Zener ECODRIVE 8000 Installation Manual Supplement

Solar vsd
Hide thumbs Also See for ECODRIVE 8000:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
ZENER VARIDRIVE SOLUTIONS
ZENER 8000 ECODRIVE®
Solar VSD Installation Manual - Supplement
Firmware Revision:
V5.2.9
Document:
IM00130 Rev J
Printed:
20/07/2018 3:59 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECODRIVE 8000 and is the answer not in the manual?

Questions and answers

Related Manuals for Zener ECODRIVE 8000

Summary of Contents for Zener ECODRIVE 8000

  • Page 1 ZENER VARIDRIVE SOLUTIONS ZENER 8000 ECODRIVE® Solar VSD Installation Manual - Supplement Firmware Revision: V5.2.9 Document: IM00130 Rev J Printed: 20/07/2018 3:59 PM...
  • Page 2 (This manual) Document: IM00130 ECODRIVE Blocking Diodes: www.zener.com.au/images/im00156.pdf Document: IM00156 ECODRIVE Solar Connectors: www.zener.com.au/images/im00157.pdf Document: IM00157 If the above cannot be accessed or found please contact ZENER VARIDRIVE: Phone: 1300 4 ZENER (1300 493 637) Email: sales@zener.net IM00130 P a g e...

  • Page 3: Table Of Contents

    This manual is a simplified guide for the ZENER ECODRIVE 8000 firmware revision V5-2-7. For full details on parameters & programmable functions refer to the ZENER 8000 Reference manual IM00140. For details on AC Wiring & circuit protection refer to the ZENER 8000 installation manual IM00124.

  • Page 4: Safety / Warnings

    Read and follow all instructions carefully!! This chapter contains safety instructions that must be followed when installing, operating and servicing the ZENER ECODRIVE 8000. Non-compliance may result in damage to the ECODRIVE, the motor or other equipment being driven. Non-compliance may also result in physical injury or death to personnel, livestock or wildlife.
  • Page 5 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS Do not touch the terminals of the equipment or any associated motor wiring when the equipment is energised, even if motor is stopped. Electric shock may result. In Auxiliary Power (Dual) Supply applications where the ECODRIVE is supplied from AC power, the photovoltaic conductors must be treated as being live parts.
  • Page 6 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS The ECODRIVE does not have integral disconnect devices and these must be provided externally for each supply source. The disconnector in the DC supply circuit must be rated to switch the whole photovoltaic array current and rated to switch the array maximum open circuit DC voltage at the expected minimum temperature.
  • Page 7 Ensure you understand how to operate the equipment before attempting to run the motor/pump to test direction. Use the set-up guide provided to setup / commission the equipment or consult Zener for assistance. If you are require clarification or more information on any of the above please contact Zener.

  • Page 8: Glossary (Terms & Abbreviations)

    It prevents current flow from the ECODRIVE to the PV modules. ECODRIVE This is a ZENER product that converts a DC supply (and AUX AC supply) to control a 3phase induction motor dependent upon the power extracted from an array of solar panels. A registered trademark of Zener Electric Pty Ltd.

  • Page 9: Introduction

    There are many modes of operation that can be customised depending on your individual requirements. To simplify installation & setup, Zener has selected 2 common modes of operation in which an ‘Application Menu’ has been developed for each. These are further detailed within this manual.

  • Page 10: Standard Applications

    ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS STANDARD APPLICATIONS Application – Tank Fill The ECODRIVE is configured to pump and fill a tank or vessel when the level is not full and there is sufficient solar energy available. An AC supply can also be used to pump when insufficient solar available.

  • Page 11: Pressure Control

    ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS Application – Constant Pressure Control The ECODRIVE is configured to provide a constant pressure using an integral PID controller. The ECODRIVE monitors the pressure and adjusts the motor/pump speed to achieve the set pressure.

  • Page 12: Technical Specifications & Ratings

    Refer to instruction manual IM00124 for more details on ratings, in particular for standard 3phase AC operation and recommended circuit protection. For single phase operation a DC bus choke must be fitted and a derating applied. Contact Zener for assistance. The output voltage cannot be higher than the AC input voltage or 70% of the DC input.
  • Page 13 8E170XX CHC+ (IP66) 715h 670w 298d All dimensions in mm. Contact Zener for larger sizes. Blocking Diode : A blocking diode is required whenever an Auxiliary AC Power Supply is used. With standalone solar installations, blocking diodes are optional but recommended with multi-string installations to ensure maximum efficiency where partial shading of the PV modules may occur.

  • Page 14: Solar Array & Pv Selection

    ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS THE SOLAR ARRAY & PV SELECTION: The Solar Array consists of a number of Photovoltaic (PV) modules connected in a series & parallel combination to achieve a certain voltage, current and power. It is important to select these carefully as the PV modules are a major cost of an installation and can be very expensive to rectify.

  • Page 15: Installation & Wiring

    800VDC which requires special consideration when installing and operating. Refer to all warnings located at the front of this manual. This manual should be read in conjunction with the ZENER 8000 instruction manual and all applicable standards and regulations.
  • Page 16 Input Power Wiring – PV Only This manual should be read in conjunction with the ZENER 8000 instruction manual and all applicable standards and regulations. This equipment and other components that are part of the system must also be installed as per the manufacturer’s recommendations and any applicable standards and regulations.

  • Page 17: Auxiliary Ac Power Supply

    ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS Input Power Wiring – PV and AUX AC Supply The ECODRIVE can also operate from an auxiliary AC power supply such as GRID or generator supply. Refer to page 16 for information on switching the auxiliary AC supply and ‘blending’.
  • Page 18 A ‘step-up or step-down’ transformer’ on the AC supply may be required to achieve maximum benefit from ‘blending’. CONTACT ZENER FOR SELECTION IM00130 P a g e | 16 20/07/2018 3:59 PM...

  • Page 19: Motor Wiring

    Metal cable gland Screened With 360°C screen screened properly terminated at both sides. Control cable termination For more details the ZENER 8000 installation manual for AC Supply Screened cable not required detailed explanation. IM00126 Screened Power cable Metal cable gland With 360°C screen...

  • Page 20: Earthing

    Lightning Protection A good earth connection is important for lightning protection. Zener recommends that surge protection devices also be installed at the ECODRIVE on the AC & DC supply inputs and PV array if located in an area where lightning flash density is greater than two flashes per square Km per year.
  • Page 21 Control wiring is provided for the ‘application menus’ offered with the ECODRIVE. Since all the Digital & analogue I/O is completely programmable alternative wiring is possible. Refer to the ZENER 8000 manual for more detail and alternate wiring. Solar Tank Fill Control Wiring The following control wiring is recommended when the application for ‘Tank Solar’...
  • Page 22 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS Solar Pressure Control Wiring: The following control wiring is recommended when the application for ‘Pressure Solar’ or ‘Pressure solar AC’ is selected. Input D1 (2): Operating mode Remove link for ‘Solar Only’ operation. The ECODRIVE will run only when ‘SOLAR GOOD’...

  • Page 23: Keypad Operation

    Remote Operation When ‘REMOTE’ mode is active the digital inputs have start/stop control. The speed reference is configured within the menu from various sources. This also includes PID operation. Refer to the ZENER 8000 instruction manual. IM00130 P a g e...
  • Page 24 Digital input selected for Solar only PV Only operation Digital input selected for Solar and AC + PV AC operation See the ZENER 8000 manual for other standard and customised trip messages & warnings. IM00130 P a g e | 22 20/07/2018 3:59 PM...

  • Page 25: Solar Mode & Parameters

    Solar related parameters This manual supplement includes only the solar related parameters. For all other parameters refer to the ZENER 8000 manual. The setup guide in Appendix A will guide you through the parameters and commissioning process for the different applications.
  • Page 26 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS Solar Only – No Irradiance Sensor The ECODRIVE monitors the DC voltage. If the voltage from the solar array reduces below the entered “VOLTAGE AT MAXIMUM POWER” the ECODRIVE MPPT tracking adjusts its output accordingly. If the speed decreases less than the ‘C01 MINIMUM SPEED’...

  • Page 27: Preparation & Preliminary Checks

    AC or DC. “Loading an Application” STEP 3: Select configuration from applications menu (This may have already been preconfigured by your ZENER Supplier/Distributor) The following steps will load the application. As the ECODRIVE powers on, the model and software version is displayed on the console.

  • Page 28: Irradiance Sensor

    Checking Irradiation Sensor Feedback This should display about 1000w/m2 on a sunny day with panels facing the sun. If incorrect check wiring. If the irradiance sensor was not supplied by ZENER check the settings & scaling. To modify the irradiance Scale...
  • Page 29 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS (Intentionally Blank) IM00130 P a g e | 27 20/07/2018 3:59 PM...
  • Page 30 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS Application SETUP GUIDE Application 1: Tank Fill … Page 31 1A Tank Solar 1B Tank Solar AC Application 2: Pressure Control … Page 36 2A Pressure Solar 2B Pressure Solar AC WARNING: When programming the ECODRIVE never remove the power when it is going through it ‘Saving sequence’.
  • Page 31 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS (Intentionally Blank) IM00130 P a g e | 29 20/07/2018 3:59 PM...
  • Page 32 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS 1 TANK FILL (or BASIC PUMPING) This setup guide is for a ‘Tank fill’ application assuming the application ‘Tank Solar’ or ‘Tank Solar AC’ is selected and all control and sensor wiring is as per wiring detailed in the manual.
  • Page 33 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS SETUP for Tank Fill / Basic Pumping Saving Changes: During the commissioning sequence you may be asked to save changes. It is not necessary to save changes each time a parameter is changed. It may be faster to leave this step till last or when all parameters are set appropriately.
  • Page 34 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS [SETUP for Tank Fill / Basic Pumping] Restart DC The voltage required for the ECODRIVE to restart the motor/pump in solar only operation. Restart DC Typically this would be set 20-25VDC higher than array voltage at maximum power. The 550VDC Minimum Restart DC allowable is the Vmp setting.
  • Page 35 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS [SETUP for Tank Fill / Basic Pumping] Rated Motor Current An important parameter is the motor rated current which is used to help estimate the Rated Motor Amps motor load. The rated current is that found on the motor nameplate.
  • Page 36 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS [SETUP for Tank Fill / Basic Pumping] Low Speed trip During ‘Tracking’ only, if the output speed operates below the minimum speed the Lo Speed Trip time ECODRIVE will fault. This setting adjusts the trip time. It should be set as short as possible 20 secs to provide the required protection of the pump/motor but longer than the ‘LO SOLAR Q...
  • Page 37 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS (Intentionally Blank) IM00130 P a g e | 35 20/07/2018 3:59 PM...
  • Page 38 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS 2 SETUP for a pressure Control System This setup guide is for a ‘Pressure Control’ application assuming the application ‘SOLAR Pressure Control’ is selected and all control and sensor wiring is as per wiring detailed in the manual.
  • Page 39 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS [SETUP for a pressure Control System] Checking the Transducer Feedback It is possible to check for the transducer signal by viewing its present value in the service menu. In general, when power is first applied it is reasonable to expect that there is no pressure in the plumbing system.
  • Page 40 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS [SETUP for a pressure Control System] The Application Parameters Saving Changes: During the commissioning sequence you may be asked to save changes. It is not necessary to save changes each time a parameter is changed. It may be faster to leave this step till last or when all parameters are set appropriately.
  • Page 41 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS [SETUP for a pressure Control System] Restart DC The voltage required for the ECODRIVE to restart the motor/pump in solar only operation. Restart DC Typically this would be set 20-25VDC higher than array voltage at maximum power. The 550VDC Minimum Restart DC allowable is the Vmp setting.
  • Page 42 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS [SETUP for a pressure Control System] Rated Motor Current An important parameter is the motor rated current which is used to help estimate the Rated Motor Amps motor load. The motor load is used to determine if the idle function is to be invoked. The 40.2 A...
  • Page 43 4.9 bar potentiometer, switches or other device. Refer to the ZENER 8000 manual to modify this. Proportional Band (For Tuning of internal PID/pressure controller, see Page 43)
  • Page 44 This 8.0bar parameter is the threshold for high pressure detection. Verify the value and alter as required. The trip time is default at 0 seconds. Refer to the ZENER 8000 manual to modify this. Fill Fail Time...
  • Page 45 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS [SETUP for a pressure Control System] Operation and Tuning • Switch to automatic operation or wire in the “REMOTE” or “pressure control” link into D4(5) to enable automatic pressure control as per this partial sketch.

  • Page 46: Additional Settings

    For assistance with other configurations contact Zener or refer to the ZENER 8000 Instruction manual. Some settings that may be required for pumping & solar applications include: Dual Ramp: A dual ramp configuration is available to have different acceleration rates above or below the minimum speed setting.
  • Page 47 ZENER ECODRIVE® 8000 ZENER VARIDRIVE SOLUTIONS Deceleration Ramp: Some installations may suffer from water hammer problems. By slowly ramping the pump speed through the critical speed region the water hammer can be reduced or eliminated. It is recommended to consult the pump/motor manufacturer to confirm it is suitable to operate with a deceleration or soft stop.

  • Page 48: Idle Mode

    When the pressure drops due to returned demand the time ‘Idle Delay’ and then goes into ‘Idle Mode’ (sleep). Or ; ZENER 8000 wakes automatically and operates in PID mode. The input from the optional Flow Switch indicating ‘No Flow’ for the ‘Idle Delay’.
  • Page 49 (‘% Load’ threshold is not used). When the flow switch provides an ‘open contact’ (ie.no flow’) into D3 (terminal 35) for the ‘Idle delay’ period the ZENER 8000 will enter idle mode. It can operate in conjunction with the ‘% Load’ method.
