa de control de energía de la compañía debe incluir un procedimiento específico. El objetivo de este manual no es reemplazar el procedimiento de desenergización o bloqueo/etiquetado...
Page 41: Procedimientos De Bloqueo/Etiquetado Eléctricos
BLADE II SAW: SEGURIDAD Procedimientos de bloqueo/etiquetado eléctricos Cuando trabaja en una máquina fuera del gabinete eléctrico principal de la máquina Si trabaja en la línea de transmisión eléctrica a la máquina, siga el procedimiento de la page 34. Antes de realizar el mantenimiento de cualquier máquina con alimentación eléctrica, bloquee y etiquete la máquina de forma adecuada.
Page 42 BLADE II SAW: SEGURIDAD 3. Coloque un candado y una etiqueta que cumplan con los requisitos de bloqueo/etiquetado de la OSHA. Figura 2-2: Mecanismo de bloqueo/etiquetado en un gabinete eléctrico principal 4. Trabe o desenergice todos los componentes neumáticos y otras piezas que tengan alimentación directa o almacenada.
Page 43: Cuando Trabaje En Una Máquina Dentro Del Gabinete Eléctrico Principal De La Máquina O En La Línea De Transmisión Eléctrica A La Máquina
BLADE II SAW: SEGURIDAD Cuando trabaje en una máquina dentro del gabinete eléctrico principal de la máquina o en la línea de transmisión eléctrica a la máquina Antes de abrir el gabinete eléctrico principal o intentar reparar o reemplazar una línea de transmisión eléctrica a la máquina, bloquee y etiquete la máquina en forma adecuada.
Page 44: Procedimiento De Bloqueo/Etiquetado Del Sistema Hidráulico O Neumático
BLADE II SAW: SEGURIDAD Procedimiento de bloqueo/etiquetado del sistema hidráulico o neumático Antes de realizar el mantenimiento de los sistemas neumáticos, purgue las líneas para eliminar la presión. Cuando no se requiere bloqueo/etiquetado Si trabaja con componentes que no son del sistema neumático pero que requieren su presencia en la proximidad de componentes neumáticos móviles,...
Page 45: Solución De Problemas Con Una Máquina Energizada
BLADE II SAW: SEGURIDAD Solución de problemas con una máquina energizada Sólo un electricista calificado que utilice el equipo de protección personal y siga los procedimientos recomendados en la norma NFPA 70E debe intentar realizar tareas de reparación o mantenimiento en un área o componente energizados de la máquina o en su proximidad.
Page 46: Inspección General
BLADE II SAW: SEGURIDAD Table 2-2: Cómo tratar el contacto con una sustancia peligrosa Si una Haga esto... sustancia entra Tinta de impresora Limpiador de en contacto impresora con... La piel/ropa Enjuague, quítese la Enjuague, quítese la ropa y lave la piel con ropa y lave la piel con jabón...
Page 47: Pruebas De Seguridad
BLADE II SAW: SEGURIDAD 3. Verifique que la sierra BLADE II no tenga desechos ni herramientas que pudieran obstruir sus piezas. Retire todo lo que encuentre. Los siguientes lugares son especialmente importantes: • Componente de alimentación (Auto Deck o Ranger) •...
Page 48 BLADE II SAW: SEGURIDAD Prueba del interbloqueo de las puertas Esta prueba tiene por objeto verificar que las puertas interbloqueadas NO se abran cuando la cuchilla de la sierra esté en movimiento. CAUTION PELIGRO DE APLASTAMIENTO Y CORTE. Antes de encender el equipo, asegúrese de que todo el personal y los equipos estén alejados.
Page 49: Prueba Del Interbloqueo De Las Puertas
BLADE II SAW: SEGURIDAD Prueba de los paros de emergencia CAUTION PELIGRO DE APLASTAMIENTO Y CORTE. Antes de encender el equipo, asegúrese de que todo el personal y los equipos estén alejados. 1. Comience haciendo funcionar la sierra y todos los componentes integrados: a) Encienda la sierra según las instrucciones de Encendido o apagado...
Page 50: Prueba De Los Paros De Emergencia
BLADE II SAW: SEGURIDAD • Si la cuchilla de la sierra y los componentes integrados se detienen según lo esperado, repita el procedimiento para probar todos los paros de emergencia indicados en step 3. Prueba de movimiento mientras el paro de emergencia está...
Page 51: Zona Restringida
BLADE II SAW: SEGURIDAD Zona Restringida DANGER Manténgase afuera de la zona restringida cuando el equipo esté en uso. Pueden producirse lesiones graves o incluso la muerte si el personal está en la zona restringida. Asegúrese que no haya personal en la zona restringida antes de operar el equipo.
Page 52: Información Adicional
BLADE II SAW: SEGURIDAD Información adicional Definiciones de los símbolos de seguridad página (Safety Symbols Definitions) Declaraciones de Cumplimiento página (Declarations of Conformity) Declaración de emisión de ruidos página (Declaration of Noise) Original Instructions: 001132 rev. A...
Page 53: Introduction
This manual addresses the most recent version of the equipment as of the date listed on the title page. For earlier revisions, contact MiTek as described on page 47. Original Instructions: 001132 rev. A...
Page 54: Introduction To The Manual
BLADE II SAW: INTRODUCTION Understanding the Manual Hyperlinks All text references colored blue (in form of page numbers, headings, etc.) can be selected to immediately take you to the relevant section. The Drawing Set A list of drawings can be found in the back of this equipment manual or in a separate 11x17 binder.
Page 55 BLADE II SAW: INTRODUCTION Operator Training Outline Subject Training and Related Links • Show the operator how to access the manual on the Using the Manual MiTek website. • Review the lockout/tagout procedures for all machine Safety systems: Lockout/Tagout on page •...
Page 56: Additional Resources
BLADE II SAW: INTRODUCTION Additional Resources Website Visit the MiTek website for up-to-date information on all MiTek equipment. You may also find the following information there: • The latest revisions of this manual • Service bulletins pertaining to your equipment •...
Page 57: General Information
NFORMATION Introduction to the Equipment Purpose of the Equipment The BLADE II Saw helps Roof Truss and Floor Truss Component Manufacturers cut more high-mix chords and web parts by avoiding machine downtime and increasing throughput with more green-light time. Description of the Equipment The BLADE II Saw includes the following components: •...
Page 58: Main Components
BLADE II SAW: GENERAL INFORMATION Main Components Graphical Overview Figure 4-1: Main Components of the BLADE II Saw Operator Interface Infeed Rail Skewed Conveyor Waste Conveyor Optional Components on page 49 for graphics of other components not shown here Descriptions...
Page 59: Optional Components
BLADE II SAW: GENERAL INFORMATION Name Description Moves waste from the saw to the point of removal. A standard Waste Conveyor and extended size are available. Optional Components Graphical Overview Figure 4-2: Auto Deck (Infeed Component) Figure 4-3: Ranger (Infeed Component)
Page 60: Descriptions
Figure 4-4: Component Delivery System (Outfeed Component) Descriptions Table 4-2 lists the optional components that may be added at the point of sale or added later as a paid upgrade. Contact MiTek for more information (see Contact Us on page 47).
Page 61: Second Display Support
Second Display Support The BLADE II Saw supports outputting truss/part data and production metrics to a second display. When purchasing a monitor for this use, it is highly recommended to obtain the specifications listed here: •...
Page 62 BLADE II SAW: GENERAL INFORMATION Table 4-5: Lumber and Cut Capacity Specification Data Edge of board 1-3/8" to 1-5/8" Face of board 2-1/2" to 11-7/8" Maximum length of board 16' ( 20' option available) Shortest length to exit saw chamber 2"...
Page 63 BLADE II SAW: GENERAL INFORMATION Table 4-10: Weight Specifications Specification Data 8,900 lbs Infeed rail - 16' 1360 lbs Infeed rail - 20' 1600 lbs Skewed Conveyor - 16' 900 lbs Skewed Conveyor - 20' 1100 lbs Table 4-11: Environmental Requirements...
Page 64: Installation & Startup
CHAPTER 5 & S NSTALLATION TARTUP Requirements to Meet for Installation Refer to your original Pre-Installation document for all requirements that must be met before or during installation. Refer to the General chapter for machine specifications and requirements. Moving the Equipment Into Place Follow these guidelines to safely move this equipment with a forklift or crane.
Page 65: Saw Chamber
BLADE II SAW: INSTALLATION Saw Chamber Figure 5-2: Saw Chamber Lift Points Skewed Conveyor The skewed conveyor does not include dedicated lift points. MiTek recommends using two forklifts to lift the skewed conveyor at the points shown in Figure 5-3.
Page 66: Auto Deck
Your Responsibilities During Installation MiTek supervises the installation to ensure that the system is installed properly and operates correctly. MiTek will also provide operating and maintenance training at the time the equipment is installed. The customer is responsible for providing all labor and equipment needed to complete the installation.
Page 67: Startup Procedures
WARNING Do NOT attempt to start the system for the first time without a MiTek representative present. Starting the system without a MiTek representative present may result in equipment damage, serious injury, and/or death. Marking Restricted Zone The restricted zone must be marked and maintained so everyone near the equipment can clearly see the area where danger may exist.
Page 68: Operation
CHAPTER 6 PERATION Safety Operating Notes WARNING ELECTROCUTION, HIGH PRESSURE, CRUSH, CUT, AND CHEMICAL HAZARDS. Read this section AND the safety section in the preliminary pages before operating or maintaining this machine. Do not operate this machine until you have a thorough understanding of all controls, safety devices, E-stops, and operating procedures outlined in this manual.
Page 69: Safety-Related Operating Procedures
Safety-Related Operating Procedures Stopping Methods This BLADE II Saw may be stopped by using a cycle stop or an emergency stop (E-stop). Engaging an E-stop will stop all movement on the Auto Deck, infeed rail, saw component, and skewed conveyor. It does NOT include other material handling systems, even those supplied by MiTek.
Page 70: Restart After E-Stop Procedure
BLADE II SAW: OPERATION Figure 6-2: E-Stops (Rear View) Electrical Infeed Rail Enclosure E-Stop E-Stop How to Operate an E-Stop Pushbutton To activate a pushbutton, push the button in. The machine no longer operates. To release a pushbutton, twist the...
Page 71: Disconnect Switch
BLADE II SAW: OPERATION Disconnect Switch There are 3 disconnect switches located on the main components of the BLADE II Saw. Figure 6-3: Everything You Need to Know About Disconnect Switches Electrical Enclosure Disconnect Switch Turning the disconnect handle to the On position supplies electrical power to the entire machine.
Page 72: Interlocked Doors Or Guards
BLADE II SAW: OPERATION Interlocked Doors or Guards Overview There are three doors located on the saw chamber that are interlocked with the safety system to prevent entry while components are moving. These doors may be opened via two methods.
Page 73 BLADE II SAW: OPERATION Door Interlock Switches The doors shown in Figure 6-4 also include interlock switches that allow the doors to be manually opened by qualified maintenance personnel with the use of a flathead screwdriver. See Figure 6-5 for instructions on how to use and reset the interlock switches.
Page 74: Safety-Related Indicators On The Machine
BLADE II SAW: OPERATION Safety-Related Indicators on the Machine This section covers visual and audio indicators that communicate important information about the status of the machine. Light and Horn Beacon The beacon is located on top of the machine’s Figure 6-6: Light and Horn Beacon on Main Enclosure main electrical enclosure.
Page 75 BLADE II SAW: OPERATION Operator Interface Indicator Lights The lights located on the Figure 6-7: Operator Interface Indicator Lights operator interface indicate the following: BLADE IN MOTION: Red light turns on when the blade is spinning. Certain doors can not be opened while this light is on.
Page 76: Hardware Overview
Auto Manual Table 6-1: Description of Operator Interface Controls Name Function E-stop Stops all movement on the entire BLADE II. Start Starts the blade motor Stop Stops the blade motor (Manual Mode) Reset Restores the safety controller and re-enables main power to the system.
Page 77 BLADE II SAW: OPERATION Name Function USB Ports Can be used to connect a mouse or keyboard or other USB devices Skewed Conveyor The Skewed Conveyor will automatically start running when a cutting job has been initiated. To turn the Skewed Conveyor off (or back on), turn the selector switch to either the STOP or START position and release the switch.
Page 78: Powering Up Or Down
6-10. Figure 6-10: Auto Deck Controls Table 6-2: Description of Auto Deck Controls Name Function E-stop Stops all movement on the entire BLADE II. Forward/Reverse Controls which direction the Auto Deck staging conveyor chains (Deck Direction) run. Raise/Lower Controls the lumber stops.The lumber stops serve two...
Page 79 BLADE II SAW: OPERATION 3. Double-click the BLADE software icon and wait for it to launch. 4. Press the blue RESET button on the operator interface. • The blue light goes out if all E-stops are cleared. If the RESET button...
Page 80: Software Overview
The BLADE II Saw operator interface is designed as a touch first device but it can also be used with a mouse and keyboard. See below for a list of terms that will be...
Page 81 BLADE II SAW: OPERATION Main Menu and Ribbon The main menu refers to the selections at the top of the home screen. As shown Figure 6-11, the functions within each main menu appear in the ribbon. See Main Menus in Detail on page 77 for a detailed description of each main menu and ribbon.
Page 82: Lumber Yard
BLADE II SAW: OPERATION Name Description Machine Shows errors found in the Machine tab under Diagnostics > Detailed Diagnostics, including E-stops, and Auto/Manual Mode switch. Additional troubleshooting must be done using Diagnostics which requires administrative permissions. Toolbar The Toolbar stays active at all times on the Home Screen. Some buttons may change function or become unavailable (greyed out) due to the status of the saw.
Page 83: Key In Part
BLADE II SAW: OPERATION • board: a specific piece of lumber required by the saw to cut out specific parts; lumber becomes a board when the software decides exactly how to use it • infeed component: any component that feeds lumber to the Infeed Rail;...
Page 84 BLADE II SAW: OPERATION Figure 6-13: Key In Part Select Screen The Key-In screen, which opens after selecting a part, allows the operator to enter the details of the part (see Figure 6-14). • If using a lumber feed system that allows stations to be chosen, the Grade, Stock Size, and Stock Length will be populated for boards being loaded from a station.
Page 85: Cut List Screen
BLADE II SAW: OPERATION If entering dimensions, one of the cuts must be calculated to ensure correct cutting of the part. Other functions include: • Validate and Draw Part updates the part based on the information entered. • Add to add the part to the Remainder or Cut List.
Page 86 BLADE II SAW: OPERATION Long-Press Menu From Cut List When a board is first selected and then long-pressed in the Cut List, most of the choices in Table 6-6 are available. When a part is long-pressed, fewer choices are available.
Page 87: Main Menus In Detail
BLADE II SAW: OPERATION Main Menus in Detail File Menu • Import Jobs: Allows files to be imported to Cut List. The different network options are customizable default folders for common job file directories (see Figure 6-16). Use Get Files to browse to a specific location if needed.
Page 88 BLADE II SAW: OPERATION Visualize: Displays an image of the saw components and active board at any point in time. The image changes as the position of the components move. Logs: Allows detailed information of each part or board to be displayed, including print information.
Page 89 BLADE II SAW: OPERATION Material Handling View Remainders: Shows the remainder list and allows the operator to manage the list and the options for each part. To add a new remainder part, see Managing Remainders. Reset Unprocessed Reset all boards in the active job so the job can be Boards: started over or skipped.
Page 90: Quick Software Troubleshooting
Troubleshooting on page 172 and on the MiTek website, but the most common operator interface problems can be solved by following the instructions here. Specifically, if a button or field is grayed out or not available, try these steps first.
Page 91: Operating Procedure
BLADE II SAW: OPERATION Operating Procedure This section instructs operators how to effectively use the BLADE II Saw. This machine offers two operating modes (AUTO and MANUAL) but it is designed be used in AUTO mode for standard production. MANUAL mode may be required for troubleshooting, performing maintenance, or changing software settings.
Page 92: Specialized Operating Procedures
BLADE II SAW: OPERATION Specialized Operating Procedures Preparing the Auto Deck 1. Ensure all E-stops have been released and the RESET button on the saw’s operator interface panel was pressed. CAUTION CRUSH HAZARD. When an E-stop is released, the load arms on the Infeed Rail may automatically raise with high force.
Page 93 BLADE II SAW: OPERATION Dealing with Imperfections • Crown: a curve of the edge of a board (1-1/2” edge on a 2x4); the crown points up on floor studs or out for wall studs in constructed homes; place board so crown points up as it enters saw •...
Page 94 BLADE II SAW: OPERATION 5. Select the Continue button and the board feeds into the saw chamber for cutting. Operating the Printer The Printer(s) print identification on each board as it enters the saw chamber. Each saw has at least 1 printer.
Page 95 Figure 6-18: Tools > Options > Printers Menu Other Printing Options (Board Stretcher) The printing features controlled by the BLADE II Saw software are minimal. Most printing control is located in the Board Stretcher software. The following topics are discussed further in the Board Stretcher manual. The manual can be accessed on MiTek website.
Page 96 BLADE II SAW: OPERATION Managing Remainders The saw program can maintain a list of default components or remainders, selected by the user, which may be processed from any waste remaining after the cutting list has been run through the normal optimizing routine. The remainder components are entered and assigned a priority by the saw operator, based on the required demand and existing supply of such items.
Page 97 BLADE II SAW: OPERATION Rejecting or Resetting Jobs and Boards Individual parts can not be rejected. • To reject/reset one board, right-click on the board in the Cut List and select Reject or Reset. • To reject/reset a series of boards in the Cut List, select one row, then immediately select a lower row.
Page 98 BLADE II SAW: OPERATION Determining Board Recovery Solutions Understanding Board Figure 6-21: Board Recovery Options Recovery The screen shown in Figure 6- will appear when a board has a status of In Process and the START CUTTING button is selected. It is the result of the saw having been stopped in the middle of a job.
Page 99: Calibration
BLADE II SAW: OPERATION Queue 1 Place the new board on the Auto Deck, above the load arms, so it is the next board to be placed on the Infeed Rail. Complete No more parts are needed from the interrupted board (in the software), so don’t manually load anything.
Page 100: Maintenance
Certain parts should be kept in stock at your facility. These parts are listed in the Ordering Parts appendix. Overview Graphics General Information on page 47 for an overview on the main and optional components of the BLADE II Saw. Original Instructions: 001132 rev. A...
Page 101: Maintenance Terminology
BLADE II SAW: MAINTENANCE Maintenance Terminology The orientation terminology in Figure 7-1 will be utilized throughout the maintenance section when referring to different sides of the BLADE II Saw. Figure 7-1: Orientation Terminology for Saw Component Rear Side Infeed Side Outfeed Side Front Side Original Instructions: 001132 rev.
Page 102: Major Components
BLADE II SAW: MAINTENANCE Major Components The following graphics call out major components that will be referenced throughout the maintenance chapter. Figure 7-2: Major Components Visible from Infeed Side of Saw Top Clamp Elevation Assembly Assembly (shown in down position) Raises and lowers saw head Printer &...
Page 103: Axes And Home Positions
BLADE II SAW: MAINTENANCE Figure 7-4: Major Components Visible from the Outfeed and Read Side of Saw Electrical Enclosure (2 Doors) Printer Supplies Axes and Home Positions There are 6 major axes referred to on this equipment. Their definitions and home positions are shown in the following graphics.
Page 104 BLADE II SAW: MAINTENANCE Figure 7-5: Elevation and Stroke Axes (Side View) Blade Orientation Home = Edge Faces Operator (shown) Stroke Home = Retracted (shown) Home = At Bottom (shown at top) Figure 7-6: LASM Axis “0” Position LASM is at “0”...
Page 105 BLADE II SAW: MAINTENANCE Figure 7-7: LASM Axis Isolated LASM at Home LASM at “0” LASM “0” and Home Positions align with sensors Figure 7-8: Gripper Axis Gripper in Home Position Original Instructions: 001132 rev. A...
Page 106 BLADE II SAW: MAINTENANCE Figure 7-9: Bevel and Angle Axis BEVEL CUT Home = 90° (0° is shown) Board Direction Top View ANGLE CUT Home = 90° (shown) Board Direction Blade Front View Original Instructions: 001132 rev. A...
Page 107: Cleaning
BLADE II SAW: MAINTENANCE Cleaning Cleaning Saw Dust and Debris It is important to blow off and vacuum the equipment daily. Saw dust acts as an insulator and will prevent electrical components from working properly, and debris causes mechanical jams.
Page 108: Cleaning Surfaces
BLADE II SAW: MAINTENANCE Cleaning Surfaces If it should become necessary to clean the surfaces of this machine, disconnect it from its power source first. Do not use liquid cleaners, aerosols, abrasive pads, scouring powders or solvents, such as benzene or alcohol. Use a soft cloth lightly moistened with a mild detergent solution.
Page 109: Motors And Gearboxes
BLADE II SAW: MAINTENANCE Motors and Gearboxes Motor Locations Figure 7-10: Front and Rear View of Saw Bevel Infeed Rail Outfeed Chain Saw Blade LASM Elevation Waste Conveyor Stroke Angle Original Instructions: 001132 rev. A...
Page 110: Motor Maintenance
BLADE II SAW: MAINTENANCE Figure 7-11: Auto Deck and Skewed Conveyor Skewed Conveyor Auto Deck Motor Maintenance Table 7-2: Overview of Motor Maintenance Motor Gearbox (if Requires Grease Requires Oil present) Angle Elevation (with brake) Stroke Bevel Saw Blade LASM...
Page 111: Lubricating Saw Blade Motor Bearings
BLADE II SAW: MAINTENANCE Table 7-3: Recommended Oil Specifications for Motor Gearboxes Motor ISO Viscosity Oil Type Oil Supplied by Grade Manufacturer Outfeed Chain Synthetic Polyglycol Klübersynth UH1 6-680 Waste Conveyor Synthetic Polyglycol Klübersynth UH1 6-680 Auto Deck Synthetic Polyglycol Klübersynth UH1 6-680...
Page 112 BLADE II SAW: MAINTENANCE Figure 7-13: Saw Blade Motor Grease Fitting Locations Opposite Drive End Fitting Drive End Fitting Original Instructions: 001132 rev. A...
Page 113: Slippage Errors And Tightening Motor Couplings
BLADE II SAW: MAINTENANCE Slippage Errors and Tightening Motor Couplings Slippage Errors Figure 7-14: Potential Causes of Gripper Slippage Error 1. Check for mechanical obstructions 2. Check the home sensor, bracket, like wedges, damaged parts, etc. that and target plate for damage.
Page 114 BLADE II SAW: MAINTENANCE Figure 7-15: Potential Cause of LASM Slippage Error 1. Check for mechanical obstructions like wedges, damaged parts, etc. that may inhibit the axis from moving freely. 2. Ensure LASM travels 6. Check the quality of the saw blade smoothly, does not hit and ensure it spins smoothly.
Page 115 BLADE II SAW: MAINTENANCE Figure 7-16: Potential Causes of Stroke Slippage 1. Check for mechanical obstructions like wedges, damaged parts, etc. that may be 8. Move to Min/Max positions inhibiting the axis from moving freely. and ensure bumpers do not hit hard stops.
Page 116: Tightening Motor Coupler On Servo Motors
BLADE II SAW: MAINTENANCE Tightening Motor Coupler on Servo Motors This section contains instructions for setting the correct torque values for various motor couplers. Table 7-5: Torque Values for Input and Output Couplers Motor Torque (in-lbs) Hex Size INPUT LASM...
Page 117 BLADE II SAW: MAINTENANCE b) For other couplers: With power on, enter small position changes in Diagnostics > Detailed Diagnostics > Move To Position fields to move motor coupler in small increments. 3. Torque bolt to the appropriate setting (see Table 7-5) using a torque wrench and hex key.
Page 118: Elevation Jack Screw
BLADE II SAW: MAINTENANCE Elevation Jack Screw The elevation jack screw raises and lowers the saw head. Apply grease to the 2 fittings on the jack screw housing every 3 months. Figure 7-19: Elevation Jack Screw Grease Fittings Location Manual grease Grease Fittings No.2 lithium-...
Page 119 BLADE II SAW: MAINTENANCE Specs for New or Used Saw Blade Saw blades can be sharpened to significantly extend their life. They must be sharpened by a reputable blade sharpener that is familiar with carbide tips. It is important to meet the specifications etched into each saw blade. If any specification is not met, it can cause the saw blade to cut inefficiently, inaccurately, and/or rotate out of balance.
Page 120 BLADE II SAW: MAINTENANCE 1. Gather the following supplies: • Socket Wrench • Torque wrench with capacity up to 220 in-lbs • T40 Torx™ bit compatible with wrench 2. Use the machine software to position the saw head to prepare for saw...
Page 121 BLADE II SAW: MAINTENANCE 6. Use a socket wrench and T40 bit to loosen and remove the 5 bolts securing the saw blade (shown in red in Figure 7-21). Discard the bolts. Figure 7-21: Bolts Securing Saw Blade Bevel Motor...
Page 122 BLADE II SAW: MAINTENANCE b) Wipe down the mounting surface on the new saw blade and the hub. Use a 320-grit emery cloth, if necessary, to remove pitch. c) Ensure all parts are clean, dry, and free of lubricants. d) If using a used saw blade, measure its diameter from outside edge of tooth to outside edge of tooth.
Page 123: Printer
Printer Ordering Printer Supplies To order supplies for the BLADE II printer, contact Matthews directly. MiTek does not sell the ink or cleaning solution. Once the account is set up, future orders can placed by providing a PO any of the three ways listed here.
Page 124: Placing Your First Supplies Order Through Matthews
MUST be present at the installation of the saw. MiTek does not sell the ink and cleaner solutions. The most efficient way to place your first order is as follows.* 1.
Page 125: Printer Components Overview
BLADE II SAW: MAINTENANCE prior to the saw installation date to ensure the supplies will be there during installation. * Failure to supply a purchase order will delay the shipment of supplies. If you do not have the credit form, contact Matthews to obtain a credit application. These supplies may also be purchased from an approved local distributor.
Page 126: Maintaining The Printer
BLADE II SAW: MAINTENANCE Maintaining the Printer General Maintenance Reminders • Always wear safety glasses and rubber gloves when handling ink. • Never clean nozzles with pressurized air. • Use only the correct Matthews inks and cleaners. Failure to do so will damage the unit and void the warranty.
Page 127: Cleaning The Printer
BLADE II SAW: MAINTENANCE Cleaning the Printer CAUTION Wear goggles and gloves when handling ink/cleaner. Never wash ink or cleaner in a location where food or dishes may be. Rinse area well when done. If ink or cleaner makes contact with a person’s skin, hair, eyes, or clothes, refer to...
Page 128: Flushing The Printer
Option AGS+ option AGS+ option The Flushing Procedure Go to Diagnostics > Detailed Diagnostics > Printer in the BLADE II software, and follow the instructions in Figure 7-27 to flush any print head. The 16- and 32-valve print head has a valve controlled by the screen in Figure 7-26 to switch between ink and cleaner.
Page 129 BLADE II SAW: MAINTENANCE Figure 7-26: Printer Flush Settings in Software Select Ink or Cleaner Select to Flush Printhead Dropdown Selector Figure 7-27: Procedure for Flushing FLUSHING INK OUT FLUSHING CLEANER OUT To bring cleaner in... To bring ink in...
Page 130: Manually Purging Ink Or Cleaner From Lines
BLADE II SAW: MAINTENANCE Figure 7-28: Manual Valve for 7-Valve Print Heads Infeed Side Tubing not shown connected to valve in graphic Manually Purging Ink or Cleaner From Lines Flushing the existing fluid from the printer lines will eventually purge all fluid from the lines, but it may be a slow process.
Page 131: Replacing An Ink Or Cleaner Fluid Bottle
BLADE II SAW: MAINTENANCE Figure 7-29: Printer Parts Diagram Connection to Purge Valve Control Unit (white) Cleaner Fluid Connector Printout Activator (yellow, 16 & 32 valve heads only) Bracket Ink Connector (black) Mounting Bracket Print Target Nozzles Guide Plate Print Head...
Page 132: Preparing The Printer For Extended Shutdown Of Over 48 Hours
BLADE II SAW: MAINTENANCE Figure 7-30: Ink Bottle Location Ink Bottle Holder 11. Purge the line so all air is pushed out. See Manually Purging Ink or Cleaner From Lines. 12. Ensure the valve is in ink position for printing.
Page 133: Setting The Air Pressure
BLADE II SAW: MAINTENANCE 2. Clean nozzles as described on Cleaning the Printer. 3. Begin operation. Setting the Air Pressure The pump that affects the printer system’s pressure can be access via the stroke / elevation door (outfeed). It must be set to no higher than 12 psi. Exceeding this recommended setting will damage the print heads The printer’s pneumatic system has a non-adjustable relief valve set at 15 psi next...
Page 134: Grease Recommended
A thin film of grease should be visible on the guide rails at all times Because the linear bearings require frequent lubrication and can be damaged by overgreasing, MiTek recommends the following grease and grease gun be used. Grease Recommended Mobilux™ EP 2...
Page 135: Location And Number
BLADE II SAW: MAINTENANCE Location and Number Table 7-10: Assemblies Lubricated by Linear Guide Bearings Lubricated Assembly Qty. Graphic Figure 7-32 Infeed Rail Gripper Figure 7-33 Top Clamp Figure 7-33 Infeed Side Clamp Figure 7-34 Stroke Figure 7-34 Elevation Figure 7-35...
Page 136 BLADE II SAW: MAINTENANCE Figure 7-34: Stroke and Elevation Bearing Locations Stroke / Evelation Door (Infeed End) Figure 7-35: Outfeed Clamp Bearing Locations Outfeed Side Original Instructions: 001132 rev. A...
Page 137: Lasm Linear Module
BLADE II SAW: MAINTENANCE LASM Linear Module The LASM linear module should be lubricated every 24 months (one shift) or every 12 months (two shifts). Use a grease gun to apply 2.8 cm of grease to the Manual grease fitting shown in Figure 7-36.
Page 138: Lumber Exit Chain Bearings
BLADE II SAW: MAINTENANCE Figure 7-37: Outfeed Cam Followers Location Grease Fitting Washer Follower Lumber Exit Chain Lumber Exit Chain Bearings Apply a #2 lithium-based grease to the idle-end bearings once every 12 months (1 shift) or every 6 months (2 shifts).
Page 139: Waste Conveyor Drive Shaft
BLADE II SAW: MAINTENANCE Waste Conveyor Drive Shaft Lubricate the waste conveyor bearings with #2 Lithium-based grease once a year. There is 1 grease fitting on each end of the drive shaft. Figure 7-39: Waste Conveyor Drive Shaft Grease Fitting Location...
Page 140: Auto Deck Drive Shaft (Infeed Component)
BLADE II SAW: MAINTENANCE Auto Deck Drive Shaft (Infeed Component) Apply #2 lithium-based grease to the grease fittings on the Auto Deck shaft bearings every 12 months (1 shift) or 6 months (2 shifts). There is 1 fitting for each Auto Deck strand and there are 5-6 strands total depending on Auto Deck length.
Page 141: Replacing Wheels
BLADE II SAW: MAINTENANCE non-powered wheels that guide the belt require no lubrication. The conveyor rollers and skatewheels on the Skewed Conveyor require no lubrication. Figure 7-41: Drive Wheel Grease Fitting Locations 2 More Grease Fittings on Other Side Replacing Wheels...
Page 142: Auto Deck Chain
BLADE II SAW: MAINTENANCE Auto Deck Chain Remove yellow guard to access chain and sprocket. Lightly lubricate each chain every 12 months. Figure 7-42: Auto Deck Chain Lubrication Point Skewed Conveyor Chain Remove yellow guard to access chain and sprocket. Lightly lubricate the chain every 2 months.
Page 143: Lumber Exit Chain Tension
BLADE II SAW: MAINTENANCE Lumber Exit Chain Tension Loosen the 4 securing bolts and then tighten or loosen the tensioning bolts (see Figure 7-44) to adjust the chain tension. Once the chain has been tensioned, tighten the securing bolts. Figure 7-44: Lumber Exit Chain Tensioner Mechanism...
Page 144: Auto Deck Chain Tension
BLADE II SAW: MAINTENANCE a) Loosen the 2 bolts called out in Figure 7-45. b) Push or pull on the lumber exit chain assembly to align as described previously. c) Tighten the 2 bolts called out in Figure 7-45. Figure 7-45: Lumber Exit Chain Positioning Bolts...
Page 145: Belts
BLADE II SAW: MAINTENANCE Belts Gripper Adjusting Gripper Belt Tension 1. Loosen the 4 bolts clamping the belt tensioner bracket to the frame. Figure 7-47: Gripper Belt Tensioner Bracket Clamping Bolts Tension Bolt End of Infeed Rail 2. Back off the jam nut and turn the tension bolt to wedge bracket out until the belt is tight.
Page 146: Stroke Axis
BLADE II SAW: MAINTENANCE 4. Repeat this process until the belt stays where it was placed on the shaft. Stroke Axis Adjusting Stroke Belt Tension The stroke assembly is attached to a cogged belt called a timing belt. To adjust the tension of stroke timing belt, follow this procedure: 1.
Page 147: Adjusting Waste Conveyor Belt Tracking
BLADE II SAW: MAINTENANCE Figure 7-49: Waste Conveyor Belt Tension Bolt 2 1/2" 2. Start with the tension bolt at approximately 2-1/2”. 3. Adjust as needed so the belt runs smoothly. Adjusting Waste Conveyor Belt Tracking With extended use or belt replacement, the belt tracking may need adjustment.
Page 148: Skewed Conveyor
BLADE II SAW: MAINTENANCE Skewed Conveyor Adjusting Skewed Conveyor Belt Tension The Skewed Conveyor belt is driven by 2 drive wheels, both powered by the same motor. The belt should be tensioned so it moves easily and smoothly without much slack. To adjust the tension, follow this procedure: 1.
Page 149: Wear Items
BLADE II SAW: MAINTENANCE Wear Items Bumpers Bumpers are used on the following axes to reduce stress on mechanical parts when stopping at the end of their range: • Stroke / Elevation • Gripper • LASM Bumpers should be replaced if they appear cracked or significantly worn.
Page 150: Brushes
BLADE II SAW: MAINTENANCE Figure 7-53: Gripper Bumpers A second bumper is located on the opposite side of the infeed rail Infeed Rail (Rear Side) Figure 7-54: LASM Bumpers A second bumper is located on the opposite side of the LASM rail...
Page 151: Replacing Brushes
BLADE II SAW: MAINTENANCE obstruction. The brushes should be inspected periodically and replaced when necessary. Figure 7-55: Brush Examples (Saw Chamber) Replacing Brushes 1. Remove bolts securing existing brush. Retain for re-installation. 2. Remove and discard existing brush. 3. Use bolts removed in step 1 to install the new brush.
Page 152: Lasm Spikes
BLADE II SAW: MAINTENANCE LASM Spikes Spikes (socket-head cap screws) are Figure 7-57: LASM Spike Depth assembled into the carriage side of the LASM 1/8" jaw to hold the board in place. When spikes become dull or damaged, unscrew each spike and replace each with a new spike, ensuring the spike extends 1/8"...
Page 153 BLADE II SAW: MAINTENANCE Figure 7-58: Accessing Taper Liner for Replacement and Tape Placement Alignment Strips 68 1/4" Seal Plate Brackets Stroke Brush Clamp 8 1/4" Seal Plate Clamp Stroke / Elevation Door (Infeed End) 1. Remove the alignment strips securing the seal plate on each side.
Page 154: Shock Absorbers
BLADE II SAW: MAINTENANCE 6. Remove the existing tape liner (4 pieces total). 7. Thoroughly clean the surface with a damp cloth. • Failure to clear the surface may prevent the new tape liner from adhering securely to the frame.
Page 155: Adjusting A Shock Absorber
BLADE II SAW: MAINTENANCE Table 7-12: Shock Absorber Overview Piston Location Graphic Distance points... Top Clamp: Top 1/2” from bottom surface of bracket Figure 7-59 Down (retract) to end of shock absorber body. Top Clamp: Bot- 1/2” from top surface of bracket to...
Page 156 BLADE II SAW: MAINTENANCE Figure 7-61: Adjusting Outfeed Clamp Shock Absorber 1. Loosen jam nut 2. Screw body in or out 3. Tighten jam nut Original Instructions: 001132 rev. A...
Page 157: Pneumatic System
BLADE II SAW: MAINTENANCE Pneumatic System CAUTION HIGH PRESSURE HAZARD. Bleed all pressure from pneumatic lines before performing maintenance on pneumatic components. Pressurized components may move suddenly or vent air to atmosphere, causing injury. The pneumatic system controls all of the components listed in Table 7-13.
Page 158: Removing Pressure From The Pneumatic System
2. Lockout/tagout through the hole on the slide. See Figure 1-4 on page 10 for example. Maintaining the Filter / Regulator Purchasing a Filter / Regulator The filter/regulator can be purchased directly from MiTek. Refer to the Ordering Parts appendix for instructions on ordering parts.
Page 159: Replacing A Filter Element On A Filter / Regulator
Replacing a Filter Element on a Filter / Regulator The regulator uses a filter that must be replaced every 6 months. This filter can be purchased through MiTek. Refer to the Ordering Parts on page 192 instructions on ordering parts. Use the following procedure to replace a filter element.
Page 160: Adjusting The Main Pressure Sensor
BLADE II SAW: MAINTENANCE 3. Unscrew the black plastic baffle holding the filter element and remove it from the regulator. Figure 7-64: Filter Element with Bowl Removed 4. Replace the filter element. Screw the black plastic baffle back into place.
Page 161: Air Knives
BLADE II SAW: MAINTENANCE Figure 7-65: Pressure Sensor Adjustment on Main Filter/Regulator Assembly Air Knives This machine utilizes multiple air-knives to manage sawdust. For optimal performance, the air-knife must supply only dry air. If droplets of water are being ejected from the air-knife. the external pneumatic system that supplies air pressure to the machine may require adjustment or maintenance.
Page 162: Clamps
BLADE II SAW: MAINTENANCE Figure 7-66: Example of Cabinet Cooler and Paired Thermostat (left to right) Clamps Raising the Top Clamp For ease of maintenance, the containing top clamp (infeed side) can be raised and locked into place when the saw is not operating. To raise and lock the assembly: 1.
Page 163: Adjusting The Outfeed Clamp
BLADE II SAW: MAINTENANCE Adjusting the Outfeed Clamp The outfeed clamp camfollowers must be parallel to the lumber exit chain at all times. 1. Mechanically adjust the clamp location using these steps. Steps for adjusting in smaller increments occur in the next step.
Page 164: Cylinders
Figure 7-61. Cylinders The BLADE II Saw utilizes pneumatic cylinders for Infeed Rail load arms and various clamps throughout the machine. Observe the operation of pneumatic systems every 3 months and adjust as needed. Adjusting Flow Control Valves Both ends of some cylinders have flow control valves to adjust how fast the cylinders extend and retract.
Page 165 BLADE II SAW: MAINTENANCE Figure 7-70: Rod-End and Cap-End Flow Control Valves Rod end Cap end Original Instructions: 001132 rev. A...
Page 166: Electrical System
BLADE II SAW: MAINTENANCE Electrical System Sensors Overview A complete list of sensors is found in Table 7-15. They are arranged in approximate order from the infeed to outfeed side of the machine (facing the machine). Photos are shown on subsequent pages.
Page 167 BLADE II SAW: MAINTENANCE Sensor Name Description See... LASM Lockout Prevents saw blade from moving when LASM is Figure 7-73 within sensor’s vision. Located on the stationary portion of the LASM assembly at the centerline of the saw blade. When LASM block is within the sensor’s vision, the saw blade will...
Page 168 BLADE II SAW: MAINTENANCE Figure 7-71: Infeed Rail Sensors Leading Edge Leading Edge Gripper Home Receiver (L) and Emmiter (R) Receiver (L) an Emmiter (R) Board Sensor Board S Senso Rear View Rear View Gripper Unclamped per Unclamped Load Arm Up...
Page 169 BLADE II SAW: MAINTENANCE Figure 7-72: Stroke/Elevation Chamber and Infeed Clamp Sensors Top Clamp Clamped / Unclamped (top to bottom) Side Clamp Unclamped mped mped Top Clamp Ski Stroke Home Angle Home Home Elevation Home Home Home Original Instructions: 001132 rev. A...
Page 170 BLADE II SAW: MAINTENANCE Figure 7-73: Saw Chamber and Outfeed Sensors Bevel Home Beve Outfeed Clamped / Unclamped (left to right) (under LASM clamp) LASM Sensors (see next page) LASM Lockout LASM Home Original Instructions: 001132 rev. A...
Page 171: Sensor Maintenance
BLADE II SAW: MAINTENANCE Figure 7-74: LASM Clamp Sensors Clamped (Extend) Measurements indicate correct sensor placment LED light is on when sensor is active Unclamped (Extend) LED light is on when sensor is active Figure 7-75: Auto Deck Sensors (Optional)
Page 172: Troubleshooting Home Sensors
BLADE II SAW: MAINTENANCE approximately 1/32". Troubleshooting Home Sensors See following procedures for instructions on troubleshooting home sensors. Checking Inspection Points 1. Check for obstructions interfering with the sensor. 2. Ensure all prox switches have 1/32" air gap. 3. Ensure dust and debris is not in the way of the sensor or target.
Page 173: Adjusting & Troubleshooting The Crooked Lumber Sensor
BLADE II SAW: MAINTENANCE 2) On the Detailed Diagnostics screen, the indicator next to the Home Sensor field should turn blue while the metal object is detected. If it does not, there is a communication issue. 2. For other sensors (not inductive proximity switches): a) From the touch screen on the operator interface, select Diagnostics >...
Page 174 BLADE II SAW: MAINTENANCE 3. Calibrate the CLS. a) Go to Tools > Calibrate from the operator interface. b) Follow the on-screen instructions and select Make Alignment Cut. 4. Lockout/tagout. 5. Drop a plumb bob over the board and down just above the bubble level.
Page 175 BLADE II SAW: MAINTENANCE Figure 7-77: Diagnostics > Detailed Diagnostics > CLS Screen Testing the Elevation and CLS Communication 1. Place a 2x4x6 or longer on the Infeed Rail and slide it into the saw chamber while still holding onto the end sticking out of the saw chamber.
Page 176: Adjust Photo Eye Sensors
Do not modify any parameters on any VFDs unless instructed by Automation Support A VFD is an important part of several electrical circuits in the BLADE II Saw. Verifying the voltage in and out of the VFD is always a good first step in the electrical troubleshooting process.
Page 177 BLADE II SAW: MAINTENANCE Figure 7-79: Electrical Enclosure (Left Side) Safety Controller VFD Keypads V-Links (1 per Printhead) Print Controller Original Instructions: 001132 rev. A...
Page 178 BLADE II SAW: MAINTENANCE Figure 7-80: Electrical Enclosure (Right Side) Safety Motion Relay Outfeed Chain Motor (ACS 380 VFD) Saw Motor (ACS 880 VFD) Servomotors Waste Conveyor Motor (ACS 380 VFD) Original Instructions: 001132 rev. A...
Page 179: Select Component Overview And Maintenance
The Skewed Conveyor is one of the outfeed components that can be paired with the BLADE II Saw. It is a powered conveyor that drives the lumber away from the outfeed side of the machine to be offloaded or directed onto other conveyors.
Page 180: Aligning The Skewed Conveyor
BLADE II SAW: MAINTENANCE Aligning the Skewed Conveyor The side skatewheel fence and lumber guide assembly must be parallel with each other. The gap should allow the exiting lumber to travel freely without rubbing hard on either side. 1. A properly aligned skewed conveyor should meet the following criteria: •...
Page 181 BLADE II SAW: MAINTENANCE Figure 7-82: Cam Follower Replacement Washer Follower b) Catch the cam follower (with grease fitting attached) as it falls out when the nut is removed. Repeat for all cam followers. 2. Install cam followers into the new outfeed clamp assembly: a) Using the same hardware, place a washer over a cam follower shaft.
Page 182: Troubleshooting
CHAPTER 8 ROUBLESHOOTING Navigating the Troubleshooting Appendix The troubleshooting appendix is divided into tables according to system of the BLADE II Saw that is experiencing problems. See Table 8-1 for a list of systems. Table 8-1: Troubleshooting by System System Page...
Page 183: Getting Started With Troubleshooting
BLADE II SAW: TROUBLESHOOTING Getting Started with Troubleshooting Safety Notes for Troubleshooting Read the safety section starting on page 1. The safety test procedures in the safety section MUST be performed by qualified personnel after ANY maintenance, adjustment, or modification. Note these safety reminders:...
Page 184: Tools Required
When the toolbox shown in the margin appears, you should gather the tools listed below it before beginning the procedure next to which it appears. Before beginning the troubleshooting process or calling MiTek Machinery Division Customer Service, gather the following tools: •...
Page 185: First Steps
2. Vacuum and dust the electrical enclosure. 3. Remove the lockout/tagout equipment and attempt to run the BLADE II Saw again. If that did not solve the problem, proceed with the next step. 4. Adhere to all regulations and guidelines given in NFPA 70e and in your company’s energy control program.
Page 186: Mechanical Problems And Solutions
BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Mechanical Problems and Solutions Problem Possible cause Possible solution Page An axis is not moving Accumulation of dust and Clean equipment at intervals debris, machine not cleaned recommended in maintenance...
Page 187 BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Problem Possible cause Possible solution Page The last part of my board is The main regulator is not set to Set the main regulator to 110 always short but the blade was...
Page 188 BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Problem Possible cause Possible solution Page My parts are off roughly 3/8 of The belt has jumped a cog on Calibrate the gripper. an inch consistently. the pulley.
Page 189 BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Problem Possible cause Possible solution Page Receiving home Z pulse errors. Calibration needed Calibrate the gripper. Gripper motor coupling is loose Check torque values for gripper motor Gripper belt tension...
Page 190 BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Problem Possible cause Possible solution Page Auto Deck not advancing the Sensor issue Adjust the location of the Auto board correctly onto the load Deck Board sensor. arms...
Page 191: Pneumatic Problems And Solutions
BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Pneumatic Problems and Solutions Problem Possible cause Possible solution Page My saw keeps shutting off The main regulator is not set to Set the main regulator to 110...
Page 192 BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Problem Possible cause Possible solution Page No printout or poor printout Tubing issue Ensure hose from ink bottle is quality but clicking sound is connected and ink bottle is full.
Page 193: Electrical And Software Problems And Solutions
BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Electrical and Software Problems and Solutions Problem Possible cause Possible solution Page Sensor faults Faulty writing, loose Check for faulty wiring and connections make certain all connections are secure...
Page 194 BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Problem Possible cause Possible solution Page Saw is in Waiting for Printer Software issue Select Abort Cutting Trigger state. Sequence on the Diagnostics ribbon. Do NOT adjust trigger status in Detailed Diagnostics—it will cause the...
Page 195 BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Problem Possible cause Possible solution Page CLS not working Miscellaneous Check that the housing and bracket are in good condition to protect the CLS and keep it in place.
Page 196 BLADE II SAW: TROUBLESHOOTING Should you lockout/tagout to perform this action safely? Problem Possible cause Possible solution Page 1. Before the next board is Software indicates that the Gripper home position issue run during a job, measure stock lumber is too short, but I...
Page 197: Maintenance Checklist
CHAPTER 9 AINTENANCE HECKLIST Using the Maintenance Checklists Copy these checklists and place the copies with the BLADE II Saw. Leave the original checklists in this manual for future use. Checklist Daily Checklist on page 188 Weekly Checklist on page 189...
Page 198: Daily Checklist
BLADE II SAW: MAINTENANCE CHECKLIST Should you lockout/tagout to perform this action safely? Daily Checklist WARNING Month and year __________ Lockout/tagout before performing maintenance. If power is required, make sure all personnel are clear of Week of __________ the restricted zone.
Page 199: Weekly Checklist
BLADE II SAW: MAINTENANCE CHECKLIST Should you lockout/tagout to perform this action safely? Weekly Checklist WARNING Year __________ Lockout/tagout before performing maintenance. If power is required, make sure all personnel are clear of the restricted zone. Action Page Initials / Date...
Page 200: Monthly / Annual Checklist
BLADE II SAW: MAINTENANCE CHECKLIST Should you lockout/tagout to perform this action safely? Monthly / Annual Checklist WARNING Lockout/tagout before performing maintenance. Year __________ If power is required, make sure all personnel are clear of the restricted zone. Action Months...
Page 201 BLADE II SAW: MAINTENANCE CHECKLIST Should you lockout/tagout to perform this action safely? Action Months Months Page Initials / Date (one shift) (two shifts) Check for leaks in all bearings, gearboxes, and motors Inspect all sprockets, replacing any that do not rotate easily.
Page 202: Ordering Parts
CHAPTER 10 RDERING ARTS Ordering Parts Use the MiTek web site to locate parts and part numbers, then order them using one of these methods: By E-Mail By Phone Send an e-mail to mitekparts@mii.com with all Call relevant information, 1-800-523-3380.
Page 203: Drawing Set
CHAPTER 11 RAWING Drawings are inserted in the back of the manual or included in a separate binder, depending on the machine. Description Drawing Number Mechanical Top Level Assembly 76100-501 Saw Assembly 76101-501 Guards and Covers Assembly 76102-501 Stroke and Elevation Chamber Brush Seal 76115-501 LASM Assembly 76160-501...
Page 204 BLADE II SAW: PARTS LIST Description Drawing Number Auto Deck Schematic (optional) 90626 Auto Deck Electrical Assembly (optional) 90626-501 Auto Deck Electrical Enclosure (optional) 90626-502 Pneumatic Assembly 76346-501 Top and Side Clamp Assembly 76350-501 Outfeed Clamp Assembly 76440-501 Printer (multiple options)
Page 205: Glossary
LOSSARY affected employee an employee whose job requires him or her to operate or use a machine or equipment on which servicing or maintenance is being performed under lockout or tagout, or whose job requires him or her to work in an area in which such servicing or maintenance is being performed angle the axis that rotates the saw blade...
Page 206 BLADE II SAW: GLOSSARY energized connected to an energy source or containing residual or stored energy energy isolating device a mechanical device that physically prevents the transmission or release of energy, including but not limited to the following: manually operated electrical circuit breaker;...
Page 207 BLADE II SAW: GLOSSARY lockout/tagout a means of isolating a piece of equipment from its energy source so maintenance can safely occur; guidelines provided in OSHA 29 CFR 1910.147 lumber A group of boards or a non-specific board; no consideration...
Page 208 BLADE II SAW: GLOSSARY side clamp roller clamp on infeed side of saw that contacts the face of the lumber Skewed Conveyor powered skewed conveyor that integrates with the system to transport and sort the lumber solenoid an assembly used as a switch consisting of a coil and a...
Page 209: Index
NDEX safety sensors adjusting system pressure see FRL e-mail support see customer service emergency stop see E-stop errors air pressure E-stop bevel sensors flow control valves see pneumatic sys- calibrating crooked lumber sensor adjusting pressure chains replacing filter element adjusting tension checklists daily checklist maintenance...
Page 210 BLADE II SAW: INDEX maintenance replacement parts see parts list checklists restricted zone Manual return goods navigation manual introduction understanding safety marking restricted zone during troubleshooting monitor general rules second monitor indicators specs lockout/tagout marking restricted zone restricted zone safety test...
Page 211 BLADE II SAW: INDEX powered skewed conveyor Original Instructions: 001132 rev. A...

Mitek BLADE II Operation And Maintenance Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitek BLADE II

Summary of Contents for Mitek BLADE II

Table of Contents
