Cochlear
Freedom
Behind the ear
Transmitting coil
fits here.
selector button
screen
decrease/
increase buttons
BTE controller
Two microphones are situated
on top of the processor
Accessories
socket is situated
on base of
controller
Transmitting
cable and coil
Key to screen messages
P1
Program 1 currently in
use
M
Microphones are in
operation
T
Sound is being heard
through telecoil only.
MT
Sound is being heard
through microphone and
telecoil
S
Sensitivity level currently
displayed (0-20,
recommended = 12)
V
Volume level currently
displayed (0-9,
recommended = 9)
H
Help message (See
troubleshooting)
L
Button lock is in
operation
EA
Indicates an accessory
has been connected
Processor unit
earhook
Accessories socket
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cochlear Freedom
Summary of Contents for Cochlear Freedom
-
Page 1: Behind The Ear
Transmitting cable and coil Cochlear Freedom Processor unit Behind the ear BTE controller earhook Accessories socket Two microphones are situated on top of the processor Key to screen messages Transmitting coil Program 1 currently in fits here. Microphones are in... - Page 2 Batteries only fit one way, there is no need to force them (top down, opposite to 3G!). Replace all three at once. Replace the battery compartment and make sure it clicks into place. A rechargeable battery pack is also available from Cochlear which fits into the same compartment. Microphone Protector...
- Page 3 How to: Turn on and off Press and hold selector button for a few seconds until display shows current program. Change program Push the selector button briefly, continuing until the correct P number is on screen Change sensitivity Press increase or decrease button once. The letter ‘S’...
- Page 4 • FM cables These connect into the accessories socket at the base of the Freedom Processor. Lift the flap with your fingernail and then plug the accessory into the socket You then need to press both the increase and decrease buttons at the same time.
