INSTRUCTION BULLETIN
NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the Parts
List in the appropriate place in the machine manual for future reference.
Retaining the Parts List will make it easier to reorder individual parts and will
save the cost of ordering an entire kit.
NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.
Installation instructions for kit number 387548 / 9006965
SYNOPSIS:
This kit contains the parts needed to install an update/retrofit kit on the 8300 sweeper/scrubber.
Please follow step-by-step instructions.
SPECIAL TOOLS / CONSIDERATIONS: NONE
(Estimated time to complete: 5 hours)
FIELD ENGINEERING REPORT DETAILS: It is possible for water or moisture to wick itself between the
touch panel material layers. This can cause traces on the touch panel to corrode and short the
backlighting and digital system circuits. The circuit board could also be damaged.
PREPARATION:
(Refer to Fig. 1 through Fig. 6)
SECTION 1:
7300/8300 TOUCH PANEL/CIRCUIT BOARD MOISTURE / CORROSION INSPECTION: (TSB No. 017300- -00)
FOR SAFETY:
Before leaving or servicing machine, stop on level surface, set parking brake, turn off
machine, and remove key.
1. Disconnect battery cables from the batteries.
WARNING:
Always disconnect battery cables from machine before working on electrical
components.
2. Remove the touch panel from the machine instrument panel housing.
3. Remove the surrounding rubber bezel. (Refer to FIG. 1)
4. Inspect the lower outside perimeter of the touch panel assembly for green copper oxide formations. Refer to
Fig. 1.
5. Replace the touch panel assembly if excessive corrosion is found.
6. If the touch panel assembly does not need to be replaced, add clear dielectic grease (TENNANT PN# 86385)
to the lower outside perimeter of the touch panel.
7. Clean the inside channel of the bezel and attach the bezel to the touch panel assembly. Wipe any exposed
dielectic grease from the assembly surfaces.
8. Ensure the switch plugs did not pull away from switches, before reinstalling touch panel. Reconnect the touch
panel and the battery cables to the machine.
9. Check the machine functions and run the self test.
IB 340485 (03- -2010)
No. 340485
Machine: 8300
Published: 03- -2010
Rev: 01
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8300 and is the answer not in the manual?

Questions and answers

Related Manuals for Tennant 8300

Summary of Contents for Tennant 8300

  • Page 1 Fig. 1. 5. Replace the touch panel assembly if excessive corrosion is found. 6. If the touch panel assembly does not need to be replaced, add clear dielectic grease (TENNANT PN# 86385) to the lower outside perimeter of the touch panel.
  • Page 2 NOTE: If excessive corrosion is found, and a new panel must be ordered, the machine can be kept operational by disconnecting and taping 21ORA wire from the backlighting touch panel circuit (backlighting will be inoperative). This will also prevent damage to the circuit board while waiting for a new touch panel to be installed.

  • Page 3: Installation

    SECTION 2: INSTALLATION: (Refer to Fig. 2 and Fig. 3) NOTE: Machines with serial numbers after 003053 are already equipped with correct fuses and propel cable. Check all connection hardware for tightness and proceed to section 3. FOR SAFETY: Before leaving or servicing machine, stop on level surface and set parking brake.
  • Page 4 9. Connect each new 4 gauge wire (5), to each of the lower posts (S1 and S2) on the propel motor, with new nuts (6), flat washers (7), and lock washers (8) as shown in Fig. 2. Hand tighten the mounting hardware. 1.
  • Page 5 FIG. 2 - - New Cable And Hardware Installation, Propel Motor (Refer to FIG. 3 for cable routing) IB 340485 (03- -2010)
  • Page 6 FIG. 3 - - New Cable Routing, Propel Motor 9. Be sure all new motor wires are routed the same way as shown in Fig. 3. NOTE: All motor wires must be routed and tied as shown in Fig. 3. 10.
  • Page 7 Replace three 10A fuses with three new 20A fuses FIG. 4 - - Circuit Board Assembly 16. Install the circuit boards in the machine and reconnect all ribbon cables to the boards. 17. Close and secure the circuit board cover. 18.
  • Page 8 SECTION 3: MAXPRO 1000 VACUUMIZED SIDE SQUEEGEE INSTALLATION: (Refer to IB 340474 for removal and installation of new vacuumized side squeegee) 1. Install the new vacuumized side squeegee. (Refer to INSTRUCTION BULLETIN 340474) SECTION 4: MAXPRO 1000 REAR SQUEEGEE INSTALLATION: (Refer to IB 340398 for removal and installation of new MaxPro 1000 rear squeegee) 1.

  • Page 9: Side View

    FIG. 6 - - Side Brush Adjustment Screws SECTION 6: 8300 ADDITIONAL DOCUMENTATION: 1. Mount the 8300 Quick Reference Guide to the machine key chain for future reference. 2. View the 8300 video (2) for recommended operating and maintenance procedures. IB 340485 (03- -2010)
  • Page 10 Nut, hex, std, M06 X 1.0 32483 Washer, flt 0.25 SAE 32982 Washer, lock, int 0.25 603103000 Fuse, 20A, 3AG, SLO--BLO Bill Of Materials For Retrofit Kit, Iron Gray, CI [8300] - - 9006965 TENNANT Ref. Part No. Description Qty. 9006962...
