Summary of Contents for CAME GARD PT Series

  • Page 1 Brushless automatic barrier FA01119-EN GARD PT series GPT40AGS EN English INSTALLATION MANUAL...
  • Page 2 ANGER OF HIGH VOLTAGE ANGER OF HAND ENTRAPMENT O NOT ENTER CAUTION: Once you have released the barrier by using the corresponding key, we highly recommend to lock the barrier into place again once it has opened, by turning the same key as shown in figure B. Not locking the barrier back into place may result in it uncontrollably falling unless it is perfectly horizontal.
  • Page 3 This product must only be used for its specifi cally intended purpose. Any other use is dangerous. Came S.P.A. is not liable for any damage caused by improper, wrongful and unreasonable use. • This manual's product is defi ned by machinery directive 2006/42/ CE as "partly-completed machinery".
  • Page 4 This symbol shows which parts to read carefully. ⚠ This symbol shows which parts describe safety issues ☞ This symbol shows which parts to tell users about. Unless otherwise stated, these operations apply to all models. The measurements, unless otherwise stated, are in millimeters. DESCRIPTION GPT40AGS- Automatic barrier with reversible gearmotor and brushless motor;...
  • Page 5 Description of parts ❶ Motor-shaft plate ❷ Boom-attachment cover ❸ Protective casing shear proof ❹ Fastening screws protective cover ❺ Control panel ❻ Boom setting mechanical stop ❼ Gear motor with encoder ❽ Lever arm ❾ Cover ❿ Cabinet ⓫ Inspection hatch ⓬...
  • Page 6 Completion accessories Accessories 803XA-0050 803XA-0070 ❶ ❷ Boom 90x35 (L= 4050) GARD PT spring unit 803XA-0051 803XA-0010 ❸ Boom 90x35 (L = 3050) GARD PT luminous gearwheel 803XA-0030 ❹ Electric lock assembly 803XA-0080 ❺ Auxiliary contacts for checking the position of the boom 806SA-0080 ❻...
  • Page 7 Standard installation ❶ Barrier ❽ Fixed rest ❷ Reflective strips ❾ Coil ❸ LED strip ❿ Control device post ❹ Anti-collision profile ⓫ Control device (keypad selector, transponder sensor) ❺ Luminous gearwheel ❻ Photocell ❼ Small photocell post ❾ ❽ ❻ ⓫ ❸ ❷ ❼ ❺ ❿ ❹ ❶ ❻ ❼...
  • Page 8 Command and safety device 2 x 0.5 mm Antenna max 10 m Paired or CRP (Came Remote Protocol) connection max 1,000 m (*) Metal mass detector (see product literature) (*) 1000 m with 001UR042; 1000 m with 001RGSM001, 001RGSM001S, 001RSLV001 (Cloud connectivity devices). With a 230V AC power supply and using it outdoors, use H05RN-F type cables compliant with 60245 IEC 57 (IEC);...
  • Page 9 Set up a foundation frame that is larger than the anchoring plate and sink it into the dug hole. Fit an iron cage into the foundation frame to reinforce the concrete. Assemble the four anchoring braces to the anchoring plate. Place the plate over the iron cage.
  • Page 10 Preparing the barrier - Fit the key into the lock and turn it counter clockwise ❶. - Raise the cover and disconnect the two earthing cables ❷. - Removethe inspection hatch ❸ ❹. ❸ ❷ ❶ ❹ ⚠ The barrier is set up for installing on the left. When installing on the right, invert the boom's opening direction, as follows: ❶...
  • Page 11 Installing the barrier The cabinet should be installed with the inspection hatch on the most accessible side to make any adjusting easier. Place the cabinet onto the anchoring plate and fasten it using nuts and washers.  and Fasten the fastening flange to the motor shaft plate by using a supplied UNI5931 M8X20 screw ⚠...
  • Page 12 Fit the boom into the fastening flange and fasten it using the screws ❶ ❷. ❷ ❶ Cut the groove covering frame to the right length and fit them into the boom grooves on either side ❸ ❹. Fit the rubber terminal cap into the corresponding housing ❺. Fit the anti-collision profile into the boom ❻, to match the terminal cap ❺.
  • Page 13 Establishing the limit-switch points Close the inspection hatch and power up the system. Actuate the boom to check that it is parallel to the road surface when in the closed position when in the closed position, and at about 89° when in the open position. To correct the boom's vertical position: - Lower the boom;...
  • Page 14: Control Panel

    Composition of the semi-oval boom ⚠ Before adjusting the boom, check the accessories you want to fit and the passage clearance width. PASSAGE CLEARANCE WIDTH (3.8 m max.) A1=1 (Fast profi le – opening time 1.2-2.5 seconds) Working intermittency 100% Bar length <...
  • Page 15 Description of parts ❶ Power supply terminal board ⓬ USB stick connector ❷ Terminals for control and safety devices ⓭ Encoder connector ❸ Barrier state (NO) terminals. ⓮ Motor connector ❹ Terminal block for signalling devices: LED strip, luminous ⓯ Display ⓰...
  • Page 16: Electrical Connections

    ELECTRICAL CONNECTIONS Input voltage Accessories terminals: 230 V AC 50/60 Hz - a 24 V AC normally; N PE L - at 24 V DC when the emergency operation batteries start operating. Maximum absorption of all the devices is max. 40 W Command and control devices TEMPORARY STOP button (NC contact).
  • Page 17 Additional cards ❷ ❸ For the system to work properly, before fi tting any plug-in card, such as the AF or R800 one, you MUST CUT OFF THE MAINS POWER SUPPLY and, if present, disconnect any batteries. ❹ ❶ AF - for radio-control of the operators. ❷...
  • Page 18 Safety devices For the type of action controlled by the device,see function F2 for terminal CX, F3 for terminal CY or F4 for terminal CZ. If unused, contacts CX, CY and CZ should be disabled during programming. Photocells Configure contact CX, CY and/or CZ (NC/NO), input for safety devices such as photocells. - C1 reopening while closing (NC).
  • Page 19: Programming Device

    SAVING AND UPLOADING USER AND CONFIGURATION DATA and updating firmware - Fit the USB stick. Enter the card's menu. The red LED lights up when the USB memory stick is recognized. Functions F50, F51 and H2 are now visible. - Fit the USB to save / copy the settings and users, select F50 or F51. - To update the fi...
  • Page 20 Menu map ⚠ Start programming by first performing the following functions SETTING THE BOOM TYPE (A1), TEMPORARY STOP (F1), CALIBRATE TRAVEL (A3).   Only program functions when the operator is stopped. Up to 250 users can be memorized. Temporary stop function (1-2) Function associated to input CX F 56 Peripheral number Function associated to input CY...
  • Page 21 0 = 1200 Baud / 1 = 2400 Baud / 2 = 4800 Baud / 3 = 9600 Baud / 4 = 14400 Baud / 5 = 19200 Baud / 6 = 38400 Baud (default) / 7 = 57600 Baud / 8 = 115200 Baud For setting the communication speed used in the CRP (Came Remote Protocol) connection system.
  • Page 22 View the fi rmware version. FW update OFF (default) ON Request the FW update fi le from CAME S.p.A. Fit the memory stick and if it is accepted the red LED lights up. Enter the H2 menu and perform the update.
  • Page 23 Motor test ❶ Select (A2 marked areas.). Press ENTER to confirm. ❷ Select 1 to activate the test. Press ENTER to confirm ... ❸ 3..the dashes (---) will appear while waiting for the command. ❹ Keep pressed the > key and check whether the operator performs an opening maneuver. If the operator performs a closing maneuver, modify function F54 ❶...
  • Page 24 ❸ < > ENTER LIST OF REGISTERED USERS   From the docs.came.com portal, download the LIST OF REGISTERED USERS form. Type L20180423. Deleting a single user ❶ Select (U2). ❶ - Press ENTER to confirm. <...
  • Page 25: Final Operations

    ❸ ... the abbreviation CLr will appear to confirm the user has been deleted. ❸ < > ENTER FINAL OPERATIONS Once you've finished with the electrical connections and powered up the system, replace the inspection hatch (respect the phases indicated by the arrows ❶...
  • Page 26: Troubleshooting

    20 - Check the parameters of the A1 boom DISMANTLING AND DISPOSAL ☞  CAME S.p.A. applies a certified Environmental Management System at its premises, which is compliant with the UNI EN ISO 14001 standard to ensure the environment is safeguarded.
  • Page 28 CAME S.p.A. Via Martiri Della Libertà, 15 31030 Dosson di Casier - Treviso - Italy tel. (+39) 0422 4940 - fax. (+39) 0422 4941...
