Summary of Contents for Aim MoTeC M400
- Page 1 MoTeC M400-M600-M800 ECU...
- Page 2 ECU data stream) values like RPM, engine load, throttle position (TPS), air and water temperatures, battery voltage, speed, gear, lambda value (air/fuel ratio) analog channels... All AIM loggers include – free of charge – Race Studio 2 software, a powerful tool to configure the system and analyze recorded data on your PC.
- Page 3 500Kbit for the 4th. 1.3 – Software check For MoTeC ECU to correctly communicate with AIM loggers it is necessary to configure it using MoTeC “ECU Manager” software “3.x” version and keeping the ECU connected and switched on. Here follows the correct procedure.
- Page 4 MoTeC M400-M600-M800 ECU Technical documentation Release 1.02 www.aim-sportline.com...
- Page 5 MoTeC M400-M600-M800 ECU Technical documentation Release 1.02 • Check Communications parameters following this path Tools/Options. • This window appears. • Select “Communication” layer and check that “CAN data rate” is set on “1 mbit (Default)”. www.aim-sportline.com...
- Page 6 MoTeC M400-M600-M800 ECU Technical documentation Release 1.02 Set CAN communication parameters following the path: Adjust / General Setup / Communications / CAN Setup. • This window appears. It is necessary to set “CAN 0 Data” and “CAN 0 Address” parameters (highlighted in the image here below).
- Page 7 MoTeC M400-M600-M800 ECU Technical documentation Release 1.02 • Select “CAN 0 Address” row and press “1”. This window appears: • Enter value “1520”. • Press “OK” and the software comes back to the previous window. • Close and save following this path: File/Close & Save”...
- Page 8 MoTeC communication cable after ECU configuration. 3 – Connecting MoTeC ECU with AIM logger Connection of MoTeC ECU with AIM logger can be done in two ways: directly or using a Deltron CAN connector (part number 716-0-0501 – following MoTeC documentation).
- Page 9 • connect AIM cable labelled CAN- to pin 4 of Deltron Connector connected to pin 24 of 26 pins “B” male connector; • connect AIM cable labelled GND to pin 1 of Deltron Connector connected to pin 5 of DB9 connector connected to pin 14 of 26 pins “B” male connector.
-
Page 10: Channel Name
4 – M400-M600-M800 ECU communication protocol Channels received by AIM loggers depend on the ECU firmware version. 4.1 – M800-M600-M400 communication protocol Channels received by AIM loggers connected to MoTeC M400-M600-M800 ECU with firmware version lower than 2.30S (select ECU Model M800-M600-M400) are: CHANNEL NAME... - Page 11 MoTeC M400-M600-M800 ECU Technical documentation Release 1.02 4.2 – M800-M600-M400-1M communication protocol Channels received by AIM loggers connected to MoTeC M400-M600-M800 ECU with firmware version 2.30S or higher (select ECU Model M800-M600-M400-1M) are: CHANNEL NAME FUNCTION ECU_1 M800_RPM ECU_2 M800_THROTPOS...
- Page 12 MoTeC M400-M600-M800 ECU Technical documentation Release 1.02 4.3 – M800-M600-M400-1M/500K_v3 communication protocol Channels received by AIM loggers connected to MoTeC M400-M600-M800 ECU with firmware version “3.x” (select ECU Model M800-M600-M400-1M_v3) are: CHANNEL NAME FUNCTION ECU_1 M800_RPM ECU_2 M800_THROTPOS Throttle position sensor...
