HiB Atrium 50 Installation Instructions

Cabinet

Download this manual

Atrium 50, 60 & 80 Cabinet

Atrium 50

Art No.

53000

Thank you for purchasing this HiB product.

Please read through these instructions carefully and refer back to them during installation to ensure that

your product is fitted safely and that it retains its high quality finish.

Please retain this leaflet for future reference.

Before drilling, ensure there are no hidden cables or pipes in the wall. Ensure the domestic electrical

mains supply to which the product is being connected is turned off for installation.

Electrical Safety Information

HiB recommends that all electrical bathroom products must be installed in accordance with current build-

ing and wiring regulations. If in doubt please contact an electrician.

Atrium 60 & 80

Art No.

53100 & 53200

#02 022 R191119

Ver No.

1.0 Jan 2020

Need help?

Do you have a question about the Atrium 50 and is the answer not in the manual?

Page 1 Electrical Safety Information HiB recommends that all electrical bathroom products must be installed in accordance with current build- ing and wiring regulations. If in doubt please contact an electrician.
Page 2 PLEASE NOTE This product can only be recessed fitted into a wall. A minium of 80mm depth is required. Before installing ensure you take note of measurements for the area of the cabinet that will be recessed into the wall and the side fixing points inside the cabinet carcass (See Fig. B & D). DO NOT fit the shelves until the cabinet is installed and secured in place.
Page 3 Wiring Diagram (Fig.F) Live is Brown Live supply can be Red or Brown Live Earth is Green and Yellow Earth Earth supply is Green and Yellow Neutral is Blue Neutral Neutral supply can be Blue or Black LUMINAIRE MAINS SUPPLY hib.co.uk...
Page 4 ©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specifications as necessary. E & OE.
