- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S ® iPad 2 and 3 Flush Mount Bracket Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FSRI2T...
- Page 2 WARNING: Do not use this product outdoors. IMPORTANT SAFETY INSTRUCTIONS IMPORTANT ! : The FSRI2T is designed for use with the iPad 2 and iPad 3 mobile digital device models. WARNING: A WARNING alerts you to the possibility of IMPORTANT ! : The FSRI2T is designed to mount directly to serious injury or death if you do not follow the instructions.
- Page 3 Installation Instructions FSRI2T LEGEND Tighten Fastener Security Wrench Apretar elemento de fijación Llave de seguridad Befestigungsteil festziehen Sicherheitsschlüssel Apertar fixador Chave de segurança Serrare il fissaggio Chiave di sicurezza Bevestiging vastdraaien Veiligheidssleutel Serrez les fixations Clé de sécurité Loosen Fastener Phillips Screwdriver Aflojar elemento de fijación...
- Page 4 FSRI2T Installation Instructions ASSEMBLY AND INSTALLATION NOTE: The FSRI2T is compatible with the iPad® 2 and iPad® 3 mobile digital device models alone, not mounted in a case. Assembly Assemble two side assemblies (A) to two end assemblies (B). (See Figure 1) Fasten side and end assemblies together using four 06-32 x 1/4"...
- Page 5 Determine mounting location on wall. Repeat Steps 4 through 7 for each mounting hole. Using FSRI2T as a template, level and mark four holes at the four holes in FSRI2T. (See Figure 7) Drill four 1/4" pilot holes at marked locations on wall. (See...
- Page 6 Attach power cord to iPad, if desired. Cable must pass through wall and be connected to an appropriate power supply. (See Figure 9) Slide iPad into FSRI2T mount, ensuring that power cord is placed in slot located on FSRI2T. Replace end piece of FSRI2T.
- Page 7 Installation Instructions FSRI2T...
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
