Summary of Contents for DAIICHI D1002ISOFIX
- Page 3 Weight below 0kg ~ 11kg (Group0) New-born ~ 12months old Weight below 11kg ~ 18kg (Group1) 12months ~ 4years old...
- Page 4 Do not place a child seat rear-facing in the front seat of a vehicle with a passenger air bag uniess deactivated DEATH OR SERIOUS INJURY can occur...
- Page 7 Safe Keeping of Manual How to Use Side Cushion Keep the manual inside Side cushion is recommended for infants under a belt cover on a backside of the car seat. 6 months.Position the cushion to support a child's head from both sides.
-
Page 8: Name Of Parts
Name of parts Head Sheet Shoulder belt hole (4 stages) Shoulder pad Fastening plate buckle Seat cover Shoulder belt Belt length adjusting lever Upper base Angle adjusting lever (Lever to change to the rearward-facing) ISOFIX latch Belt cover ISOFIX top tether hook Belt Guide (For Rear-Facing Installation) Seat Angle Indicator... -
Page 9: How To Operate
How to operate Releasing Fastening plate Fastening plate Buckle Click Press button Button Cover Take out the fastening plate by pushing the Separate the fastening plate consisting of press button within the buckle of the front pad. 2 parts into the upper and lower units. Locking Fastening plate Fastening plate... - Page 10 How to use the angle adjusting lever Front viewing mode The angle can be adjusted in four stages, with the 1st ~ 3rd stages for the front viewing mode, and the 4th stage for the rear viewing mode. Rear viewing mode In case of the front viewing mode, the safety seat’s angle needs to be adjusted according to the angle of the car seat to which the safety seat will be fastened.
- Page 11 How to use the locking lever The locking lever is a device to attach the infant safety seat into the car firmly. It should be used. There are 2 locking levers, located at the right and left side individually. Use the product according to the attachment position.
- Page 12 Before being attached into the car How to seat an infant Each part needs to be adjusted to be suitable for the body of the infant before being attached into the car. Every time when an infant is seated, the adjusting belt should be pulled to seat the baby tightly. If the shoulder Danger belt can not function as originally designed, consequently, the infant may risk his or her life, or suffering critical damage.
- Page 13 * Note The shoulder strap comes in 2 positions upon the product shipment. Adjust the height of the shoulder strap depending on a child's sitting height. Adjustment Belt cover Shoulder belt hanger Belt cover...
-
Page 14: Headrest Adjustment
Headrest Adjustment * Note For easy operation, insert the shoulder strap through the hole on the backrest cover. The headrest and shoulder strap move together from the 2nd position of the backrest height. Adjustment 1. Pull the head adjustment lever forward on the back of the car seat to adjust up and down.The headrest can be adjusted to 4 positions. - Page 16 Adjust the height of the shoulder strap and headrest appropriately to infant's body. (See the shoulder strap and headrest adjustment on page 11 & 12.)
- Page 17 1. Slide the locking lever on the other end of the vehicle mounting plate sideway to unlock. 2. Insert the car shoulder strap through the locking lever and slide the lever to the opposite side to lock it while pulling the strap tightly. (Position the strap under the lever and push the lever all the way to securely hold the strap.)
- Page 18 slide the strap locking lever sideway and press down to fasten it while pulling the strap tightly using your body weight from above the car seat after checking if the car shoulder strap is properly inserted through the locking lever. Hang the car shoulder strap to the belt guide for dual fix of the strap initially fastened with the locking lever.
- Page 19 Group l 9kg~ 18kg Adjust the height of the shoulder strap and headrest appropriately to infant's body. (See the shoulder strap and headrest adjustment on page 11 & 12.)
- Page 20 1. Slide the locking lever on the other end of the vehicle mounting plate sideway to unlock. 2. Insert the car shoulder strap through the locking lever and slide the lever to the opposite side to lock it while pulling the strap tightly. (Position the strap under the lever and push the lever all the way to securely hold the strap.)
- Page 21 Check the car shoulder strap is properly inserted through the locking lever. If the car seat is shaking, slide the locking lever sideway and press down to lock it while pulling the strap tightly using your body weight from above the car seat.
- Page 22 Follow the direction conversely when covering the seat. Pull out the shoulder strap, and untie the elastic on the back of the head covering to remove. Belt guide Remove back covering by detaching velcro on the back of Spread the covering left and right to get around the covering.
- Page 23 * Shoulder pad for children is used for front-facing installation over 9kg. Detach existing shoulder pad. Pull out the shoulder strap through a shoulder strap adjusting gear on the back of the car seat. (See P.11) Pull out the shoulder strap from the shoulder pad. Front Back Outer...
-
Page 25: Isofix Installation
ISOFIX Installation (Optional) This device can be used in vehicles designed to fit ISOFIX. ISOFIX is an international standard fastener for child safety equipment installation for a vehicle that securely protects infants through the direct connection to the vehicle. How to Fasten & Release Bottom Latch Fasten Pull the stopper lever in the front edge of ISOFIX base of the car seat forward from the both sides, and then push the lever out of the ISOFIX base. - Page 26 ISOFIX Installation (Optional) Release Release the latch by pulling the car seat forward while pressing the latch lever on the opposite side of the fixed control lever. How to Connect Upper Tether * The mark in the picture on the left is located on the top edge of the rear seat backrest if the vehicle is designed to fit ISOFIX.
- Page 27 82-2 Wunjeong 4(sa)-gil, Paju-City, Gyeonggi-do, Korea (413-837) Tel. : +82-31-942-4324 Fax. : +82-31-942-4326...
