First 7
Car-seat Manual

Advertisement

Table of Contents
loading

Related Manuals for DAIICHI First7

Summary of Contents for DAIICHI First7

  • Page 1 First 7 Car-seat Manual...
  • Page 3 First 7 Car-seat Manual...

  • Page 4: Table Of Contents

    Table of contents For safe use About Indicative Marks Conditions of children, who can use this product Before installing safety seat in your car 2 ~ 5 Seats that can install the safety seat Seats that cannot install the safety seat Types of seatbelts for installation Deciding direction of safety seat 4 ~ 5...

  • Page 5: For Safe Use

    For safe use This product is safety equipment for children used in cars, which will reduce shocks to children in case of accidents. However, it cannot perfectly (100%) save children from some cases, so please drive safely to not to cause any accident.

  • Page 6: Before Installing Safety Seat In Your Car 2

    Before installing the seat in your car Seats that can install the safety seat For more detailed installing method, please refer to method for each mode. Rear seat Front seat (arrow shows the driving direction) (arrow shows the driving direction) Rear facing Forward facing Rear facing...

  • Page 7: Types Of Seatbelts For Installation

    Types of seatbelts for installation ☆ First of all, please check the type of seat belt in the car. Please use it only for 3-point seat belt that is approved by ECE NO16 or same regulation. This safety seat cannot be equipped with 2-point seat belt. Possibility Classification Special features...

  • Page 8: Notes 4

    Caution The user manual needs to be kept well and read accordingly when necessary. Danger The infant safety seat needs to be attached according to the user The product should not be used for manual. If the seat is attached the seats with an airbag.
  • Page 9 Warning When the infant safety seat is installed While driving, you should not operate on the passenger’s seat, it may cause the infant safety seat(Belt adjustment some interference, leading to inconve /Angle adjustment, for example). nience in operating the transmission The car should be parked in a safe gear or the side brake.

  • Page 10: Name Of Each Part

    Name of each part Front of safety seat Shoulder belt holes ( 4 levels ) Head seat Shoulder pad Fastening plate buckle Seat cover Shoulder belt Belt length adjusting lever Base Angle adjusting lever Rear facing lever Accessories ☆ Design of the inner seat can be different according to types of models. Manual Head inner seat Inner seat...
  • Page 11 Back of safety seat Belt guide ( for rear facing only ) Belt cover Sun visor ratch frame Belt locking lever When taking off the belt cover ( For both directions ) Shoulder belt hanger Belt path Shoulder belt hanger is required when the height of shoulder belt is adjusted.

  • Page 12: Adjustment Method

    Adjustment method Please stop the car to adjust each function. Warning Adjusting the safety seat during driving will interrupt your driving and might cause accidents. How to adjust angle Forward facing You can adjust angles in 4 different levels. For forward facing, use levels 1~3 and level 4 is only for facing to rear.

  • Page 13: How To Adjust Shoulder Belt

    How to adjust shoulder belt Please stop the car to adjust each function. Warning Adjusting the safety seat during driving will interrupt your driving and might cause accidents. Shoulder belt hanger Belt cover Take off the belt cover at the back of main body to pull out the shoulder belt from its hanger. When you cannot see the shoulder belt hanger, pull out the front belt Caution so shoulder belt hanger at the back can come out to front to adjust height of belt.

  • Page 14: How To Use Buckle

    How to use buckle Danger Using the safety seat without buckle is very dangerous, so do not use the seat after unfastening buckle. Unfastening Fastening plate Buckle Click Fastening plate Press button Button cover Press the press button inside buckle Separate joined fastening plate into upper of button cover to take off fastening plate.

  • Page 15: How To Use Locking Lever

    How to use locking lever Locking lever is an equipment to securely install the child safety seat into your car. Please use it. You will find 2 locking levers, one on each side of the main body. Please use it according to location of installment. locking lever Locking lever and belt guide are equipments for secure installment of child safety seat with car’s seat Danger...

  • Page 16: How To Adjust Height Of Headrest

    How to adjust height of headrest Using the safety seat without the buckle is very dangerous, so do not use the seat after unfastening Danger the buckle. Pull up adjusting lever in the middle of backside of headrest to adjust height (up and down). Headrest can be adjusted in 7 different levels.

  • Page 17: How To Use Baby Mode 13

    First 7 How to use BABY MODE Baby Mode is designed for children aged 0 to 1 with maximum weight of 13kg.

  • Page 18: Angle Adjustment Of Back Support At Baby Mode

    How to Use Baby Mode Angle adjustment of back support at Baby Mode Forward facing Rear facing Lay down the main body of the seat to level 4 (lowest level). Pull out rear facing lever Set the child safety seat to angle of level 4, To check the right angle, (angle adjusting lever)

  • Page 19: Height Adjustment Of Headrest At Baby Mode

    Height adjustment of headrest at Baby Mode Caution Headrest should have a room of 3 cm higher from top of the baby. Pull up adjusting lever in the middle Lower part of headrest should be in the of backside of headrest to adjust height closest location from baby’s shoulder.

  • Page 20: How To Install Baby Mode ( Forward Facing / Front Installment ) 16

    How to install Baby Mode ( Rear facing/rear installment ) According to types of car’s seat belt, installment and fixing methods vary. Please refer to check possible Danger and impossible seats for installment on p. 3 and then install child safety seat in a right way. For ELR/ALR 3-point safety belt, switch to ALR function after installment.
  • Page 21 Shoulder belt of car Push the safety seat to contact the back of seat and then pull out the car’s seat belt. Belt path Then, let the pulled out belt and fastening plate of the belt to pass through belt path in the backside of main body. Caution Be careful not to twist the car’s seat belt.

  • Page 22: Checklist For Baby Mode

    Firstly, make sure whether shoulder belt of car is properly inserted into the locking lever. Put your weight to the safety seat, and then strongly pull the shoulder belt of car while pushing belt locking lever on side to fix it. Shoulder belt of car For double fixation, hang the fixed belt inside belt guide.

  • Page 23: How To Use Toddler Mode 19

    First 7 How to use TODDLER MODE Toddler mode is designed for children aged 1 to 4 with weight from 9 to 18kg.

  • Page 24: Angle Adjustment Of Back Support At Toddler Mode

    How to Use Toddler Mode Angle adjustment of back support at Toddler Mode Forward facing Rear facing Adjust the main body according For Toddler Mode, angle of safety seat should be adjusted Pull out the angle adjusting lever to seat’s angle of the car from level 1 to 3.

  • Page 25: How To Use Shoulder Pad At Toddler Mode 21

    How to use shoulder pad at Toddler Mode Caution Shoulder pad for toddler should be used for the toddler mode only (For 9kg or above and forward facing) Take off existing shoulder pad, put out shoulder belt from shoulder belt hanger of the backside. From back of the safety seat, put shoulder pad for toddler into shoulder belt hole.
  • Page 26 Shoulder belt will get through smoothly Advice if you push it gently with your thumb. Shoulder belt with the shoulder pad should Insert shoulder belt into shoulder pad for toddlers. be inserted into shoulder belt hole at the back of safety seat. Completed! Inner side Put shoulder belt into shoulder belt hanger.

  • Page 27: Height Adjustment Of Headrest At Toddler Mode

    Height adjustment of headrest at Toddler Mode Caution Headrest should have a room of 3 cm higher from top of the baby. Pull up adjusting lever in the middle Lower part of headrest should be of backside of headrest to adjust height in the closest location from baby’s shoulder.

  • Page 28: How To Install Toddler Mode ( Rear Facing / Rear Installment ) 24

    How to install Toddler Mode ( Forward facing /front installment ) ☆ With 3-point car’s seat belt, install the baby seat forward facing. Do not install in the seats with airbag. Danger Due to operation of the airbag you might lose your child’s life or seriously injured. When the baby seat is installed on side seat of driver, it might be difficult to change gears or side Warning break.
  • Page 29 Put the main body in same direction (forward facing) as driving. Belt Path Pull out car’s seat belt and then let it go through the belt path, which is located in the backside of the main body. Be careful not to twist the car’s seat belt. Caution Belt Path Belt Path...

  • Page 30: Checklist For Toddler Mode

    Push the locking lever located on the opposite side of fastening plate to open. Pull shoulder part of car’s seat belt to make it tight as much as possible and insert it into locking lever. Then, pull the lever to opposite direction and push to lock. (Make sure to put the belt inside the locking lever and then push the lever strongly, so it can hold the belt tightly.) Waist belt of car should be fastened up to the...

  • Page 31: How To Use Child Mode 27

    First 7 How to use CHILD MODE Child mode is designed for children aged 3 to 7 with weight from 15 to 25kg.

  • Page 32: Separation And Storage For Child Mode 28

    How to Use Child Mode Separation and storage for Child Mode ☆ To easily use child mode, First Seven will let you to safely store unused belt, buckle and pad inside the safety seat. Pull up the back lever of headrest to the maximum height.
  • Page 33 ☆ Taking off sponge (memory foam) might damage your safety seat, so please just look at different storage spaces as shown in the above diagram and put things under the sponge. This company does not take any responsibilities of sponge damage that is made during this process. Shoulder belt strap without buckle should be rolled up, and then tie it up with rubber band or string.
  • Page 34 Back part Front part of safety seat of safety seat Shoulder belt hanger should be fixed at the entry of shoulder belt at backside of the safety seat as shown above. Then, push belt adjustment belt in the front to pull it completely. Button cover and shoulder pad should be stored Store belt strap in the location shown above.

  • Page 35: How To Install Child Mode ( How To Use Seat Belt )

    How to install Child Mode ( How to use seat belt ) Pull the belt in diagonal direction to pass through underneath headrest and below armrest, Pull out car’s seat belt loosely as shown above. and then fasten it with buckle as shown above. Checklist for Child Mode ☆...

  • Page 36: Maintenance And Management 32

    Maintenance and management How to detach headrest Side levers located inside the seat As you pull out the lever of headrest, push right and left side levers located Pull out the headrest to the highest position. on the backside of safety seat at the same time in order to separate headrest.
  • Page 37 Belt cover Take off belt cover at the back of main body, and then take off shoulder belt from its hanger. Taken off belt should be pulled out from shoulder belt hole. Take out shoulder pad and fastening plate from shoulder belt. Shoulder belt [ Note ] If you cannot see shoulder belt hanger ☆...
  • Page 38 MEMO...
