Suntracer KNX-GPS light
Weather Station
Technical specifications and installation instructions
EN
Elsner Elektronik GmbH Control and Automation Engineering
Herdweg 7
D – 75391 Gechingen Phone +49 (0) 70 56 / 93 97-0
Germany
Fax
+49 (0) 70 56 / 93 97-20 www.elsner-elektronik.de
info@elsner-elektronik.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Suntracer KNX-GPS light and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elsner Suntracer KNX-GPS light

Summary of Contents for Elsner Suntracer KNX-GPS light

  • Page 1 Suntracer KNX-GPS light Weather Station Technical specifications and installation instructions Elsner Elektronik GmbH Control and Automation Engineering Herdweg 7 D – 75391 Gechingen Phone +49 (0) 70 56 / 93 97-0 info@elsner-elektronik.de Germany +49 (0) 70 56 / 93 97-20 www.elsner-elektronik.de...
  • Page 2 Configuration is made using the KNX software ETS. The programme file (format VD), the data sheet and the manual can be downloaded from the Elsner Elektronik homepage on www.elsner-elektronik.de in the “Service” menu. Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.

  • Page 3: Technical Specifications

    63 lux at 1 047…52 363 lux 423 lux at 52 364…150 000 lux Accuracy (brightness) ±35% The product conforms with the provisions of EC guidelines • EMC Directive 2004/108/EC Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.

  • Page 4: Installation And Commissioning

    Elsner Elektronik is not liable for any changes in norms and standards which may occur after publication of these operating instructions.
  • Page 5 The weather station comes with a combination wall/pole mount. The mount comes ad- hered by adhesive strips to the rear side of the housing. Fasten the holder vertically to the wall or pole. Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.
  • Page 6 With the hinge arm mounting, the weather sta- tion projects from beneath the roof overhang. Sun, wind and precipitation can act upon the sensors without hindrance. Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.

  • Page 7: Rear View And Drill Sketch

    Dimensions of the rear side of the housing with holder, dimensions in mm. Diver- gences are possible for technical reasons. Oblong hole 7,5 x 5 mm Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.

  • Page 8: Preparing The Weather Station

    +/- to the provided clamps. Fig. 10 Remove the cable shielding under the circuit board and only feed the connector cables up- wards through the openings in the circuit board. Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.

  • Page 9: Pcb Layout

    Close the housing by putting the cover back over the bottom part. The cover must snap in on the left and right with a definite “click”. Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.

  • Page 10: Notes On Mounting And Commissioning

    After the auxiliary voltage has been applied, the device will enter an initialisation phase lasting a few seconds. During this phase no information can be received via the bus. Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.

  • Page 11: Addressing Of The Device At The Bus

    ATTENTION The device can be damaged if significant volumes of water penetrate the housing. • Do not clean with high pressure cleaners or steam jets. Weather Station Suntracer KNX-GPS light • Version: 15.07.2013 • Technical changes reserved. Errors reserved.
