  • Page 1 Bright Installation Guide...
  • Page 2 General < < < <...
  • Page 3 > > > >...
  • Page 4 Bright Build-in frame < < < <...
  • Page 5 (De)mounting the Glass > > > >...
  • Page 6: Table Of Contents

    Appendix A: Example calculation..............16 Appendix B: Flue restrictor................17 Appendix C: Installation of the flue..............18 Appendix D: Technical specifications Flatburner ..........19 Appendix E: Dimensions Bright................ 20 Appendix F: Dimensions Convection grid............21 Appendix G: Dimensions Service hatch .............. 22 <...
  • Page 7: Introduction

    Note: these instructions should be read carefully and retained for future reference. Please leave these instructions with the user. • The Bright can be build on all desired heights • The Bright is only in a frameless configuration available. Special features: •...
  • Page 8: Safety And General Information

    2 Safety and general information Before installation, ensure that the local distribution conditions (identification of the type of gas and pressure) and the adjustment of the appliance are compatible. This gas appliance is factory set and can not be adjusted. This appliance does not contain any component manufactured from asbestos or any asbestos related products.
  • Page 9: Installation Requirements

    • always ventilate the space above the appliance. Use a Faber ventilation grid. • to avoid cracking, the plaster has to dry for at least 1 day per millimetre plaster •...
  • Page 10: Flue Requirements

    The appliance is of the type C11/C31. The appliance will need to be supplied with the approved Faber flue pipes and terminal, it is not possible to supply your own. The minimum effective height of the flue system must be 1 meter.
  • Page 11: Using An Existing Chimney

    • Some important requirements for a good functioning are • The wall-mounted terminal has to be at least 0,5 m off: Corners of the building Below eaves Balcony's etc. The roof mounted terminal has to be at a distance of at least 0.5 meters of the sides of the roof, excluded the ridge Using an existing chimney.
  • Page 12: Instruction For Installation

    4 Instruction for Installation Gas Connection • Installation pipes should be in accordance with BS 6891. Pipe work from the meter to the appliance must be of adequate size. • The complete installation including the meter must be tested for soundness and purged as described in the above code.
  • Page 13: Building The False Chimney Breast

    Building the False Chimney Breast. Use the Build-in frame mounted on the front of the appliance as guide (fig. 2.1). Use Promatec, Ytong or a similar non combustible material. Service hatch • The gas valve is for transport assembled on the side of the appliance. Demount it and place the gas valve together with the valve support on an chosen place near the fire behind the service hatch ( max 1m away).
  • Page 14: Commissioning (Functional Checks)

    5 Commissioning (functional checks) Pilot ignition check • Ignite the pilot light as described in the user manual • Check if the pilot burner stays alight • Extinguish the pilot burner Check functional burner and pilot burner The appliance is preset to give the correct heat input. No further adjustment is necessary. Always check the inlet pressure and burner pressure: •...
  • Page 15: Handing Over (Final Check And Customer Briefing)

    6 Handing over (final check and customer briefing) Instruct the customer on the full operation of the appliance and the remote control, including replacement of batteries Advise the customer how to clean the appliance including the glass Hand over these instructions including the user guide to the consumer Recommend that the appliance should be serviced by a competent person at least once a year 7 Servicing...
  • Page 16: Cleaning The Combustion Chamber And Burner

    Attention: Before placing the glass: check the glass sealing rope is in good condition and makes an effective seal. Be sure that there are no fingerprints on the glass. It is not possible to remove those prints after you burn the appliance for a while (they are burnt in). Place the glass in front of the appliance and fix the glass frame or use the glass clamps.
  • Page 17: Appendix A: Example Calculation

    Appendix A: Example calculation Calculation 1: Calculating horizontal extension fig. 2a: Flue length C + E = 1m + 1m Elbows D = 2m Total horizontal extension Measure or calculate effective height (Hvert) Flue length A Roof mounted terminal Total effective height Always check if the calculated situation is allowed (see appendix B: Flue restrictor) Calculation 2:...
  • Page 18: Appendix B: Flue Restrictor

    Determine according to the table the right flue restrictor size • When meeting an X, and when the values are outside the table, the combination is not allowed • Normally the 30 mm flue restrictor is pre-installed Horizontal length (m) Bright 17 < < < <...
  • Page 19: Appendix C: Installation Of The Flue

    Appendix C: Installation of the flue Connection with use of concentric duct material Make a hole of ø 153 mm for the wall or roof mounted terminal. The horizontal pipes need to rise away from the appliance at a rate of 3 degrees per metre Build the system starting from the appliance on.
  • Page 20: Appendix D: Technical Specifications Flatburner

    Appendix D: Technical specifications Flatburner Flatburner Flatburner Country UK / IRL UK / IRL II 2E+3+ II 2H3+ Appliance type C11 of C31 C11 of C31 Reference gas Input (Nett) Efficiency class Inlet pressure Mbar Gas rate* Gas rate* gram/h Working pressure (high) Mbar 11.0...
  • Page 21: Appendix E: Dimensions Bright

    Appendix E: Dimensions Bright > > > >...
  • Page 22: Appendix F: Dimensions Convection Grid

    Appendix F: Dimensions Convection grid 21 < < < <...
  • Page 23: Appendix G: Dimensions Service Hatch

    Appendix G: Dimensions Service hatch > > > >...
