  • Page 1 V-ZUG Ltd Dishwasher Integrated Adora S Operating instructions...
  • Page 2 These operating instructions apply to the models: Model Type Model no. Norm Adora 55 S GS55Si/-c SMS 55 Adora 55 S GS55S-Gi/-c SMS 55 Adora 60 S GS60Si/-c EURO 60 Adora 60 S GS60S-Gi/-c EURO 60 © V-ZUG Ltd, CH-6301 Zug, 2009...

  • Page 3: Table Of Contents

    Contents Safety precautions Before using for the first time ..... . . Correct use ........Children in the home .
  • Page 4 … Contents Care and maintenance General cleaning ....... . . 43 Cleaning the exterior of the appliance .

  • Page 5: Safety Precautions

    Safety precautions The appliance corresponds to recognised technology standards and the relevant safety regulations. Proper use of the appliance is however essential to avoid damage and accidents. Please therefore follow the precautions given in these operating instructions. In accordance with the requirements of IEC 60335-1: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless supervised or unless they have been given instruction...

  • Page 6: Correct Use

    … Safety precautions Correct use The appliance is only suitable for washing household dishes and cutlery with water and standard dishwasher detergent. It is designed for use in the home and the above-mentioned purpose only. No liability is assumed for any damage caused by improper or incorrect use.

  • Page 7: Children In The Home

    … Safety precautions Children in the home Packaging material (e.g. plastic, polystyrene) can be dangerous for chil- dren. Danger of suffocation! Keep packaging material away from children. The appliance is designed for use by adults who are familiar with these op- erating instructions.

  • Page 8: Note On Use

    … Safety precautions Note on use Switching off the power to the appliance disables the built-in over- flow protection system. Do not use the appliance if visibly damaged or any of the connections are damaged. Contact Customer Services. In the event of any defects or faults, contact Customer Services. If the appliance is not operating properly, turn off the water tap and discon- nect the appliance from the electricity supply immediately.
  • Page 9 … Safety precautions Never fill the rinse agent reservoir or the regeneration salt reservoir with de- tergent. If this were to happen, however, do not operate the appliance un- der any circumstances, as this could cause expensive damage to it. Please contact our service centre, which can be found in the 'Repair service' section.

  • Page 10: Your Appliance

    Your appliance Appliance description Capacity: 12 place settings 7 programmes «Daily wash» «Quick wash/Glass care» «Fondue/Raclette» «Intensive» «Pre-wash» «Normal/Standard» «Hygiene» Additional functions «Energy saver» «Wash upper basket only» «Delayed start» 3in1 detergent Childproof lock Overflow protection 4-digit digital display Automatic limescale sensor Automatic rinse aid dosage Air fan drying...

  • Page 11: Construction

    … Your appliance Construction Door handle Operating and display elements Appliance door Baskets Salt reservoir Coarse and fine filters Rinse aid reservoir Detergent dispenser Quick programme guide 10 Cutlery basket 11 Spray arms...

  • Page 12: Operating And Display Elements

    … Your appliance Operating and display elements Programme selection buttons Programme selection with indicator light Energy saver with indicator light Wash upper basket only with indicator light Delayed start End of programme with indicator light Digital display Display for: Programme duration/Programme time remaining Delayed start Childproof lock Wash temperature (during the «Cleaning»...
  • Page 13 … Your appliance Indicator lights Indicator lights flash Select programme(s) or function(s). Indicator light for «End of programme» flashes The programme has finished. Indicator lights are illuminated Programme(s) or function(s) is (are) active. Indicator lights are not illuminated Programme(s) or function(s) is (are) inactive.

  • Page 14: Programme Overview

    Programme overview Programme/Symbol Type of soiling Daily wash For normal soiling. Not suitable for burned-on or dried-on food. Quick wash/Glass For light soiling, aperitif dishware and coffee cups. Not suitable for slowly dissolving tabs. Fondue/Raclette For heavy soiling and burned-on food, especially cheese (fondue and raclette pans), casserole and gratin dishes.
  • Page 15 … Programme overview Programme sequence/Consumption data Pre- Intermedi- Rinse Dura- Cleaning Drying Water Energy wash ate wash tion 55 °C 65 °C 1h10 14 l 1.1 kWh 45 °C 60 °C 0h45 12 l 0.9 kWh 65 °C 65 °C 2h25 19 l 1.6 kWh...

  • Page 16: Additional Functions

    … Programme overview Additional functions In addition to the main programmes, two additional functions «Wash upper basket only» and/or «Delayed start» may be selected. The «Energy saver» function can only be selected in combination with the programmes. Function/Symbol Energy saver Reduces the wash temperature at the «Cleaning»...

  • Page 17: Fondue/Raclette Programme

    … Programme overview Fondue/Raclette programme Uses Removes cheese which tends to stubbornly stick to fondue and raclette pans and dishes. Removes food burned on to gratin dishes. Can be used to clean all other dishes. Tips for best results Fondue pans made of enamelled metal or stoneware may be cleaned in the appliance.
  • Page 18 … Programme overview Load raclette dishes in the upper basket as shown in the diagram. Add about a tablespoon of detergent to the pre-rinsing compartment in addition to the detergent in the detergent dispenser. This will im- prove the wash results for heavily burned-on food. Use an aluminium heat distribution plate between the burner and the fondue pan to protect the fondue pan and to help prevent food from burning on.

  • Page 19: User Settings

    User settings You can change certain user settings to suit your own preferences. Settings can only be changed when there is no programme running. The procedure is the same for all settings. To access the configuration mode Hold the button depressed for 5 seconds. –...

  • Page 20: 3In1 Detergent

    … User settings 3in1 detergent setting adapts the wash programmes for 3in1 detergent in an opti- mal way. 3in1 products can generally only be used up to a certain water hardness. When the refill indicators light up, the appliance needs to be re- filled with regeneration salt or rinse aid.

  • Page 21: Childproof Lock

    … User settings Childproof lock The childproof lock is to prevent children accidentally starting or stopping a programme. Switching the childproof lock ON/OFF Hold the button depressed for 5 seconds (to access the configuration mode). Press the button 2×. – appears in the digital display for childproof lock OFF (factory setting).

  • Page 22: Water Hardness

    … User settings Water hardness The built-in water softener removes limescale from the water, enabling prob- lem-free cleaning. Automatic regeneration occurs at regular intervals, thus guaranteeing its effectiveness. Your appliance is equipped with an automatic limescale sensor. Configuring the level of water hardness is therefore not nec- essary.

  • Page 23: Rinse Aid Dosage

    … User settings Rinse aid dosage The rinse aid dosage is automatically adjusted to the load level and the water hardness. If the drying result is unsatisfactory, then the dosage can be adjust- ed manually between for «OFF» to for «Level 12». If the dishes are still wet or there are water spots, set the rinse aid dosage «Level 4»...

  • Page 24: Operation

    Operation Preparing the appliance Open the appliance door Pull the handle towards you. – Any programme that is running will be automatically interrupted. Before using for the first time Turn the power on. Turn the water tap on. Fill the salt reservoir with approximately 1.5 l water and 1 kg regeneration salt.

  • Page 25: Loading The Appliance

    … Operation Loading the appliance Not all dishes and cutlery are dishwasher-safe: Follow the tips and advice in the 'Dishwashing tips' section. Remove any large or hard pieces of food or foreign objects left on the dish- es or cutlery. Make sure no toothpicks get into the appliance.

  • Page 26: Loading Tips For The Upper Basket

    … Operation Loading tips for the upper basket Slide the upper basket out as far as possible and load with smaller items such as saucers, glasses, cups and dishes. If using the foldable racks, stagger the items so that the water can reach the dirty surfaces better.
  • Page 27 … Operation Glass holder The height of the glass holder 2 in the upper basket is adjustable. The bar can also be pivoted. The glass holder can be put in one of three standard rest positions. For optimal drying results, pivot the glass holder into the uppermost position.
  • Page 28 … Operation Easy prongs The easy prongs 1 can be placed over the prongs anywhere in the upper basket. By using the easy prongs, standard drinking glasses, baby bottles, sports bottles, vases and carafes can be placed anywhere in the basket. Use two easy prongs for larger objects.
  • Page 29 … Operation Adjustable upper basket The height of the upper basket can be adjusted on both sides or just on one side by approximately 4 cm. Raising the upper basket Hold the upper basket around the height adjustment lever 1. Place thumbs on the height adjustment levers.

  • Page 30: Loading Tips For The Lower Basket

    … Operation Loading tips for the lower basket Slide the lower basket out as far as possible and load. Load larger items such as plates, bowls, platters, pots and pans. Stack soup plates 1 in the rack at the back. Very large plates 2 can be loaded diagonally.
  • Page 31 … Operation Foldable racks The racks can be folded down to create a larger area for loading e.g. large plates, pans, dishes or a number of cups and glasses. Easy prongs The easy prongs can be placed over the prongs anywhere in the lower basket. By using the easy prongs, standard drinking glasses, baby bottles, sports bottles, vases and carafes can be...
  • Page 32 … Operation Cutlery basket Due to risk of injury, place knives and cutlery with sharp edges or points into the cutlery basket in such a way that they do not stick out (points facing downwards). Knives and cutlery with sharp edges or points may also be placed hor- izontally in the upper basket.

  • Page 33: Adding Detergent

    … Operation Adding detergent Powder Open the detergent dispenser by pressing the latch in the direction of the arrow. Add the detergent to the detergent compartment. For dosage, follow the detergent manufacturer’s instructions. Observe the «20 ml and 30 ml» level marks 1.
  • Page 34 … Operation Choice of detergent Do not use washing-up liquid. It can cause excessive foaming, causing your appliance to malfunction. Follow the instructions printed on the detergent package carefully. Using too high detergent can cause damage to the appliance. Only use detergent specially formulated for dishwashers. The detergent manufacturer’s advice centre will gladly help with any prob- lems (e.g.

  • Page 35: Programme Selection

    … Operation Programme selection Close the appliance door. – The indicator lights for the buttons flash. If no programme selection is made within 15 seconds of closing the appliance door, the display goes out. However, it is still possible to select a programme.

  • Page 36: Selecting Additional Functions

    … Operation Selecting additional functions Additional functions can be selected within 15 seconds of selecting the main wash programme. Energy saver This additional function reduces energy consumption by approximately 10 %. It is also gentle to glasses. The energy saver function cannot be used togeth- er with the programmes.

  • Page 37: Delayed Start

    … Operation Delayed start The delayed start allows you to wash during off-peak hours (e.g. at off-peak electricity rates). The delayed start can be set between 1 and 24 hours. The delayed start time last entered is shown as a suggestion. Setting the delayed start Close the appliance door.

  • Page 38: Interrupting A Programme

    … Operation Interrupting a programme The dishes and the water may be hot – scalding hazard! Press the button. – This interrupts the programme. Open the appliance door. – The digital display flashes. – The indicator light for the programme selected flashes. When the appliance door is closed –...

  • Page 39: Aborting A Programme

    … Operation Aborting a programme The dishes and the water may be hot – scalding hazard! Hold the button depressed for 2 seconds. – The water is pumped off. – The digital display goes out after 30 seconds. – The indicator light for the button flashes.

  • Page 40: End Of Programme

    … Operation End of programme When the programme has finished, the corresponding indicator light remains illuminated. The indicator light for the button flashes. For a better drying result, the fan continues running – until the digital display goes out – during which time the appliance door should re- main closed.

  • Page 41: Operation With Childproof Lock Activated

    … Operation Operation with childproof lock activated When the childproof lock is activated, a programme can only be started by pressing two buttons simultaneously. After 'Accessing programme selection', the next steps (as described in the previous sections) can be carried out. Accessing programme selection Close the appliance door.
  • Page 42 … Operation Cancelling a delayed start Hold the button depressed and press the button repeatedly until the programme starts. Aborting a programme The dishes and the water may be hot – scalding hazard! Holding the button depressed, press the flashing button.

  • Page 43: Care And Maintenance

    Care and maintenance General cleaning Using the correct dosage of detergent will automatically clean the inside of the appliance. We recommend that the appliance be cleaned twice a year us- ing dishwasher cleaner, see the 'Accessories' section. Follow the directions for use for dishwasher cleaner carefully. Most dishwasher cleaners work more effectively at higher temperatures.

  • Page 44: Cleaning The Filters

    … Care and maintenance Cleaning the filters The filter system is comprised of a filter plate 1, a coarse filter with a foreign body trap 2 and a fine filter 3. A blocked filter prevents the wa- ter from draining away and triggers a corre- open close sponding fault message, which is described in...

  • Page 45: Cleaning The Spray Arms

    … Care and maintenance Cleaning the spray arms If the cleaning performance is unsatisfactory or if dishwasher detergent is be- ing left behind, then the nozzles in the spray arms may be clogged. Upper spray arm Remove the upper basket. Turn the nut 1 anti-clockwise and remove.

  • Page 46: Cleaning The Water Inlet Filter

    … Care and maintenance Cleaning the water inlet filter This should only be carried out by an expert. If carried out incor- rectly, there is a risk of flooding! The built-in water inlet filter can become blocked by limescale deposits, rust or foreign objects.

  • Page 47: Filling With Regeneration Salt

    … Care and maintenance Filling with regeneration salt Never fill the salt reservoir with detergent! – When the supply of regeneration salt is exhausted, the refill indicator flashes. Open the appliance door and pull out or re- move the lower basket. Open the salt reservoir by pulling on the grip.

  • Page 48: Filling With Rinse Aid

    … Care and maintenance Filling with rinse aid Never fill the rinse aid reservoir with detergent. Wipe away any spilt rinse aid (risk of foaming and check for «A2» faulty water outlet er- ror message). Always follow the manufacturer’s safety warnings. Rinse aid prevents water spotting after final rinsing (rinse aid).

  • Page 49: Trouble-Shooting

    Trouble-shooting What to do if … … (water outlet) appears in the digital display and the indicator light for the button flashes Possible cause Solution Coarse/fine filter is Fix the problem. clogged. Cancel the error message by pressing the button. Drain hose is bent or Restart the programme.
  • Page 50 … Trouble-shooting … appears in the digital display and the indicator light for the button flashes Possible cause Solution Water intake is hotter than A plumber should reduce the temperature 60 °C (warm water of water intake. connection). … appears in the digital display and the indicator light for the button flashes Possible cause Solution...
  • Page 51 … Trouble-shooting … the appliance does not start Close the appliance door. Insert the plug into the mains socket. Check the fuse or circuit breaker. See the 'Operation with childproof lock activated' section. … the dishes are not clean Select a more powerful programme. Load the baskets differently, avoiding blind spots.
  • Page 52 … Trouble-shooting … the dishes are wet and dull or water drops have dried on them Fill or top-up the rinse aid. Increase the rinse aid dosage. Do not open the appliance door too early. If not using 3in1 detergent, then in 'User settings' the setting for 3in1 detergent must be set to OFF.

  • Page 53: Interruption In Power Supply

    … Trouble-shooting … there is discolouring of the baskets and plastic parts inside the appliance Dishes were washed that still had discolouring food leftovers on them (e.g. tomato or curry sauce). The discolouration may fade after a few wash cycles. …...

  • Page 54: Dishwashing Tips

    Dishwashing tips Table and kitchenware Not all table and kitchenware are dishwasher safe. Handcrafted objects and wooden or plastic parts that are sensitive to heat or detergent suds should be cleaned by hand. Decorative glass objects are not dishwasher safe – the decoration will wear off over time.

  • Page 55: Technical Data

    Technical data Dimensions SMS 55 SMS 55 EURO 60 EURO 60 Extra height Extra height Height (with slide plate): 76 cm 82.5 cm 76 cm 82.5 cm Height (with plinth): 86.5–95 cm 80–88.5 cm 86.5–95 cm Width: 54.6 cm 54.6 cm 59.6 cm 59.6 cm Depth:...

  • Page 56: Accessories And Spare Parts

    … Technical data Accessories and spare parts Please give model number and exact description when ordering parts. Accessories Cup rack Spray head for baking trays Adjustable cutlery basket Rack Set of 4 easy prongs Spare parts Seal / Water inlet filter for Aqua-Stop Coarse filter Fine filter...

  • Page 57: Note For Testing Institutes

    … Technical data Note for testing institutes Capacity: 12 place settings Loading: See diagrams below Detergent dosage: 30 g reference detergent in the detergent dispenser Rinse aid dosage: «Level 10» Declaration programme: Normal/Standard Upper basket Lower the basket. Fold down the glass holder 2 and load the glasses and dishes.
  • Page 58 … Technical data Cutlery basket SLF = Soup spoon TLF = Tea spoon DLF = Dessert spoon = Knife = Fork = Serving spoon (2×) = Serving fork (1×) = Sauce spoon (1×) Arrange cutlery vertically and so that it is not touching. A, B and C must be placed diagonally in the cutlery basket.
  • Page 59 … Technical data Noise measurement The measurement is to be carried out in accordance with the European Norm EN 60704-2-3, section 6.1.3. Please note the installation instructions accompanying the appliance. The appliance is to be installed in accordance with the accompanying in- stallation instructions.

  • Page 60: Disposal

    Disposal Packaging All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety Disable the appliance to prevent accidents caused by improper use, espe-...

  • Page 61: Index

    Index Accessories........56 Display Additional functions ..... 12, 16 A2 Check water outlet ... 49 Delayed start ......37 A9 Check water inlet ....49 Energy saver......36 F.. Read instructions....50 Wash upper basket only ..36 F8 Read instructions ....50 Appliance Display elements ......
  • Page 62 … Index Maintenance ......... 43 Safety..........60 Model no......... 2 Safety concept......55 Safety precautions Children in the home ....7 Noise measurement ....59 Correct use ......... 6 Note for testing institutes ... 57 Note on use ........ 8 Using for the first time ....

  • Page 63: Repair Service

    Repair service The 'Trouble-shooting' section will help you to carry out small repairs yourself, saving you the time and trouble of calling out a service engi- neer and the cost that goes along with it. Whether you contact us about a malfunction or an order, please always state the serial number (FN) and the model type of your appliance.

  • Page 64: Quick Instructions

    Close the appliance door Select a programme Select any additional functions, if required The appliance starts in 15 seconds Wait about 30 minutes after the programme has ended to unload the appliance V-ZUG Ltd Industriestrasse 66, CH-6301 Zug vzug@vzug.ch, www.vzug.com J182.352-0...
