  • Page 1 550-867 Additional Instructions Fingerprint scanner...
  • Page 2 IMPORTANT READ CAREFULLY BEFORE USE KEEP FOR FUTURE REFERENCE All rights reserved. Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents, including extracts, is prohibited without the prior written approval of Dürkopp Adler AG. Copyright © Dürkopp Adler AG 2019...

  • Page 3: Table Of Contents

    Setting up the USB port .............. 11 Activating the fingerprint scanner ..........13 Operation................... 15 Creating a new user using fingerprint detection ......15 Logging in using the fingerprint scanner........21 Deactivating the fingerprint scanner ........23 Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 4 Table of Contents Additional Instructions 550-867 - 01.0 - 02/2019...

  • Page 5: General Information

    General information General information Machines of the 550-867 class can be retrofitted with a fingerprint scanner. Users will then have 3 different options to log into the system. • using a hand scanner and barcode • via software • using the fingerprint scanner...

  • Page 6: Setting Up The Fingerprint Scanner

    Fig. 2: Determining the software version (1) To determine which software version has been installed: 1. Tap on the machine name 550-867 XE6 at the top right corner of the start screen.  The display switches to:...

  • Page 7: Updating The Software

    The latest software version has been included on the USB key. To update the software on the control panel: 1. Switch on the machine ( Operating Instructions). 2. Log in with security level 2.  The display switches to: Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 8 The program must not be open while the software is being updated.  The control panel shows the Windows user interface. 5. Connect the USB key at the control panel. Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 9  Unless renamed previously, the old file Options will now be replaced by the new file Options . Important The NEW software MUST be named Options for the fingerprint scanner to work. Do not change the entries in the Options.txt file. Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 10 3 Messages files. 17. Close all windows. 18. Restart the program of the machine with a double click.  The software has been updated. You can now connect the fingerprint scanner ( p. 9). Additional Instructions 550-867 - 01.0 - 02/2019...

  • Page 11: Connecting The Fingerprint Scanner

    4. Set up the USB port ( p. 11). 5. Activate the fingerprint scanner ( p. 13). Fig. 6: Connecting the fingerprint scanner (1) ① ② ③ (1) - Cable opening (3) - Fingerprint scanner (2) - Connecting cable Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 12 The control box (4) can only be accessed behind the engineered workstation located under the tabletop. 4. Switch on the machine ( Operating Instructions and  Service Instructions). Fig. 8: Connecting the fingerprint scanner (3) ⑤ (5) - USB plug Additional Instructions 550-867 - 01.0 - 02/2019...

  • Page 13: Setting Up The Usb Port

     The Windows user interface appears. 4. Click on the Windows Start button. 5. Select the following path from the options shown to the right of the Start menu: Settings > Devices > Device Manager > Ports (Com&LPT) Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 14  The USB port for use with the fingerprint scanner has now been set up as COM19 in the system. 16. Close the window. 17. Switch off the machine. 18. Switch on the machine.  The settings are saved. Additional Instructions 550-867 - 01.0 - 02/2019...

  • Page 15: Activating The Fingerprint Scanner

    Fig. 10: Activating the fingerprint scanner (1) 2. Tap the Check button on the start screen.  The display switches to: Fig. 11: Activating the fingerprint scanner (2) 3. Tap the Setup button.  The display switches to: Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 16 4. Check the box for the component Finger Print Sensor. 5. Confirm with OK.  The fingerprint scanner has been activated. Information If the fingerprint scanner is not immediately active, tap the Restart button to restart the control panel. Additional Instructions 550-867 - 01.0 - 02/2019...

  • Page 17: Operation

    2. Tap the Access button on the start screen.  The display switches to: Fig. 14: Creating a new user using fingerprint detection (2) 3. Tap the New button.  The display switches to: Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 18 The fingerprint must be immediately linked to a user profile as it cannot be added later once the user has been set up. 7. Tap the FingerPrnt button.  The display switches to: Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 19 Information A LONG press on the access button until the button flashes and lights up permanently will start the login procedure using the hand scanner.  The display switches to: Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 20 (3) - Fingerprint scanner 11. Place your finger tip on the fingerprint sensor (2) for approximately 3 seconds.  The display switches to: Fig. 20: Creating a new user using fingerprint detection (8) Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 21  After 3 successful scans, the display will switch to: Fig. 22: Creating a new user using fingerprint detection (10) 16. Confirm with OK.  An Identity number will appear automatically in the input field of the same name. Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 22 Fig. 23: Creating a new user using fingerprint detection (11) 17. Confirm with OK.  The information for the new user is saved. 18. Tap the Save button.  The new user has been created using fingerprint detection. Additional Instructions 550-867 - 01.0 - 02/2019...

  • Page 23: Logging In Using The Fingerprint Scanner

     The access button (1) flashes once before lighting up green permanently, indicating that the login procedures has started. Information If pressing the access button too long, you will start the login procedure for the hand scanner rather than the fingerprint scanner. Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 24 If the fingerprint is not recognized because it is unknown or was captured only partially, a corresponding error message will be displayed. If a user is logged in, they will be logged out automatically. Repeat the login procedure. Additional Instructions 550-867 - 01.0 - 02/2019...

  • Page 25: Deactivating The Fingerprint Scanner

    Fig. 26: Deactivating the fingerprint scanner (1) 2. Tap the Check button on the start screen.  The display switches to: Fig. 27: Deactivating the fingerprint scanner (2) 3. Tap the Setup button.  The display switches to: Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 26 Deactivating the fingerprint scanner Fig. 28: Deactivating the fingerprint scanner (3) 4. Deselect the check box for the component Finger Print Sensor. 5. Confirm with OK.  The fingerprint scanner has been deactivated. Additional Instructions 550-867 - 01.0 - 02/2019...
  • Page 28 DÜRKOPP ADLER AG Potsdamer Str. 190 33719 Bielefeld Germany Phone: +49 (0) 521 925 00 Email: service@duerkopp-adler.com www.duerkopp-adler.com...
