DVQM

Classification:
Description:
Command syntax:
DVQ
Mode Components
0 RGBY
CbCr
1 RGBY
CbCr
2 RGBY
CbCr
Example:
Related commands:
24 Chapter 3 HDMI Command Reference
Digital Video Quantization Mode
Format parameter setting
Controls the gamut of digital signals per EIA/CEA-861.
DVQM x
Where x is 0, 1, or 2.
NBPC=6 gamuts
LMIN LMAX
0 63
0 63
1 62
1 62
4 59
4 60
Notes:
• Computer (for example, DMT and CVT) formats set DVQM=0 for full gamut.
• DVQM can be set to 1 to test the undershoot/overshoot signal code margins (for
example, see SMPTE 296M section 7.12).
• All television formats (for example, 1080i29) set DVQM=2 for reduced gamut required
by various television standards (for example, EIA/CEA-861-B).
DVQM 1
FMTU
LMIN, LMAX, NBPC
NBPC=8 gamuts NBPC=10 gamuts
LMIN LMAX LMIN
0 255 0
0 255 0
1 254 4
1 254 4
16 235 64
16 240 64
NBPC=12 gamuts
LMAX LMIN LMAX
1023 0 4095
1023 0 4095
1019 16 4079
1019 16 4079
940 256 3760
960 256 3840
