INSTRUCTION BULLETIN
NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the Parts
List in the appropriate place in the machine manual for future reference.
Retaining the Parts List will make it easier to reorder individual parts and will
save the cost of ordering an entire kit.
NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.
Installation instructions for kit numbers 83225 (12VDC) and 83253 (36VDC)
SYNOPSIS:
This kit contains the parts needed to install a backup alarm kit on the 6100 sweeper.
Please follow step-by-step instructions.
SPECIAL TOOLS / CONSIDERATIONS: NONE
(Estimated time to complete: 1 hour)
PREPARATION: BOTH KITS
1. Park the machine on a clean level surface, turn off
the machine, remove the key, and set the parking
brake..
FOR SAFETY: Before leaving or servicing
machine, stop on level surface, set parking brake,
turn off machine, and remove key.
2. Disconnect the battery cable from the machine.
WARNING: Always disconnect battery
cables from machine before working on
electrical components.
IB 340163 (08- 2015)
PROTECT THE ENVIRONMENT
Please dispose of packaging materials, used machine components
such as batteries and fluids in an environmentally safe way according
to local waste disposal regulations.
Always remember to recycle.
No. 340163
Machine: 6100
Published: 08- 2015
Rev. 05
1
Advertisement
Related Manuals for Tennant 83225
Summary of Contents for Tennant 83225
- Page 1 NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials. Installation instructions for kit numbers 83225 (12VDC) and 83253 (36VDC) SYNOPSIS: This kit contains the parts needed to install a backup alarm kit on the 6100 sweeper.
- Page 2 INSTALLATION: Kit 83225 FIG. 1- Alarm Kit, Backup, Ped, CI [6100]- 83225 1. Remove the debris hopper. Lower and remove 9. Use the hex screws (14), lock washers (7), and flat the filter to access the mounting holes for the washers (8) to mount the roller switch assembly pedestal (2).
- Page 3 INSTALLATION: Kit 83253 10. Use hardware included with the snap switch (12) Install the switch onto the propel pedal. (Fig. 2 / NOTE: If machine is not equipped with the optional Fig. 3) vacuum wand, refer instructions on previous page to install the backup alarm to the pedestal (2).
- Page 4 Vacuum wand assembly FIG. 3- Alarm Kit, Backup, CI [6100]- 83253 IB 340163 (08- 2015)
- Page 5 FIG. 4 Yellow Blue Brown Black Yellow FIG. 5 IB 340163 (08- 2015)
- Page 6 Bill of Materials for Alarm Kit, Backup, Ped, CI [6100] - 83225 Tennant Ref. Part No. Description Qty. 83225 Alarm Kit, Backup, Ped, CI [6100] 9007131 Alarm Assy, Backup, 12- 24VDC 82- 107DBA 384400 Pedestal, Mtg, Light, Flsh 1027395 Duct, Vyl, 0.73 X 0.75 .50d 48.0l 16735 Screw, Hex, M8 X 1.25 X 16, 8.8...
