1. Manuals
  2. Brands
  3. Univex Manuals
  4. Commercial Food Equipment
  5. VS9
  6. Operator's manual

Univex VS9 Operator's Manual

Vegetable slicing & shredding units
Hide thumbs Also See for VS9:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454
V
e
g
e
V
e
g
e
Persons under the age of 18 are not permitted to operate or have
accessibility to operate this equipment per U.S. Dept. of Labor Employment
UNIVEX CORPORATION - 3 Old Rockingham Road - Salem, NH 03079-2140 – Tel (800) 258-6358 – Fax (800) 356-5614
Int'l Tel 603-893-6191 – Int'l Fax 603-893-1249 – Website
2940 Hwy 14 W, Rochester, MN 55901
E
x
a
c
t
i
n
g
S
t
a
n
d
E
x
a
c
t
i
n
g
S
t
a
n
t
a
b
l
e
S
l
i
c
i
n
g
&
t
a
b
l
e
S
l
i
c
i
n
g
&
Operators Manual
Standards Administration Fact Sheet No. ESA91-3.
a
r
d
s
,
J
u
s
t
L
i
k
e
Y
o
u
r
s
,
s
i
n
d
a
r
d
s
,
J
u
s
t
L
i
k
e
Y
o
u
r
s
,
s
i
S
h
r
e
d
d
i
n
g
U
n
i
t
S
h
r
e
d
d
i
n
g
U
n
i
t
V
S
9
&
V
S
V
S
9
&
V
S
www.univexcorp.com
c
e
1
9
4
8
n
c
e
1
9
4
8
V
V
s
s
9
H
9
H
- E-mail
Univex@univexcorp.com
S
9
&
V
S
9
H
S
9
&
V
S
9
H
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS9 and is the answer not in the manual?

Questions and answers

Related Manuals for Univex VS9

Summary of Contents for Univex VS9

  • Page 1 U.S. Dept. of Labor Employment Standards Administration Fact Sheet No. ESA91-3. UNIVEX CORPORATION - 3 Old Rockingham Road - Salem, NH 03079-2140 – Tel (800) 258-6358 – Fax (800) 356-5614 Int’l Tel 603-893-6191 – Int’l Fax 603-893-1249 – Website www.univexcorp.com...

  • Page 2: Table Of Contents

    GRATER, SHREDDER AND JULIENNE PLATE UNIT ..... .5 LOADING PLATE UNITS INTO THE VS9 HOUSING ..... .6 MOUNTING INSTRUCTIONS .

  • Page 3: Introduction

    Never insert any utensil into the hopper. Note that the front housing of the VS9/VS9H has a feed hopper (Figure 6 [1]). It is also equipped with a feed plate (Figure 6 [19]). Food to be processed must always be fed to the cutters by way of the hopper, and pressed against the cutting surfaces with the feed plate.

  • Page 4: Inspection And Model Variation Explanation

    UNIVEX. INSTALLATION The VS9/VS9H is an attachment with no internal power source. To function, it must be mounted to a power take-off on a mixer or a power base unit. Make sure that a comfortable working clearance is provided around the machinery and that the machinery is installed where it will save the operator steps.

  • Page 5: Plate Units - Assembly - Use

    To vary slice thickness CAUTION: The thrust bearing must be securely tightened before the slicer plate assembly is loaded into the housing. Failure to tighten the thrust bearing will damage the VS9 and the power source equipment. NOTE: The thrust bearing requires a left hand twist to tighten.

  • Page 6: Grater, Shredder And Julienne Plate Unit

    Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 2940 Hwy 14 W, Rochester, MN 55901 THE GRATER, SHREDDER AND JULIENNE PLATE UNIT (Figure 8) To fit the plate of your choice to the hub and shaft (Figure 8), line up the key hole slots on the plate with the locating pins on the hub, slip the plate over the pins and secure it by turning the plate in a clockwise direction until it shoulders up firmly on the pins.

  • Page 7: Loading Plate Units Into The Vs9 Housing

    LOADING PLATE UNITS INTO THE VS9 HOUSING With the VS9/VS9H resting on a stable working surface, unlatch the front housing (Figure 6 [1]) and swing it toward you. Lift the assembled plate unit and insert it into the rear housing (Figure 6 [5]). Lift the shaft lock pin (Figure 6 [15]) and seat the plate unit with a gentle twist.

  • Page 8: Mounting Instructions

    PTO adapter. Slide the VS9/VS9H forward until the square milled shaft end seats in the PTO adapter. Turn the VS9/VS9H to align the locating pin with the alignment pin locating hole in the PTO hub and push the VS9/VS9H fully forward onto the PTO hub. Tighten the thumb screw to secure the VS9/VS9H to the PTO hub.

  • Page 9: Processing Product

    DISMOUNTING: Make sure that the power source equipment is turned off and its electrical supply is disconnected or locked out. Loosen the thumb screw and slide the VS9/VS9H from the PTO hub. Set the VS9/VS9H on a stable working surface.

  • Page 10: Cleaning

    Do not remove thrust bearings from julienne or shredder plate shafts. Dry component parts with a soft cloth. For the best and most sanitary product, clean the VS9 immediately after use or before switching food products.

  • Page 11: Mechanics Maintenance

    2940 Hwy 14 W, Rochester, MN 55901 MECHANICS MAINTENANCE Before preforming maintenance on the VS9/VS9H, please review the safety precautions on page 2 and read all assembly and reassembly instructions. Wear gloves when handling plate units. Since the VS9/VS9H contains no internal power source, most problems can be immediately traced to im- proper assembly, improper adjustment or worn parts.

  • Page 12: Warranty

    Please call the UNIVEX Warranty Service Department at 800-258-6358 to report warranty claims before arranging for repair of the unit. The unit must be delivered to a UNIVEX authorized service agent or to the UNIVEX Facility for warranty repairs. The end user is responsible for all shipping or travel charges arising from the repair or servicing of this unit under warranty.

This manual is also suitable for:

Vs9h

Table of Contents
