- Page 1 Doc. no.SX10-OMR0002-A PRODUCT NAME High Speed 2 Port Valve MODEL / Series / Product Number SX10 Series...
-
Page 2: Table Of Contents
Contents Safety Instructions ····················································································· 2,3 Design ······································································································ 4 Selection ··································································································· 4 Mounting ··································································································· 4 Wiring······································································································· 4 Lubrication ································································································· 5 Air Supply ·································································································· 5 Operating Environment ················································································· 5 Maintenance ······························································································· 5 Precautions ································································································ 6 Continuous Energization ················································································ 6 Energizing Time and Non-Energizing Time························································· 6 Others ·······································································································... -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Safety Instructions
Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch. -
Page 5: Design
SX10 Series Precautions 1 Be sure to read this before handling. Design/Selection 2. Low temperature operation When using the valve in a low temperature condition, take appropriate measures to avoid freezing of the drainage, 1. Review the specifications. moisture, etc. at low temperatures. Unless specified, the valve The product is designed for use only in compressed air systems. -
Page 6: Lubrication
SX10 Series Precautions 2 Be sure to read this before handling. Lubrication Operating environment 1. Lubrication 1. Do not use in an environment where corrosive gases, chemicals, sea water, water or steam are present. Do not supply oil. Air Supply 2. -
Page 7: Precautions 3
SX10 Series Precautions 3 Be sure to read before using. Lead Wire Connection Precautions 1. Valves will reach high temperatures during Connect the lead wires to those specified. operation. Lead wire color Use caution, as there is a danger of being burnt if a valve is touched directly. -
Page 8: Control Method
SX10 Series Precautions 4 Be sure to read before using. Control Method (Operation example with an energy saving driver circuit) 1. Control with 2 power supplies, starting power supply and holding power supply Switching system from high voltage to low voltage 2. -
Page 9: Trouble Shooting
SX10 Series Trouble shooting If any failure is found during operation, please check and take measures in accordance with the procedure below. Phenomenon Possible causes Countermeasure Flow does not start. Non-conformance of electric system Check each part and take corrective - Incorrect wiring actions for the failed part. -
Page 10: Trouble Shooting
SX10 Series Trouble shooting Delay in ON response Check the supply voltage. Take corrective Voltage drop actions if voltage drop is confirmed. Keep the voltage at +24 VDC, +/-5%. Check if the supply pressure is out of the Supply pressure is too high. - Page 11 Revision ARENEWAL 2018.8 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2018 SMC Corporation All Rights Reserved No.SX10-OMR0002-A...
