  • Page 1 MIL-STD-1553 Interface Module for Windows AIM GmbH Sasbacher Str. 2 79111 Freiburg, Germany Tel: +49-761-45229-0 Fax: +49-761-45229-33 sales@aim-online.com www.aim-online.com November 2012 V11.2x Rev. A...
  • Page 3 MIL-STD-1553 Getting Started Manual MIL-STD-1553 TEST AND SIMULATION INTERFACE MODULE API1553-1/2 (PCI Version) ACI1553-1/2 (cPCI Version) APX1553-1/2/4/DS (PCI-X Version) ACX1553-3U-1/2/4/DS (PXI Version) ACX1553-6U-4/8/DS (cPCI-X Version) AMC1553-1/2/4/T (PMC Version) ACP1553 (PCI Verson) ACC1553-3U (cPCI Version) ACC1553-6U (cPCI Version) APM1553 (PC-Card Version)
  • Page 4 Notice: The information that is provided in this document is believed to be accurate. No responsibility is assumed by AIM for its use. No license or rights are granted by implication in connection therewith. Specifications are subject to change without notice.
  • Page 5 P. Giesel Modified for BSP V09.10 New system driver installation description New firmware update description 09.1x-B February 2006 P. Giesel Changed AIM-USA to AIM in some pictures 09.2x-A June 2006 P. Giesel Modified for BSP V09.20 09.3x-A January 2007 P. Giesel Modified for BSP V09.30...
  • Page 6 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 7: Table Of Contents

    Removing Previously Installed Drivers and BSP ........... 20 3.3.1 Removing the Windows system driver and BSP ..........20 CONNECTING THE AIM MODULE TO THE BUS .......... 23 COMPILING AND RUNNING A SAMPLE PROJECT........27 NOTES ........................31 Acronyms and Abbreviations ................. 31...
  • Page 8 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 9: Introduction

    The current version of all BSPs is available from the DOWNLOAD AREA of the AIM website at http://www.aim-online.com. AIM is also a leading designer and manufacturer of other high performance test and simulation modules, data bus analyzer software and systems for MIL-STD-1553 A/B, AFDX/ARINC664, ARINC429, MIL-STD-1760 and CAN/ARINC825, PANAVIA Serial Link and Fibre Channel.

  • Page 10: How This Manual Is Organized

    1553 BSP installed. Section 4, CONNECTING THE AIM MODULE TO THE BUS, contains a description and diagrams of the different methods used to connect the AIM 1553 card to the 1553 bus. Section 5, COMPILING AND RUNNING A SAMPLE PROJECT, contains the procedure used to open, build, and run a sample project included in the BSP.

  • Page 11: General Documentation Conventions

    Section 1 – Introduction 1.3 General Documentation Conventions We use a number of different styles of text and layout in this document to help differentiate between the different kinds of information. Here are some examples of the styles we use and an explanation of what they mean: Italics - used as a placeholder for the actual name, filename, or version of the software in use...

  • Page 12: Applicable Documents

    Section 1 – Introduction 1.4 Applicable Documents AIM has developed several documents that may be used to aid the user with other aspects of the PCI 1553 bus interface card. These documents and a summary of their contents are listed...

  • Page 13: New Bsp And Hardware Installation Procedure

    These files are automatically loaded onto the system by installing the BSP software package. The software is available on DVD from AIM or via a download from AIM-Online. Appendix A contains instructions for obtaining the BSP via a download from AIM-Online.
  • Page 14 Section 2 – New BSP and hardware installation procedure  To install the BSP software from the AIM provided CD or a download from AIM-Online If using the AIM provided DVD, insert the DVD into the DVD ROM drive. The Setup Application will automatically start after a few seconds.
  • Page 15 Programs | AIM GmbH | PCI-1553-Windows-BSP-Vxxxx: The BSP installation will also result in the creation of the directory structure shown below. The AIM GmbH directory will be located in C:\Program Files\. The Program Files directory will be located on the drive that was chosen during the BSP install.

  • Page 16: Hardware Installation (Api1553)

    2.2 Hardware Installation Once you have installed the BSP as described in Section 2.1, you can now begin installation of the hardware and associated driver. AIM devices are full PCI Plug-and-Play capable. There are no jumpers or switches to modify before installation.

  • Page 17: Installing The Aim Hardware

    Section 2 – New BSP and hardware installation procedure 2.2.1 Installing the AIM Hardware ESD Warning!!! The PCI 1553 boards are typical electronic devices that are sensitive to electrostatic discharge. It is important to observe normal precautions when handling the board to prevent damage.

  • Page 18: Installing The Windows System Driver

    The following procedures perform installation and verification of the Windows XP, Windows Vista Driver or Windows 7. The Hardware Wizard will be directed to obtain the Windows XP, Windows Vista or Windows driver for the device from: c:\Program Files\AIM GmbH\PCI-1553-Windows-BSP-Vxxxx\SysDrv32 c:\Program Files\AIM GmbH\PCI-1553-Windows-BSP-Vxxxx\SysDrv64 SysDrv32...
  • Page 19 Section 2 – New BSP and hardware installation procedure Select: Don’t search. I will choose the driver for install. Select the Next button. Select the Next button again. PCI 1553 Getting Started Manual...
  • Page 20 Section 2 – New BSP and hardware installation procedure Select the Have Disk button. Select Browse and navigate to: For 32 Bit PCI devices: c:\Program Files\AIM GmbH\PCI-1553-Windows-BSP- Vxxxx\SysDrv32\PCI For 32 Bit USB devices: c:\Program Files\AIM GmbH\PCI-1553-Windows-BSP- Vxxxx\SysDrv32\USB For 64 Bit PCI devices:...
  • Page 21 Section 2 – New BSP and hardware installation procedure Select the OK button. Select the Next button. The Hardware Wizard will begin installing the driver and the following window will appear upon completion. Select Finish to close the wizard. PCI 1553 Getting Started Manual...
  • Page 22 View in order to find the System icon) In the Device Manager window, expand the AIM Components entry by clicking on it Next, right click on the AIM board entry and select Properties. In the Properties window, select the Driver tab… PCI 1553 Getting Started Manual...
  • Page 23 Section 2 – New BSP and hardware installation procedure …then the Driver Details... button. The Driver File Details window will appear. PCI 1553 Getting Started Manual...
  • Page 24 Section 2 – New BSP and hardware installation procedure THIS PAGE INTENTIONALLY LEFT BLANK PCI 1553 Getting Started Manual...

  • Page 25: Bsp Upgrade Procedure

    PC driver software and the onboard target driver software. The BSP is available on CD from AIM or via a download from AIM-Online. Appendix A contains instructions for performing the download.

  • Page 26: Update The Onboard Flash Firmware

    If you are updating from a BSP version lower than V10.00 please contact support@aim-online.com for advice. Select Start | Run..., then in the Run window, click the Browse... button and navigate to: x:\Program Files\AIM GmbH\PCI-1553-Windows-BSP-Vxxxx\Onboard-SW Update.bat Select the file, then the Open button.

  • Page 27: Update Of Amc / Apm / Ap104 / Usb Boards

    Select Start | Run..., then in the Run window, click the Browse... button and navigate to: c:\Program Files\AIM GmbH\PCI-1553-Windows-BSP-Vxxxx\Onboard-SW From the Onboard-SW directory, navigate into the subdirectory which corresponds to the type AIM 1553 module you are updating. In the module specific subdirectory, select the Update_Axx1553.bat file, then the Open button.

  • Page 28: Removing Previously Installed Drivers And Bsp

    Section 3 – BSP upgrade procedure 3.3 Removing Previously Installed Drivers and BSP Before installing the new PCI 1553 Windows BSP, it is recommended that the previously installed drivers and BSP are removed from the system. The next chapter explains how to remove the Windows system driver and BSP from a PC.
  • Page 29 "AIM GmbH" and verify the contents are related to the AIM GmbH API driver using a text editor such as Notepad or Wordpad prior to deletion. Use the pnputil.exe command to find and delete all 1553 drivers. (Windows Vista and Windows 7 only) pnputil –e will list all device drivers installed on the system.
  • Page 30 Section 3 – BSP upgrade procedure THIS PAGE INTENTIONALLY LEFT BLANK PCI 1553 Getting Started Manual...

  • Page 31: Connecting The Aim Module To The Bus

    Section 4 – Connecting the AIM module to the bus CONNECTING THE AIM MODULE TO THE BUS The MIL-STD-1553 Specification clearly defines the process of coupling subsystems to the bus. This connection, called a stub, has two coupling options: Direct and Transformer Coupled.
  • Page 32 Section 4 – Connecting the AIM module to the bus Transformer Coupling Transformer Coupling utilizes a bus coupler that contains an isolation transformer and isolation resistors. Transformer Coupling extends the stub length to 20 feet and provides electrical isolation, better impedance matching and higher noise rejection characteristics than Direct Coupling.
  • Page 33 Section 4 – Connecting the AIM module to the bus Direct to Device (Network) Coupling Direct to Device (Network) Coupling is an option with AIM modules. The AIM design includes on-board Bus Network circuitry that is software selectable. This allows the user to connect directly to a single terminal device without the need for any bus coupling.
  • Page 34 Section 4 – Connecting the AIM module to the bus THIS PAGE INTENTIONALLY LEFT BLANK PCI 1553 Getting Started Manual...

  • Page 35: Compiling And Running A Sample Project

    1553 programmers guide document. Note: To execute a pre-compiled sample program run 1553_sample_project.exe from within the sample directory : Start | All Programs | AIM GmbH | PCI-1553-Windows-BSP-Vxxxx | 1553_sample_project The 1553_sample_project program opens a board and provides a selection of sample functions to execute .
  • Page 36  To Open the sample solution which contains all the sample functions Start Visual Studio, then select File | Open Project/Solution and navigate to: C:\Program Files\AIM GmbH\PCI- 1553-Windows-BSP-Vxxxx\sample\ and open the solution : 1553_sample_project.sln  To add the proper search paths for the include files...
  • Page 37 Section 5 – Compiling and running a sample project  To add the proper preprocessor definition Right click the project and select Properties Select the C++ / Preprocessor Under Preprocessor Definitions, if not already included, enter _AIM_WINDOWS then select OK. ...
  • Page 38 Section 5 – Compiling and running a sample project  To Build and Execute a Sample Program Build | Rebuild Solution The executable will be stored in the Debug or Release subdirectory Copy the api_mil.dll into the Release and Debug directory Run the executable.

  • Page 39: Notes

    Compact PCI C (Language) Virtual Instrument Dynamic Link Library Electrostatic Discharge MIL-STD Military Standard Operating System MIL-STD-1553 Databus Analyzer Software for Windows PC/AT Personal Computer/Advanced Technology Peripheral Component Interconnect Peripheral Component Interconnect Mezzanine Card Plug and Play Read Only Memory...
  • Page 40 Section 6 – Notes THIS PAGE INTENTIONALLY LEFT BLANK PCI 1553 Getting Started Manual...
  • Page 41 Appendix A – Downloading the BSP from AIM-Online APPENDIX A Downloading the BSP from AIM-Online PCI 1553 Getting Started Manual...

  • Page 42: Downloading The Bsp From Aim-Online

    Appendix A – Downloading the BSP from AIM-Online DOWNLOADING THE BSP FROM AIM-ONLINE The AIM-Online DOWNLOAD AREA consists of current manuals, BSPs, and documentation categorized by product.  To obtain the PCI 1553 Windows BSP from AIM-Online http:\\www.aim-online.com Go to The aim-online.com main web page appears.
  • Page 43 Appendix A – Downloading the BSP from AIM-Online If you have lost your password, please click on the following button: If you are already a registered user fill in your Username and Password and Click the Login selection The following page appears when successfully logged in. Click on the...
  • Page 44 Appendix A – Downloading the BSP from AIM-Online The following page appears. Click on the board name you want to download software or manuals from: The following page appears. You can now choose the Operating System you want to download software for. Just click on the related OS icon on the right...
  • Page 45 Appendix A – Downloading the BSP from AIM-Online PCI 1553 Getting Started Manual...
  • Page 46 Appendix A – Downloading the BSP from AIM-Online Select the package to be downloaded (BSP, Release Notes, Manuals). We will select now the BSP to be downloaded: The download will start immediately.  To install the BSP (See Section 2.1)
