hentech HT201 Instruction Manual

Enlarged version

IMPORTANT: This manual includes essential information on the safety measures to

Instruction Manual for LED

be implemented for installation and start-up. Therefore, the installer, as well as the

user, must read these instructions before beginning installation and start-up.

Technical Specification

Underwater Light HT201

Standard input voltage: 12V AC/DC (Range: 12~18VAC or DC)

Standard input watt:

RGB

18W

23W

30W

33W

40W

50W

95W

White

21W

26W

33W

36W

45W

60W

100W

Use life: 60,000 hours

16 programs with Synchronization capability

Dimensions:

Table of Contents

Do you have a question about the HT201 and is the answer not in the manual?

Page 1 Therefore, the installer, as well as the user, must read these instructions before beginning installation and start-up. Technical Specification Underwater Light HT201 Standard input voltage: 12V AC/DC (Range: 12~18VAC or DC) Standard input watt:...
Page 2 Concrete Pool Concrete & Liner Cable Connection...
Page 3 Maintenance & Replacement Chart of parts There is no maintenance required for this lamp it is designed to be used only once, meaning that replacement is necessary if it becomes defective (repairing is impossible). Before any handling, ensure that there is NO voltage supplied to the lamp. To replace, unfasten the lamp from the bracket.
Page 4 Safety Warnings The persons who are in charge of installation should have the required qualifications for this type of work. Avoid making contact with the electric voltage. " Comply with the current standards regarding accident prevention. " IEC 364-7-702 standards must be observed: WIRING IN BUILDINGS, SPECIAL WIRING, SWIMMING POOLS.
