kozy heat CW50-501 Quick Start Manual

CW50-501 TRADITIONAL LOG SET
For use with model #CLW-50
NOTE: Log numbers are located on the bottom of each log.
Refer to the following directions for proper placement. Your
components may look different than the ones shown.
IMPORTANT: PROPANE INSTALLATIONS ONLY - When using 903-
LAVA with minimum venting you may have to remove up to 1
lb. of lava rock. When using 304-BLK or 304-COP with minimum
venting you may have to remove up 1/2 lb. of crushed glass.
1. Install the log placement bracket. The bracket is etched with a
"T" to show the topside of the bracket. Remove the two screws
from the burner as shown below. Install the bracket with the "T"
showing and using screws previously removed.
Figure 3, Rear Logs Installed
REMOVE AND SAVE (2) SCREWS FOR LOG PLACEMENT BRACKET
Figure 1, Log Placement Bracket
Figure 2, Log Bracket Installed
2. Place logs CW50-L1 and CW50-L2 as shown, with the notches
facing inwards.
3.

Remove and save the log placement bracket.

4. Place log CW50-L4 as shown below and aligned with the notch in
log CW50-L1.
5. Place log CW50-L6 as shown below and aligned with the notch in
log CW50-L7.
6. Place the rest of the logs as shown.
7. Use a stiff or steel bristle brush to distribute rockwool onto the
logs and burner.
HUSSONG MANUFACTURING CO., INC.
#CW50-501 R.1 4/18
