Summary of Contents for Eglo NOOSA Series
- Page 1 Ă170 Ă1320.8mm （52" ） NOOSA Ceiling Fan 203369 203371 203372 203373 NOOSA Ceiling Fan with Light Installation Manual 202969 202971 Use & Care Guide 202972 202973 Warranty Information Distributed by: Reduction Revolution Pty Ltd NOOSA Ceiling Fan www.reductionrevolution.com.au...
- Page 2 EGLO Lighting has a policy of continual product improvement and development, dimensions, hardware and designs may change to reflect this policy. EGLO reserves the right to discontinue or change product specifications & designs at any time without notice and without incurring obligations.
-
Page 3: Table Of Contents
WARRANTY CONDITIONS: HOW TO MAKE A WARRANTY CLAIM: Thank you for purchasing your new EGLO ceiling fan. To ensure a safe and successful installation, please make sure to read this manual, ensure it is on hand for your installer to refer to, and keep in a safe place for future reference. -
Page 4: For Your Safety
17. This fan is designed for use indoors only. 18. EGLO lighting will not be liable for any advice given to the consumer from any of our suppliers or third parties, related or otherwise. 19. Proper performance relies on the right fan being correctly installed in the optimum location. Fans that do not perform as expected and which are not faulty cannot be replaced or exchanged under warranty. -
Page 5: Before Installation
Canopy Screws • If any parts are missing, carefully check the packaging, polyfoam and plastic bags for Canopy Cover the missing parts, and if they cannot be located, contact EGLO for assistance before commencing assembly or installation. Hanger Ball SPECIFICATIONS:... -
Page 6: Selecting A Location
Refer to Figure 2. 4. Many EGLO fans are designed for indoor use, though they can NOTE: Image is for representation only, also be installed in appropriately covered outdoor locations where and does not represent the actual bracket. - Page 7 Fig. 9 Fig. 8 Fig. 11 Fig. 10 4. Ensure the downrod is clamped with two screws on the coupling to prevent shaking and wobble during operation. Refer to Fig 5. 5. Re-check that all screws are properly tightened. 6. Carefully lift the fan assembly up to the hanging bracket. 7.
-
Page 8: Wiring Connections
WIRING CONNECTIONS: WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST ONLY BE UNDERTAKEN BY A QUALIFIED AND LICENSED ELECTRICIAN. Light connection (Light models only) Note: For safe use of this fan, and all-pole disconnection MUST be incorporated into the fixed wiring in accordance with the wiring rules. As outlined in clause 7.12.2 of AS/NZS 60335-1 for meeting the minimum electrical safety of this standard. -
Page 9: Operating Your Remote Control (Light Models)
OPERATING YOUR REMOTE CONTROL (LIGHT MODELS): Turns fan ON & OFF Colour Temperature: Warm White Neutral White Cool White Fan Speed: Lowest Speed Low Speed Medium Speed High Speed Highest Speed Increase Brightness (+)/ Decrease Brightness (-) Timer: - Fan turns off after 2 Hours - Fan turns off after 8 Hours Turns light ON &... -
Page 10: Cleaning And Maintenance
Your fans natural movement can cause screws to loosen. Every 6 months, check that ALL screws are securely tightened with a screwdriver. All EGLO ventilation products should be cleaned regularly to insure against corrosion from salt, dust and moisture, both externally and internal (where allowed and possible). -
Page 11: Trouble Shooting Checklist
If the measurements are different; Check that the blade screws are not overly tightened, or loose, causing the tip of the blade to be unlevelled. Out of shaped blades can unbalance the fan and cause wobble. Check by removing all blades and stacking on a flat level surface, and ensure all blades are a uniform shape. -
Page 12: Warranty Claims On Installed Products
Subject to “Your Consumer Rights“ outlined above, but otherwise to the maximum extent permitted by law, EGLO will not be liable for any consequential or indirect loss or damage suffered or incurred by you in relation to an EGLO product, including but not limited to loss of use, loss or damage for business interruption, or profits. -
Page 13: In-Home Warranty
1. The product is deemed to be a non- EGLO product, or the fault is caused by a non-EGLO controller or accessory. 2. There is nothing wrong with the EGLO product or to the extent that the failure is not a failure of the product to perform in accordance with its published features and specifications as reasonably determined by EGLO. -
Page 14: Commercial Use
15. The cost of renting, obtaining and using special access equipment (i.e. scaffoldings, scissor lifts, etc.) for accessing products installed at a height of greater than 3.0 meters. 16. Travelling costs incurred by EGLO personnel or service agents traveling greater than 25 Km from an EGLO service agent base. The purchaser must meet these traveling costs. -
Page 15: Warranty Conditions
EGLO retailer where the product was purchased. To the maximum extent permitted by law, the customer must bear the costs and expenses of claiming under this warranty, including but not limited to the cost incurred in freight, postage, handling, travel, dismantling or reinstalling the product. - Page 16 NOOSA Ceiling Fan...
- Page 17 EGLO USE ONLY Date: Electrican: Quote No.: Cost to Rectify: Approved By: Signed: Please email this form, together with a copy of your purchase receipt, and installers invoice to EGLO LIGHTING: warranty@eglolighting.com.au, or call 1800 254 448 for assistance. NOOSA Ceiling Fan...
- Page 18 EGLO LIGHTING AUSTRALIA 5/339 Archerfield Road Richlands Queensland 4077 www.eglo.com/australia Distributed by: Reduction Revolution Pty Ltd NOOSA Ceiling Fan www.reductionrevolution.com.au...
