Order No. 4564
BUILDING INSTRUCTIONS
CHIP
For electric motor and three 850 mAh LiPo cells
The model requires a three-function HoTT radio control system
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
Modifications reserved. No liability for printing errors.
Id.-Nr. 0062414
3/2011
