- Page 1 Version Translation of the original instruction manual Instruction manual Industrial PCs OPC7000 series Updated 2019-04-04...
-
Page 2: Table Of Contents
OPC7000 series Table of Contents Notes ................................3 General remark Limitation of liability Manufacturer Relevant device documentation Safety instructions ............................5 Structure of safety instructions Graduation of risk level Explanation of used symbols Symbols Data, figures and modifications Trademarks Copyright... - Page 3 Component replacement .......................... 49 12.1 Opening the service slot (OPC7008) 12.2 Opening the service slot (OPC7013-7022) 12.3 Replacing the lithium battery (OPC7000 series) 12.4 Replacing the HDD (hard disk) (OPC7013-7022) 12.5 Replacing the fan (OPC7013-7022) 12.6 Replacing the working memory (RAM) (OPC7013-7022) 12.7...
-
Page 4: Notes
OPC7000 series 1 Notes 1.1 General remark This instruction manual is intended to ensure safe and efficient handling of the device. It must be accessible to all persons who are involved in installation and commissioning of the device and must be read and understood before any work is started. -
Page 5: Relevant Device Documentation
OPC7000 series 1.4 Relevant device documentation The following documents are decisive to device setup and operation: Instruction manual (this documentation): Contains information for installation, commissioning and operation of the device along with technical data of the device hardware. Website You can download drivers, software, user manuals, leaflets and flyers about the product from our website www.ads-tec.de. -
Page 6: Safety Instructions
OPC7000 series 2 Safety instructions 2.1 Structure of safety instructions The signal word classifies the hazard. Reference to the type/consequences and source of the hazard is made underneath the signal word. Instructions for preventing the hazard are identified by an arrow (). - Page 7 OPC7000 series Tips and suggestions for the efficient use of the device and software optimisation are also provided. © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
-
Page 8: Symbols
OPC7000 series 2.4 Symbols Symbol Meaning Designation of batteries in accordance with § 13 of the German Battery Act (BattG). Batteries may not be disposed of with household waste, but must rather be disposed of separately. Used batteries must be returned to the point of sale or a disposal system. -
Page 9: Environmental Conditions
OPC7000 series 2.8 Environmental conditions The device can be put into operation and used under the following conditions. Failure to observe any one of these conditions will invalidate the warranty. ADS-TEC cannot be held liable for any damages arising from improper use and handling. -
Page 10: Standards
OPC7000 series 2.9 Standards The manufacturer hereby declares that this device has been marked with the CE mark in accordance with the basic requirements and other relevant conditions of the following European Directives: • 2011/65/EU, RoHs Directive • 2014/30/EU, EMC Directive •... -
Page 11: Device Features
OPC7000 series 2.11 Device features Proven many times over in rough environments, Panel PCs from ADS-TEC create clarity and precision in a new form. Optimised in every detail - with multi-touch operation and rear service access for simple and safe replacement of all components. In wide-screen format in four different sizes, reduced to the essential without compromise, powerful and with long-term availability. - Page 12 OPC7000 series Rear side Fig. 2: Description Service slot Tensioners for installation purposes © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
- Page 13 OPC7000 series Rear side Fig. 3: Description Tensioners for installation purposes Service slot © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
-
Page 14: Operating And Safety Instructions
OPC7000 series 3 Operating and safety instructions The device operates under electrical voltage and contains highly sensitive components. Intervention by the user is required only for connecting the power supply lines. Should any further modifications be required, it is necessary to consult either with the manufacturer directly or with service personnel authorised by the manufacturer. -
Page 15: Operating Location
OPC7000 series 3.1 Operating location The control system is designed for use inside a switching cabinet. Make certain that the specified environmental conditions are maintained at all times. Use in non-specified environments, i.e., on board ships, in explosive atmospheres or at extreme elevations, is prohibited. -
Page 16: Intended Use
OPC7000 series 3.4 Intended use The Panel PCs are designed for the control and monitoring of machines and equipment. The unit is intended for installation in electrical panels, consoles and cabinets. The device has to be assembled, installed and operated within the permissible specifications. Use in non-specified environments is prohibited. -
Page 17: Treatment And Disposal Of Lithium Batteries
OPC7000 series 3.6 Treatment and disposal of lithium batteries This device contains a lithium battery for supplying the system clock with power as long as the supply voltage is not connected. The battery has a life cycle of 3 - 5 years depending on which load is applied. -
Page 18: Safety Instructions
OPC7000 series 3.7 Safety instructions ATTENTION Damage due to electrostatically sensitive components Damage to the device can be caused by electrostatically sensitive components. All installation and service work performed on the device must be performed only under safe, secure and de-energised conditions. -
Page 19: Installation
OPC7000 series 4 Installation 4.1 Installation option This device is designed for integration. For installation and operation reasons (connector access), the installation location must be accessible from the rear. The wall thickness of the installation location must be between 2 and 13 mm. We recommend at least 3 mm for proper installation with IP65 on the front. -
Page 20: External Device Dimensions Opc7008
OPC7000 series 4.2 External device dimensions OPC7008 Abb. 4: © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 21: External Device Dimensions Opc7008
OPC7000 series 4.3 External device dimensions OPC7008 © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 22: External Device Dimensions Opc7013
OPC7000 series 4.4 External device dimensions OPC7013 Fig. 5: © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 23: Installation Layout Opc7013
OPC7000 series 4.5 Installation layout OPC7013 © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 24: External Device Dimensions Opc7015
OPC7000 series 4.6 External device dimensions OPC7015 Fig. 6: © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 25: Installation Layout Opc7015
OPC7000 series 4.7 Installation layout OPC7015 © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 26: External Device Dimensions Opc7022
OPC7000 series 4.8 External device dimensions OPC7022 Fig. 7: © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 27: Installation Layout Opc7022
OPC7000 series 4.9 Installation layout OPC7022 © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 28: Safety Notices Prior To Beginning Installation
OPC7000 series 4.10 Safety notices prior to beginning installation ATTENTION The grub screw of the Quick Snap element must not protrude when folding in, but must rather be flush with the tensioner! Non-compliance may result in damage to the device! -
Page 29: Order Of Installation (Opc7008)
OPC7000 series 4.11 Order of installation (OPC7008) ACHTUNG The screws have to be tighten with a torque of 0.25 NM 1) Before the device can be integrated in the panel, the tensioner fixing screws must be loosened until the tensioners open. - Page 30 OPC7000 series 2) Now, position the device inside the installation recess. ATTENTION In order to position the device correctly, the opened tensioners should be held back by hand while inserting the device in the installation recess. © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
- Page 31 OPC7000 series Fasten the tensioner screws with 0.25 NM until once the device is installed in the recess. (Item) © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
-
Page 32: Order Of Installation (Opc7013-7022)
OPC7000 series 4.12 Order of installation (OPC7013-7022) ACHTUNG The screws have to be tighten with a torque of 0.25 NM Information: The connection to the power supply network is established via the included power cable or lead-through terminal with screw connection. No earthing connection needs to be established as earthing takes place via the protective earth of the device plug / power supply connection. - Page 33 OPC7000 series The device must be carefully pushed into the cabinet. Then the tensioners snap forward again. The device is now secured in the installation recess. The tensioners must be fastened with 0,25 NM. © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
-
Page 34: Commissioning
OPC7000 series 5 Commissioning The interfaces for the device are located under protective covers. It has to be removed in order to connect the power supply lead and the interface cables. All supply leads and all required data leads have to be connected before commissioning. -
Page 35: Available Interfaces (Opc7008)
OPC7000 series 5.1 Available Interfaces (OPC7008) Abb. 8: Variante 1 Description On-/Off Switch Power Supply 24 V DC 1 x COM-Port 2 x LAN 3 x USB 2.0 © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 36: Available Interfaces (Opc7013-7022)
OPC7000 series 5.2 Available interfaces (OPC7013-7022) Abb. 9: Variante 1 Description On-/Off Switch Power Supply 24 V DC 1 x COM-Port 5 x USB 2.0 3 x LAN Abb. 10: Variante 2 Description On-/Off Switch Power Supply 24 V DC 1 x COM-Port 2 x USB 3.0... -
Page 37: Cable Installation
OPC7000 series Pos : 18 /D atentec hni k/Inbetri ebnahme/R eihenfolg e der Inbetriebnahme/R ei henfolge der Inbetriebnahme für VMT 60xx- Seri e @ 1\mod_1222073159179_6.doc @ 4100 @ 5.3 Cable installation The interfaces and the device power supply plug are located at the bottom of the device. -
Page 38: Operation
OPC7000 series 6 Operation 6.1 Front panel operation keys (basic function) Fig. 11: The keys can be assigned or deactivated according to customer needs. The keys on the front are assigned the following functions ex works by a special driver in the soft keyboard:... -
Page 39: Soft Keyboard
OPC7000 series firmware update of the front keys. Information: The BIOS Navigation via the frontkeys is enabled by Default.Via the Path: Advanced EC firmware configuration, the front keys can be disabled. Inside Bios Setup, the key reacts like the Enter-Key on a real keyboard. - Page 40 OPC7000 series Fig. 12: Operating the soft keyboard for version 3.11 and higher: Activate and deactivate the soft keyboard for letter/character input using the touch screen Switches numeric keys on and off (only if numeric keys are visible) Switching between different representations (Alphanumeric keys ...
-
Page 41: Touch Screen
OPC7000 series When deactivating the soft keyboard, the previously active state (alphanumeric / numeric keys or function keys) will be stored and will be displayed when re-activating the keyboard. This setting can be configured. Pos : 22 /D atentec hni k/Bedienung/T ouch Scr een/T ouch Scr een für VMT 60xx @ 1\mod_1246361069977_6.doc @ 5853 @ 6.3 Touch screen... -
Page 42: Interfaces
OPC7000 series 7 Interfaces Pos : 26 /D atentec hni k/Schnitts tell en/Spannungs versorgung/Spannungs versorg ung für VMT60xx- Seri e @ 2\mod_1260450284020_6.doc @ 6853 @ 7.1 Voltage supply 24V DC The supply voltage is fed to the device via a lead-through terminal with screw connection. (The figure shows the socket inside the device). -
Page 43: Network Connection (Rj45)
OPC7000 series 7.3 Network connection (RJ45) If the drivers required for functioning are installed on the device, the control system may be integrated in an Ethernet network supporting the 10/100/1000Mbit standard by using the Ethernet 10/100/1000BaseT network connector. The specifications of this network topology must be observed. If the drivers required for function are not installed, they can be installed from the website (www.ads-tec.de). -
Page 44: Serial Interface Com (Rs232)
OPC7000 series 7.4 Serial interface COM (RS232) The serial interface is used for digital data transmission. The RS232 interface can be connected by using a commercially available 9-pin SUB-D cable. PIN number Signal name Information: This interface is not electrically isolated. -
Page 45: Drives
OPC7000 series 8 Drives 8.1 Hard disk / Flash SSD The storage medium is selected according to the customer requirements. The following options are available for storage: 2,5” HDD SATA 2,5” SSD SATA mSATA-Form factor SSD The size depends from operating system and the additional programmes to be installed. -
Page 46: Software
OPC7000 series 9 Software The device will be delivered with a pre-installed operating system depending on what the customer wants. The drivers required for this, are already installed and the operating system will be enabled by entering the licence information. Should an initial installation be required, please follow the following steps. -
Page 47: Technical Details
OPC7000 series 10 Technical details OPC7008 OPC7013 OPC7015 OPC7022 Housing Die-cast aluminum, powder-coated Front panel 3mm glass, thermally hardened and anti-reflective treatment Display 8" TFT 13.3" TFT 15.4" TFT 21.5" TFT Resolution 800 x 480 pixels 1280 x 800 Pixel... - Page 48 OPC7000 series Professional / Ultimate, Windows® XP Professional Protection class Front-side IP65 Optional casing IP65 Operating temperature 0 °C bis +55 °C 5°C to +45°C , 5°C to +45°C –20°C to +60°C* –20°C to +55°C* Dimensions (W x H x D)
-
Page 49: Service & Support
OPC7000 series 11 Service & support ADS-TEC and its partner companies offer you comprehensive maintenance and support services, ensuring quick and competent support should you have any questions or concerns with regard to ADS- TEC products and equipment. Because ADS-TEC products are also used by partner companies, these devices may have customised configurations. -
Page 50: Component Replacement
OPC7000 series 12 Component replacement ATTENTION Make certain that all cables are disconnected and that no voltage is connected to the device! 12.1 Opening the service slot (OPC7008) Remove the four screws for the service slot on the rear of the device. - Page 51 OPC7000 series Fig. 14: By removing the service slot cover, it is possible to replace the following components. Lithium battery mSATA connection © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
-
Page 52: Opening The Service Slot (Opc7013-7022)
OPC7000 series 12.2 Opening the service slot (OPC7013-7022) Remove the four screws for the service slot on the rear of the device. The screws can be removed with a size Tx 10 screwdriver. The rear cover can be tilted forward and removed using the groove on the top side of the service slot. - Page 53 OPC7000 series Fig. 16: By removing the service slot cover, it is possible to replace the following components. Lithium battery mSATA connection © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
-
Page 54: Replacing The Lithium Battery (Opc7000 Series)
OPC7000 series 12.3 Replacing the lithium battery (OPC7000 series) Loosening / removing the retaining bracket This battery is secured by a plugged-in retaining bracket. The retaining bracket can be removed from the battery holder by carefully lifting the external tabs with a flat tool (screwdriver). -
Page 55: Replacing The Hdd (Hard Disk) (Opc7013-7022)
OPC7000 series 12.4 Replacing the HDD (hard disk) (OPC7013-7022) Removal The extraction aid provided on the HDD should be used for removing the HDD. Carefully pull out the HDD. Installation The HDD must be carefully inserted into the slot and should noticeably engage. -
Page 56: Replacing The Fan (Opc7013-7022)
OPC7000 series 12.5 Replacing the fan (OPC7013-7022) ATTENTION Before the device fan can be replaced, the fan cable must be unplugged! Removal Use a size Tx 10 screwdriver to remove the fan screws. The fan can then be lifted out and replaced with a new one. -
Page 57: Replacing The Working Memory (Ram) (Opc7013-7022)
OPC7000 series 12.6 Replacing the working memory (RAM) (OPC7013-7022) Removal The RAM memory is released by carefully pulling apart the retaining clips (1+2). It can now be replaced with new RAM memory. Installation Insert the new RAM memory in the designated slot and push the RAM memory to the back until the retaining clips engage. -
Page 58: Replacing The Msata Modules (Opc7000 Series)
OPC7000 series 12.7 Replacing the mSATA modules (OPC7000 series) Information: For the devices OPC7013-7022, the HDD (hard disk) must be removed before the SSD Flash Modules can be installed or replaced. Remove the HDD (OPC7013-7022) Remove the screw(s) of the spacer bolt by using a Tx10 screw driver. - Page 59 OPC7000 series Mounting (OPC7000 Serie) 1 Mainboard 2 plastic disc 3 plastic distance holder 4 mSATA Card 5 plastic disc © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
