- Page 1 OPERATOR 119 GM 0 2E N FOR STREET BARRIERS G2500 - G2500N INSTALLATION MANUAL English...
-
Page 2: Read Carefully
Warning Sings (e.g. gate plate). (i.e. that for which it was expressly built for). Any other use is Special instructions and to be considered dangerous. Came Cancelli Automatici S.p.A. advice for users is not liable for any damage resulting from improper, wrongful •... -
Page 4: Legend Of Symbols
G0462 - Fixed rest for barrier-arms; G0257 - Joint for the G0251 (maximum length of the barrier-arm is 2.0 m). Important! Make sure that the command and safety equipment and accessories are CAME originals; this ensures easy and safe installation and maintenance for your system. -
Page 5: Technical Description
4.3 Technical description OPERATOR ASSEMBLY UNIT Steel sheeting cabinet, 2 mm thick with galvanised finish. Varnished (G2500, RAL2004, G2500N textured grey). Inspection flap with customised key. Galvanised finish, steel anchoring-base complete with four clamps and relative nuts and bolts for fastening the cabinet to the floor. -
Page 6: Overall Dimensions
4.4 Overall dimensions Measurements in mm 5 Installation Installation must be carried by skilled, qualified technicians in accordance with current regulations. 5.1 Preliminary checks Before installing the operator, do the following: • Check that the installing the operator does not create and hazardous situations; Set up a suitable omnipolar cut-off device, with distances greater than 3 mm between contacts, with sectioned power supply;... -
Page 7: Standard Installation
5.3 Type of cable and minimum thicknesses Type of Cable length Cable length Cable length Connection for cable 1 < 10 m 10 < 20 m 20 < 30 m Power supply 230 V 2F 3G x 1.5 mm 3G x 2.5 mm 3G x 4 mm FROR CEI Photocell transmitters... - Page 8 5.5 Setting up the operator base The following illustrations are just examples, in that the space for securing the operator and accessories depends on the overall measurements. It is up to the installer to choose the most suited solution. - Dig a pit for the anchoring base and set up the required corrugated tubes for the connections coming out of the junction pit.
- Page 9 5.6 Assembly - Proceed with installing the unit: we suggest setting up the cabinet so that the inspection flap points inwards (see p. 8). Assemble the barrier-arm while calculating the proper length and fasten it to the arm-supporting attachmentA using the four supplied bolts.
-
Page 10: Description Of The Control Panel
5.7 R/L barrier To change sense of rotation, request documentation from your local dealer or contact CAME in your country (see last page, otherwise go to www.came.com). Left-hand Right-hand BARRIER BARRIER Entrance Entrance side side Inner zone Inner zone 6 Description of the control panel Engineered and built entirely by Came Cancelli Automatici S.p.A. -
Page 11: Main Components
6.1 Main components 1. Transformer 2. Working time adjuster trimmer 3. Automatic closing time adjuster trimmer 4. Radio frequency card socket 5. Connecting terminals 6. Transformer terminals 7. Antenna connection terminals 8. Line fuse 9. Accessories fuse 10. Code memorising button 11. -
Page 12: Electrical Connections
6.2 Electrical connections Gearmotor, limit switch The swing-joint in the picture (which is factory made) is for a left-hand barrier (see par. 5.7). Opening micro- switch (F-FA) Orange 230 V AC motor Orange Brown Black Closing micro- switch (F-FC) Blue Accessories power supply Terminals for powering the 24V AC accessories. - Page 13 Warning devices 230 V AC output for fl ashing light: - Flashes while barrier opens and closes. Barrier raised/open warning-light Contact rated for: 24 V - 3 W Max. - Signals that barrier-arm is raised, and switches of when the barrier-arm is lowered.
- Page 14 Safety devices Delta-S "Reopening when closing (N.C.) Contact» - Input for safety devices like photocells, compliant with law EN 12978. While the barrier is lowering, opening the contact will invert movement until it is fully raised. if unused, short-circuit contact 2-C1. if unused Delta "Reopening when closing (N.C.) Contact»...
- Page 15 6.4 Settings TCA Trimmer = Adjusting automatic closing time, from a minimum of 5 seconds to a maximum of 60 seconds. TL Trimmer = Adjusting working time from a minimum of 15 seconds to a maximum of 120 seconds. Connecting two barriers joined by a single command Motor A terminals Motor B terminals L1 L2 U...
-
Page 16: Activating The Radio Command
7 Activating the radio command Antenna Connect RG58 antenna cable to the apposite terminals. Radio frequency card Only for the AF43S / AF43SM radio-frequency cards. - position jumper as shown depending on the series of transmitters you are using. Frequency Card Series Radio-frequency... - Page 17 Transmitters ATOMO AT01 • AT02 see instruction sheet in the packaging AT04 of the AF43SR radio-frequency card see instructions on box TOUCH TOP-432A • TOP-434A TOP-432NA • TOP-434NA TCH 4024 • TCH 4048 TOP-302A • TOP-304A TOP-862NA • TOP-864NA TOP-432S TWIN TWIN 2 •...
-
Page 18: Safety Instructions
8 Safety instructions Important general safety instructions This product is only intended to be used for the purpose it was designed. Any other use is therefore improper and dangerous. The manufacturer is not liable for any damage caused by improper, wrongful or unreasonable use. Stay away from working mechanical parts. -
Page 19: Extraordinary Maintenance
Periodic maintenance log to be done by users (every 6 months) Date Notes Signature 9.2 Extraordinary maintenance The following table is used to log extraordinary maintenance, repair and improvement jobs done by the specialised external firms. N.B. All extraordinary maintenance jobs must be carried out by skilled technicians. Extraordinary maintenance log Installer's stamp Product name... -
Page 20: Troubleshooting
Installer's stamp Product name Date of job Technician's signature Customer's signature Job carried out _______________________________________________________________________________________ __________________________________________________________________________________________________ _______________________________________________________________________________________________ Installer's stamp Product name Date of job Technician's signature Customer's signature Job carried out _______________________________________________________________________________________ __________________________________________________________________________________________________ _______________________________________________________________________________________________ Installer's stamp Product name Date of job Technician's signature Customer's signature Job carried out _______________________________________________________________________________________... -
Page 21: Dismantling And Disposal
UNI EN ISO 14001 standard to ensure environmental protection. Please help us to safeguard the environment. At CAME we believe this to be one of the fundamentals of ours market operations and development strategies. Just follow these short disposal instructions: DISPOSING OF THE PACKAGING The components of the packaging (i.e. - Page 22 HR • Za sve dodatne informacije o poduzeću, proizvodima i tehničkoj podršci: UK • Для отримання будь-якої іншої інформації про компанію, продукцію та технічну підтримку: www. came.com www. came.com CAME Cancelli Automatici S.p.a. CAME Cancelli Automatici S.p.a. Via Martiri Della Libertà, 15 31030 Dosson Di Casier...
