FLIR Quasar Gen III CM-6308 Quick Install Manual

FLIR Website
QR Code
CM-6308-P1-I mini-dome camera
Accessory Bag: 4 x screw s, 4 x plastic anchors
T20 Torx w rench
Drill template
Desiccants
2-pin pow er terminal connector
8-pin I/O terminal connector
3/4" Rubber O-ring
CM-6308 Quick Install Guide
A. Insert the microSD
The camera is shipped without a microSDXC card.
The user must install a card if storing snapshots or recording triggering by events locally is required.
To install a microSDXC card
1. Format a microSDXC card (min 4GB, up to 128GB, Class 10, formatted as a single partition) on your PC.
2. Insert the card into the slot on the camera's circuit board.
3. Verify that the card status is displayed as Mounted in the unit's System > Events Handler > SD Card screen.
4. Configure the camera to store snapshots and recordings from the System > Events Source screens.
Quick Install Guide
What's in the Box
Qty
1
1
1
1
2
1
1
1
1
Quasar Gen III
CM-6308
4x2K Convertible 180 ° / 360 ° Panoramic Mini-dome Camera
