Clas Ohlson EMT1700P Manual

Twilight Switch
with Countdown Timer
Art.no 36-5740 Model EMT1700P
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for any
errors in text or images and any necessary changes made to
technical data. In the event of technical problems or other queries,
please contact our Customer Services.

Safety

• This twilight switch should only be repaired by a qualified
service technician.
• The twilight switch should not be taken apart or modified.
• Do not let children play with the twilight switch.
• Make sure that the wall socket that the twilight switch
is plugged into is easily accessible as the only way to
completely disconnect the twilight switch from the mains is
by unplugging it.
• The twilight switch is only intended for indoor use.
• Do not place the twilight switch in damp or dusty environments
or where it could be subject to strong vibrations.
• The power button on the front of the twilight switch
does not disconnect the device plugged into it (such as
a light or lamp) from the mains. To completely disconnect
the plugged in device from the mains, the twilight switch
must be removed from the wall socket.
GREAT BRITAIN • customer service tel: 0845 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk

Buttons and functions

1
2
4H
1H 6H
3
2H 8H
4
R
1. LED indicator – shines a steady blue when the outlet of
the twilight switch is switched to continuous operation
mode. Flashes when any of the buttons is pressed when
the outlet of the twilight switch switched off.
2. Activates the twilight switch and switches the plugged in
device on at dusk and off at dawn regardless of any timer
setting.
3. [ 1H ], [ 2H, [4H ], [ 6H ], [ 8H ] Activates the twilight switch and
the countdown timer. The connected light will be switched
on at dusk and off after the selected interval 1, 2, 4, 6 or
8 hours. The timer can be changed at any time from e.g.
a 2-hour to a 4-hour countdown.
4. [ ] Switches the plugged in device (light) on regardless of
the light conditions and countdown timer setting.
5. Light sensor.
6. [ R ] Reset. Press carefully with a suitable object to reset
the twilight switch to its factory default settings.

Placement

• Bear in mind that the twilight switch should be positioned
where it is exposed to sunlight and is not obscured in any way.
• The twilight switch should also be positioned where it is
5
not activated by other artificial light sources or the headlights
of traffic.

Operating instructions

6
1. Switch off the light which is to be connected to the twilight
switch.
2. Plug it into the outlet of the twilight switch.
3. Plug the twilight switch into a wall socket.
4. Programme the twilight switch as directed in the Buttons
and functions section above.
5. Switch on the connected light (device).

Care and maintenance

• Always unplug the twilight switch from the wall socket before
cleaning. Wipe the housing with damp cloth and a mild
cleaning agent. Never use solvents or corrosive chemicals.
• Always unplug the twilight switch from the wall socket when
it is not in use.

Disposal

The twilight switch should be disposed of in accordance with
local regulations. If you are unsure how to proceed, contact
your local council.

Specifications

Rated voltage 230 V, 50 Hz
Max load 1800 W
