IOM1710 Input/Output Module
Installation Instructions
MS-IOM1710-0
Applications
The Input/Output Module (IOM) 1710 is a member of
the Metasys® system Field Equipment Controller
(FEC) family. The IOM controller provides increased
capacity to larger FEC applications when used on the
Sensor Actuator (SA) Bus. The IOM controller can also
be used on the Field Controller (FC) Bus to connect
additional physical points to the system.
IMPORTANT: In Metasys system smoke control
applications, use only the IOM1710 models that are
UL Listed, UUKL 864 Listed, Smoke Control
Equipment. See Repair Information on page 6 for
UUKL 864 Listed IOM1710 models. For Metasys
system smoke control applications, you must refer to
the Metasys System UL 864 UUKL Ninth Edition
Smoke Control System Technical Bulletin
(LIT-12011252) for detailed requirements and
procedures for installing and operating UUKL 864
Listed Metasys system devices. Failure to meet the
requirements or follow the procedures in the
Metasys System UL 864 UUKL Ninth Edition Smoke
Control System Technical Bulletin (LIT-12011252)
can void the UUKL 864 listing for Smoke Control
Equipment.
North American Emissions Compliance
United States
This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when this equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference, in which case
the user will be required to correct the interference
at his/her own expense.
Canada
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte
toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
Installation
Observe the following guidelines when installing the
IOM controller:
•
Transport the IOM controller in the original
container to minimize vibration and shock damage
to the IOM.
•
Do not drop the IOM controller or subject it to
physical shock.
Materials and Special Tools Needed
You need either of the following items to install the IOM
controller:
•
three fasteners appropriate for the mounting
surface (#8 screws or M4 screws)
•
one 20.3 cm (8 in.) or longer piece of DIN rail and
appropriate hardware for mounting the DIN rail
Mounting
Follow these guidelines when mounting an IOM
controller:
•
Ensure that the mounting surface can support the
IOM controller and any user-supplied enclosure.
•
Mount the IOM controller in the proper orientation.
See the Wall Mount Applications and DIN Rail
Mount Applications section.
•
Mount the IOM controller on an even surface
whenever possible.
•
Use shims or washers to mount the unit securely
on the mounting surface.
•
Mount the IOM controller in areas free of corrosive
vapors and observe the environmental limitations
listed in the Technical Specifications section.
IOM1710 Input/Output Module Installation Instructions
Part No. 24-10144-9, Rev. G
Release 5.0
Issued January 4, 2010
Supersedes October 6, 2008
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Johnson Controls MS-IOM1710-0
Summary of Contents for Johnson Controls MS-IOM1710-0
- Page 1 IOM1710 Input/Output Module Installation Instructions Part No. 24-10144-9, Rev. G MS-IOM1710-0 Release 5.0 Issued January 4, 2010 Supersedes October 6, 2008 Applications Canada The Input/Output Module (IOM) 1710 is a member of This Class (A) digital apparatus meets all the the Metasys®...
-
Page 2: Wall Mount Applications
• Do not mount the IOM controller on surfaces that are prone to vibration, such as duct work, or in (4-1/4 ) areas where electromagnetic emissions from other devices or wiring can interfere with IOM controller (2.13 ) (2.13) communication. •... -
Page 3: Din Rail Mount Applications
DIN Rail Mount Applications To wire the IOM controller: To mount the IOM controller on a DIN rail: 1. Terminate wiring per engineering drawings. 1. Securely mount the section of DIN rail horizontally 2. If the IOM is connected to the FC Bus of a Network and centered in the required space. - Page 4 SA/FC Bus Port Sensor, SA Bus, or FC Bus Port (RJ-12 Modular Jack) The SA/FC Bus port on the front of the IOM is an RJ-12, 6-position modular jack that provides a connection for the Wireless Commissioning Converter SA or FC Bus + (MS-BTCVT).
-
Page 5: Setup And Adjustments
See Figure 8. Setup and Adjustments Table 3 shows the valid FC Bus and SA Bus device addresses for FECs and IOMs on Johnson Controls® The IOM controller can reside on either the FC Bus or MS/TP communications bus applications. -
Page 6: Troubleshooting
If the IOM controller fails to operate within its Use Table 5 to order accessories for the IOM controller. specifications, replace the unit. For a replacement IOM controller, contact the nearest Johnson Controls® representative. Table 5: FEC and IOM Accessories (Order Separately) (Part 1 of 2) -
Page 7: Technical Specifications
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products. - Page 8 507 E. Michigan Street, Milwaukee, WI 53202 Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc. All other marks herein are the marks of their respective owners. © 2010 Johnson Controls, Inc. IOM1710 Input/Output Module Installation Instructions Published in U.S.A.
