www.weslo.com
Model No. WLEX91708.0
Serial No.
Write the serial number in the
space above for reference.
Serial Number
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: You must note the
product model number and serial
number (see the drawing above)
before contacting us:
1-866-699-3756
CALL TOLL-FREE:
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.wesloservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
All manuals and user guides at all-guides.com
Decal
USERʼS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit T 3.8 and is the answer not in the manual?

Questions and answers

Related Manuals for Weslo Pursuit T 3.8

Summary of Contents for Weslo Pursuit T 3.8

  • Page 1 All manuals and user guides at all-guides.com www.weslo.com USERʼS MANUAL Model No. WLEX91708.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE;...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise cycle before using your exercise cycle. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    The model number and the location of the serial for increasing cardiovascular fitness, building number decal are shown on the front cover of this endurance, and toning the body. The PURSUIT T 3.8 manual. exercise cycle provides a selection of features...

  • Page 5: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY To hire an authorized service technician to assemble the exercise cycle, call 1-800-445-2480. Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the pack- ing materials.
  • Page 6 All manuals and user guides at all-guides.com To make assembly easier, read the information on page 5 before you begin. Turn the Front Stabilizer (2) so that the large holes are facing the Frame (1). Attach the Front Stabilizer (2) to the Frame (1) Large with two M10 x 60mm Patch Screws (33).

  • Page 7: Seat Brackets (14, 15) With Four M6 X 35Mm

    All manuals and user guides at all-guides.com 4. Attach the Left and Right Seat Brackets (14, 15) to the Seat Frame (5) with two M8 x 125mm Bolts (62), four M8 Washers (54), and two M8 Locknuts (10) as shown. Do not tighten the Locknuts yet.

  • Page 8: Seat Brackets (14, 15) With Four M6 X 35Mm

    All manuals and user guides at all-guides.com 7. Attach the Seat (12) to the Left and Right Seat Brackets (14, 15) with four M6 x 35mm Button Screws (61) and four M6 Washers (52). 8. While another person holds the Upright (13) near the Frame (1), locate the wire tie in the Wire Upright.
  • Page 9 All manuals and user guides at all-guides.com 9. The Console (16) can use four AA batteries (not included); alkaline batteries are recommended. Batteries IMPORTANT: If the Console has been exposed to cold temperatures, allow it to warm to room temperature before inserting Battery batteries.
  • Page 10 All manuals and user guides at all-guides.com 11. Identify the Left Pedal (24), which is marked with an “L” sticker. Using an adjustable wrench, firmly tighten the Left Pedal (24) counterclockwise into the left arm of the Crank (21). Tighten the Right Pedal (not shown) clockwise into the right arm of the Crank.

  • Page 11: How To Use The Exercise Cycle

    All manuals and user guides at all-guides.com HOW TO USE THE EXERCISE CYCLE HOW TO ADJUST THE SEAT FRAME For effective exercise, the seat should be in the proper position. As you pedal, there should be a slight bend in your knees when the pedals are in the most forward position.
  • Page 12 All manuals and user guides at all-guides.com CONSOLE DIAGRAM HOW TO USE THE MANUAL MODE 1. Turn on the console. To turn on the console, press the On/Reset button or begin pedaling. The entire display will light for a moment; the console will then be ready for use. 2.
  • Page 13 All manuals and user guides at all-guides.com 5. Measure your heart rate if desired. The upper display is the priority display. Note: If there are The priority display thin sheets of clear can show the Metal Contacts plastic on the metal elapsed time, the contacts of the distance that you...
  • Page 14 All manuals and user guides at all-guides.com HOW TO USE A PERSONAL TRAINER PROGRAM Note: You can manually override the programmed resistance level by pressing the Resistance 1. Turn on the console. increase and decrease buttons. However, when the current segment ends, the resistance will auto- See step 1 on page 12.

  • Page 15: Maintenance And Troubleshooting

    All manuals and user guides at all-guides.com MAINTENANCE AND TROUBLESHOOTING HOW TO ADJUST THE DRIVE BELT Inspect and tighten all parts of the exercise cycle reg- ularly. Replace any worn parts immediately. If you can feel the pedals slip while you are pedaling, To clean the exercise cycle, use a damp cloth and a even when the resistance is at the highest level, the small amount of mild detergent.

  • Page 16: Exercise Guidelines

    All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning time. During the first few minutes of exercise, your this or any exercise program, consult your body uses carbohydrate calories for energy.
  • Page 17 All manuals and user guides at all-guides.com SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips.

  • Page 18: Part List

    All manuals and user guides at all-guides.com PART LIST—Model No. WLEX91708.0 R0209A Key No. Qty. Description Key No. Qty. Description Frame – Not Used Front Stabilizer Flywheel – Not Used Magnet Front Stabilizer Cap Flywheel Axle Seat Frame M10 Small Washer Rear Stabilizer M4 x 25mm Screw Handlebar Cap...

  • Page 19: Exploded Drawing

    All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. WLEX91708.0 R0209A...

  • Page 20: Ordering Replacement Parts

    All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
