Proton & Neutron Cabinets

Proton

Neutron

Art No.44800

Art No.44500

Thank you for purchasing this HiB product.

Please read through these instructions carefully and refer back to them during installation to ensure that

your product is fitted safely and that it retains its high quality finish.

Please retain this leaflet for future reference.

Before drilling, ensure there are no hidden cables or pipes in the wall.

Please Note

This product must be installed with a minimum distance of 150mm between the

infra-red sensor switch and any adjacent wall or object to ensure correct operation of

the sensor. DO NOT FIT SHELVES AT THIS STAGE.

Min. 150mm

#02 003 R150904

Ver No.

1.0 Jan 2016

Need help?

Do you have a question about the Proton and is the answer not in the manual?

Page 1 Art No.44800 Art No.44500 Thank you for purchasing this HiB product. Please read through these instructions carefully and refer back to them during installation to ensure that your product is fitted safely and that it retains its high quality finish.
Page 2 REAR VIEW Mounting Points location of internal ﬁxing hole Angle Adjustment Claw In/Out Claw In/Out Adjustment Adjustment Fixing Preparation (Fig A) Fixing Brackets (Fig B) Hanger Adjustment (Fig C) Wall Hung Installation plasterboard walls, specialist fixings should be purchased from any DIY or hardware store. 1.
Page 3 Sensor switch controller LED driver Rewire the cabinet as shown in the diagram above. HiB recommends that all electrical bathroom products should only be fitted by a suitably qualified, Part P registered electrician. For further assistance on isolating the sensor please contact us.
Page 4 ©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specifications as necessary. E & OE.
