- Page 1 Operating instructions AdoraDish V2000 Dishwasher...
- Page 2 AdoraDish V2000 AS2T-41094 SMS 55 AdoraDish V2000 AS2T-41106 EURO 60 AdoraDish V2000 AS2T-41107 EURO 60 AdoraDish V2000 AS2T-41108 EURO 60 AdoraDish V2000 AS2T-41109 EURO 60 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2020...
-
Page 3: Table Of Contents
Contents Wipe protection ............. 33 Safety warnings 4 Information ............. 33 Symbols used............ 4 V-ZUG-Home 34 General safety precautions........ 4 Appliance-specific safety precautions .... 5 Conditions .............. 34 Instructions for use.......... 6 Initial set-up............ 34 Using for the first time 8... -
Page 4: Safety Warnings
Safety warnings Symbols used General safety precautions Denotes important safety precau- tions. Failure to observe said precautions ▪ Read the operating instruc- can result in injury or in damage to tions before using the appli- the appliance or fittings! ance for the first time. Information and precautions that should be observed. -
Page 5: Appliance-Specific Safety Precautions
1 Safety warnings ently installed electrical install- ▪ No detergent must enter the ation in accordance with the opening of the door lock. This installation regulations. can cause the door lock to ▪ If the mains cable of this ap- malfunction. -
Page 6: Instructions For Use
1 Safety warnings ▪ Before closing the appliance door and Instructions for use starting a programme ensure that there Before using for the first time are no foreign objects or pets in the ap- ▪ The appliance must be installed and pliance. - Page 7 1 Safety warnings Caution: Risk of injury! ▪ Do not lean on any part of the appli- ance – risk of accident! ▪ Keep pets away from the appliance. Caution: Risk to life! ▪ Packaging material, e.g. plastic film and polystyrene, can be dangerous for chil- dren.
-
Page 8: Using For The First Time
Using for the first time The appliance must be installed and connected to the electricity supply by a quali- fied fitter/electrician in accordance with the separate installation instructions. Before using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸... -
Page 9: Appliance Description
3 Appliance description Appliance description Construction Interior Upper basket Spray arms Lower basket «Large» cutlery basket Rinse agent reservoir Detergent dispenser Salt reservoir Filter system Appliance door For integrated models, the operating and display elements are located on the outside of the appliance door. -
Page 10: Operating And Display Elements
3 Appliance description Operating and display elements Main menu Buttons Display Programmes (see page 13) V-ZUG-Home Frequently used user settings (see page 15) Navigation elements Other user settings (see page 35) Programme selected Intensive 1h15 70° Buttons Displays Back arrow button... -
Page 11: Functionlight
3 Appliance description Button state Non-selectable functions Function selected Selectable functions Non-selectable navigation elements Action elements Increase value Decrease value Activate user setting Deactivate user setting Cancel entry, confirm message Start permanent mode programme, empty storage tank Navigation elements Go back to the previous menu Display other functions in the menu Display other functions in the menu Display other selection options in the menu... - Page 12 3 Appliance description Final drying phase During the final drying phase, all 6 LEDs illuminate orange and pulsate between dimmed and undimmed. Delayed start When the appliance door is closed and a delayed start is started, all 6 LEDs illuminate dimmed white. Programme-independent appliance reactions In the case of the following appliance reactions, all 6 LEDs illuminate white and pulsate between dimmed and undimmed:...
-
Page 13: Functions
4 Functions Functions Selection buttons enable the user to select and start frequently used programmes simply and quickly at the touch of a button. The user can create and change a selection button for any favourite programme and thus adapt it perfectly to their own work processes. Programmes Consumption values The programme time (h), water consumption (l) and energy consumption (kWh) are in-... -
Page 14: Setting Options
4 Functions Glass Programme phases Consumption values Gentle programme for glasses. ▪ Cleaning: 45 °C ▪ 0h39 ▪ Intermediate rinsing ▪ 11 l ▪ Rinsing with rinse ▪ 0.8 kWh agent: 60 °C ▪ Drying Quick Programme phases Consumption values For lightly soiled dishes. ▪... -
Page 15: Frequently Used User Settings
4 Functions Frequently used user settings Childproof lock The «Childproof lock» user setting prevents a programme from being started accident- ally. If the childproof lock is turned on, it can be overridden by entering the four-digit code (1223). The code is set at the factory and cannot be changed. All in 1 The «All in 1»... -
Page 16: Loading
5 Loading Loading Preparing the appliance ▸ Remove any coarse or hard pieces of food or foreign objects (such as toothpicks) left on the dishes. ▸ Load the baskets. After loading, check that the spray arms can turn freely. Loading tips for the lower basket Overloading the basket can damage the appliance! Do not exceed the maximum loading weight for the lower basket of 21 kg. - Page 17 5 Loading Loading the cutlery basket Risk of injury from being loaded incorrectly! Place knives and cutlery with sharp edges or points into the cutlery basket with the points facing downwards. Make sure that they do not stick out of the cutlery bas- ket.
-
Page 18: Loading Tips For The Upper Basket
5 Loading Loading tips for the upper basket Overloading the basket can damage the appliance! Do not exceed the maximum loading weight for the upper basket of 9 kg. Loading smaller items ▸ Arrange smaller items such as saucers, glasses, cups and dishes. ▸... - Page 19 5 Loading Loading tall glasses For tall glasses, use glass holders and racks for greater stability. Remove the racks to accommodate tall glasses. Glass holder ▸ Pull the glass holders 1 gently up until they engage. ▸ Rest tall glasses on the glass holder. Rack ▸...
- Page 20 5 Loading Adjusting the upper basket Depending on the model, the height of the upper basket can be adjusted by around 2–4 cm. It can be inclined in various ways. ▸ Hold the upper basket at the sides by the grips 1 and raise it into the desired engaged position.
-
Page 21: Operation
6 Operation Inserting the upper basket ▸ Extend the rails 1 as far as they will go. ▸ Slide the upper basket on to the rails 1 in such a way that the rollers 2 of the up- per basket come to rest on the rails. ▸... -
Page 22: Selecting Detergent
6 Operation Selecting detergent General note Do not use washing-up liquid! Strong foaming can cause the appliance to malfunc- tion. Follow the dosage instructions printed on the detergent packaging exactly. Should you have any questions, please contact the detergent manufacturer. Using too high or too low a dosage can cause damage to the appliance. -
Page 23: Adding The Detergent
6 Operation Adding the detergent Ensure no cleaning agent gets into the opening of the door lock. This can cause the door lock to malfunction. Powder ▸ Open the detergent dispenser 2 by push- ing the release catch 1 in the direction of the arrow. -
Page 24: Operating The Display
6 Operation Operating the display Programmes, setting options, user settings, permanent mode and favourites can be se- lected by touching or holding depressed the relevant buttons. Touching a button Briefly touching a selectable or selected button enables the user to ▪... -
Page 25: Selecting And Starting A Programme
6 Operation Selecting and starting a programme Selecting a programme ▸ Touch the dark display. – The start screen appears. ▸ On the start screen, touch the button repeatedly until the desired programme ap- pears. ▸ Touch the desired programme, e.g. –... -
Page 26: Adding Extra Dishes
6 Operation Adding extra dishes The dishes and water may be hot. Scalding hazard! ▸ Open the appliance door carefully. – This interrupts the programme. – The interrupted programme alternates in the display with the «Close the door» mes- sage. Intensive 0h35 1h15... -
Page 27: Unloading Dishes
6 Operation Unloading dishes The dishes can be unloaded either at the end of the programme or when the final drying phase finishes. For optimum drying results, it is recommended that the appliance only be unloaded after the final drying phase has finished. End of programme and final drying phase When the programme has finished, –... -
Page 28: Programme Options
7 Programme options Programme options Delayed start The delayed start allows you to wash during off-peak hours (e.g. at off-peak electricity rates). It can be set briefly after selecting a programme. A delayed start of between 30 minutes and 24 hours can be set. Setting the delayed start duration ▸... -
Page 29: Programme In Permanent Mode
7 Programme options Programme in permanent mode Only one programme can be used in permanent mode. When the appliance door is opened, the programme appears on the start screen and can be started immediately. A programme used in permanent mode can be deleted at any time. Saving a programme as permanent mode ▸... -
Page 30: Favourites
7 Programme options Favourites Up to 5 programmes with or without setting options can be saved as favourites. Pro- grammes saved as favourites appear on the start screen after the «Eco» programme and can be deleted at any time. Creating favourites without setting options This function is suitable for displaying programmes on the start screen that are not displayed on it by default. -
Page 31: Permanently Selecting Setting Options
7 Programme options Using favourites in permanent mode ▸ On the start screen, touch the button repeatedly until the desired favourite appears. ▸ Hold the button for the desired favourite, e.g. , depressed until the buttons appear in the display next to the favourite selected. ▸... -
Page 32: Childproof Lock
7 Programme options Temporarily turning off a permanent setting option ▸ Touch the desired programme, e.g. – The programme selected appears in the display. Intensive 1h15 70° ▸ Touch the button. – A selection of setting options appears in the display. ▸... -
Page 33: All In 1
7 Programme options Deactivating ▸ On the start screen, touch the button repeatedly until the frequently used user set- ting «Childproof lock» appears. ▸ Touch the button. ▸ Touch the button. – The childproof lock is deactivated. All in 1 Activating ▸... -
Page 34: Zug-Home
– A bluetooth pairing request appears in the V-ZUG App. – A 6-digit PIN appears in the display of the appliance. ▸ Enter the 6-digit PIN in the V-ZUG App and confirm the bluetooth pairing request. – All available wireless networks appear in the V-ZUG App. -
Page 35: User Settings
9 User settings User settings Changing the user settings The user settings can be changed at any time. ▸ On the start screen, touch the button repeatedly until «User settings» appears. ▸ Touch the button. – The user settings menu appears. ▸... - Page 36 9 User settings Rinse agent dosage Selection The rinse agent dosage is automatically ▪ Automatic (factory setting) justed to the load and the water hardness. If ▪ Level 1–12 the drying result is unsatisfactory, the dosage ▪ can be set manually to one of 12 levels.
- Page 37 : Deactivated (factory setting) trieve and change the user settings or retrieve various statistics about your household appli- ances. Further information can be found in the V-ZUG-Home operating instructions or on home.vzug.com. Hot water connection Selection If the appliance has a hot water connection ▪...
-
Page 38: Care And Maintenance
10 Care and maintenance Care and maintenance 10.1 Cleaning the interior and exterior Cleaning the interior Using the correct dosage of detergent will automatically clean the interior of the appli- ance. The appliance should be additionally cleaned twice a year with dishwasher cleaner. -
Page 39: Cleaning The Filter System
10 Care and maintenance 10.3 Cleaning the filter system Only use soft materials for cleaning beneath the filter system. Never use metal ob- jects. An incorrectly assembled filter system can cause the appliance to malfunction. ▸ Open the appliance door and pull out the lower bas- ket. -
Page 40: Filling With Rinse Agent
10 Care and maintenance Approximate consumption of regeneration salt The consumption of regeneration salt depends on the hardness of the water supply. The lower the water hardness, the greater the number of wash cycles per kg of regeneration salt. Wash cycles per kg ∞... -
Page 41: Trouble-Shooting
11 Trouble-shooting Trouble-shooting You may be able to trouble-shoot the following errors yourself. If not, note down the error message in full and the serial number (SN), which can be found on the identification plate, and call Customer Services. 11.1 Error messages In the event of error messages follow the instructions on the operating panel. - Page 42 11 Trouble-shooting Display Possible cause Solution F… /E… ▪ Various situations can ▸ Cancel the error message by press- lead to an «F» mes- ing the button. see instructions / sage. SN XXXXX XXXXXX If the error message persists: ▸ Switch the power supply off for about 1 minute.
-
Page 43: Other Possible Problems
11 Trouble-shooting 11.2 Other possible problems Problem Possible cause Solution The appliance will ▪ There could be several ▸ Close the appliance door. not start. reasons for this. ▸ Insert plug into mains socket. ▸ Check the fuse or circuit breaker. ▸... -
Page 44: Unsatisfactory Washing Results
11 Trouble-shooting 11.3 Unsatisfactory washing results Problem Solution The dishes are not ▸ Select a more powerful programme. clean. ▸ Load the baskets differently (see page 16), avoiding blind spots. ▸ Clean the filter system and re-insert correctly (see page 39). ▸... -
Page 45: In The Event Of A Power Failure
12 Accessories and spare parts Problem Solution There is discolour- Dishes that still had discolouring food leftovers (e.g. tomato or ing of the baskets curry sauce) on them or silver cutlery were washed. The discoloura- and plastic parts tion may fade after a few wash cycles. inside the appli- ance. -
Page 46: Spare Parts
13 Technical data 12.2 Spare parts Filter system Technical data Dimensions SMS 55 SMS 55 EURO 60 EURO 60 Extra height Extra height Appliance height 756 mm 827 mm 756 mm 827 mm (incl. slide plate 3 mm) Appliance height – 845–893 mm 780–828 mm 845–893 mm (incl. adjustable plinth) Appliance width 546 mm 546 mm... -
Page 47: Product Fiche
13 Technical data 13.3 Product fiche In accordance with EU Regulation No. 1059/2010 Brand V-ZUG Ltd Model identifier (the first 5 alphanumerics of the 41091 41106 serial number (SN)) 41093 41107 41094 41108 41109 Rated capacity in standard place settings for the... -
Page 48: Disposal
14 Disposal Disposal 14.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 14.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸... -
Page 49: Index
Index Operating ............ 24 Unlocking ............ 32 A messages ............41 Wipe protection.......... 15 Aborting Disposal............. 48 Programme ........... 26 Door handle ............9 Acoustic signal ..........35 DryPlus............... 14 Alert tone ............35 All in 1............15, 22 Activating............ 33 Easy care Deactivating .......... - Page 50 Initial set-up ............8 Using in permanent mode ...... 29 Validity..............2 Queries .............. 51 Vario cutlery basket insert......45 Quick programmes V-ZUG App ............34 Quick.............. 14 V-ZUG-Home Activating............ 37 Rack ............19, 45 Regeneration salt Water hardness ..........36 Consumption ..........
-
Page 51: Service & Support
Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements. - Page 52 Select programme Close appliance door: At end of final drying: programme starts unload dishes 1065806-R02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
