Technical Data Manual
• Monobloc • EDLQ011-016AA6V3
TABLE OF CONTENTS
EDLQ011-016AA6V3
1
2
3
4
5
6
7
8
9
10
11
• Altherma • Monobloc
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wiring diagram
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daikin EDLQ011-016AA6V3
Summary of Contents for Daikin EDLQ011-016AA6V3
-
Page 1: Table Of Contents
• Monobloc • EDLQ011-016AA6V3 TABLE OF CONTENTS EDLQ011-016AA6V3 Features ............. 2 Specifications . -
Page 2: Features
• Monobloc • EDLQ011-016AA6V3 Features 1 6 A 1 - 0 h e r o b l Q 0 1 M o n A l t E D L • Heating only monobloc with bottom plate heater • Low energy bills and low CO2 emissions •... -
Page 3: Specifications
• Monobloc • EDLQ011-016AA6V3 Specifications 2-1 NOMINAL CAPACITY AND NOMINAL INPUT EDLQ011AA6V3 EDLQ014AA6V3 EDLQ016AA6V3 Condition 1 Heating Nominal 11.20 14.00 16.00 capacity Heating PI Nominal 2.47 3.20 3.79 Nominal 4.54 4.37 4.22 Condition 2 Heating Nominal 10.87 13.10 15.06 capacity... -
Page 4: Main Components
• Monobloc • EDLQ011-016AA6V3 Specifications 2-2 TECHNICAL SPECIFICATIONS EDLQ011AA6V3 EDLQ014AA6V3 EDLQ016AA6V3 Notes The sound pressure level is measured via a microphone at a certain distance from the unit. It is a relative value depending on the distance and acoustic environment. Refer to sound spectrum drawing for more information. -
Page 5: Electrical Specifications
• Monobloc • EDLQ011-016AA6V3 Specifications 2-3 MAIN COMPONENTS EDLQ011AA6V3 EDLQ014AA6V3 EDLQ016AA6V3 Water circuit Piping connections inch G5/4 (FEMALE) Piping inch 5/4" Safety valve Manometer Drain valve / Fill valve Shut off valve Air purge valve Total water volume (6) 2-4 ELECTRICAL SPECIFICATIONS... - Page 6 • Monobloc • EDLQ011-016AA6V3 Specifications 2-4 ELECTRICAL SPECIFICATIONS EDLQ011AA6V3 EDLQ014AA6V3 EDLQ016AA6V3 Power supply Voltage range Minimum -10% hydraulic Maximum V +10% component Wiring Connection type for power supply hydraulic compartment connections Quantity of wires Type of wires Select diameter and type according to national and local regulations...
-
Page 7: Options
• Monobloc • EDLQ011-016AA6V3 Options EDLQ011-016AAV3 Kit availability for E(D/B)(H/L)Q011-016AA* Altherma Monoblock / Low temperature 1-Phase 3-Phase Zone 2 Zone 3 Zone 2 Zone 3 EDLQ***AA6V3 EDHQ***AA6V3 EDLQ***AA6W1 EDHQ***AA6W1 EBLQ***AA6V3 EBHQ***AA6V3 EBLQ***AA6W1 EBHQ***AA6W1 Reference Description EKRP1HB Digital I/O PCB EKBPHT16Y... -
Page 8: 3 Options
55°C and it required, install an aquastat(*) valve in the 6 Collector (field supply) return water flow of the EKHB* unit. 7 Shut-off valve Daikin shall not be held liable fo any damage resulting from failure to observe 8 Motorised 3-way valve (field supply) this rule. 10 Booster heater... -
Page 9: Capacity Tables
• Monobloc • EDLQ011-016AA6V3 Capacity tables 4 - 1 Heating capacity tables EDLQ011-016AA6V3 Maximum Heating Capacity (Peak values) Model LWC [°C] Tamb HC [kW] PI [kW] HC [kW] PI [kW] HC [kW] PI [kW] HC [kW] PI [kW] HC [kW]... -
Page 10: Dimensional Drawing & Centre Of Gravity
• Monobloc • EDLQ011-016AA6V3 Dimensional drawing & centre of gravity 5 - 1 Dimensional drawing EDLQ011-016AA6V3 Center of gravity 1. Drain outlet 2. Waterpiping outlet 3. Waterpiping inlet 4. Power supply cables intake 5. Field wiring intake 6. Service door switchbox 7. -
Page 11: Piping Diagram
• Monobloc • EDLQ011-016AA6V3 Piping diagram EDLQ011-016AA6V3 Expansion vessel Heat exchanger Filter Filter Pressure gauge Evaporator Safety valve Condenser Distributor Air purge Pump Outlet Shut off valve Service port Electric heater body 5/16″ Capillary tube Flowswitch Filter Inlet Shut off valve... -
Page 12: Wiring Diagram
• Monobloc • EDLQ011-016AA6V3 Wiring diagram 7 - 1 Wiring diagram EDLQ011-016AA6V3 Printed circuit board (Main) Power supply Printed circuit board (INV) Compressor module switchbox Printed circuit board (Noise filter) BS1∼BS4 Push button switch C1∼C4 Capacitor DIP switch To hydromodule switchbox (8.5 Page 2... - Page 13 • Monobloc • EDLQ011-016AA6V3 Wiring diagram 7 - 1 Wiring diagram EDLQ011-016AA6V3 Printed circuit board (Main) Power supply Printed circuit board (INV) Compressor module switchbox Printed circuit board (Noise filter) N-50Hz Printed circuit board 230V BS1∼BS4 Push button switch C1∼C4...
- Page 14 • Monobloc • EDLQ011-016AA6V3 Wiring diagram 7 - 1 Wiring diagram EDLQ011-016AA6V3 Outdoor unit Only for EC/BLQOption Only for EKSOLHWAV1Option Domestic hot water tank Power supply Solar pump connection A11P : Main PCB 230V 1N∼50Hz Only for *KHWE*Option A12P : User interface PCB...
-
Page 15: Sound Data
• Monobloc • EDLQ011-016AA6V3 Sound data 8 - 1 Sound pressure spectrum EDLQ011-016AA6V3 EDLQ011-016AA6V3 E(D/B)(H/L)Q011* E(D/B)(H/L)Q014* E(D/B)(H/L)Q016* E(D/B)(H/L)Q011* E(D/B)(H/L)Q014* E(D/B)(H/L)Q016* HEATING HEATING HEATING HEATING HEATING HEATING Octave band center frequency (Hz) Octave band center frequency (Hz) Octave band center frequency (Hz) -
Page 16: Installation
• Monobloc • EDLQ011-016AA6V3 Installation 9 - 1 Service space EDLQ011-016AA6V3 A. Non stacked installation Legend Unit: mm Suction side obstacle Discharge side obstacle Left side obstacle Right side obstacle Top side obstacle Obstacle is present In these cases, close the bottom of... -
Page 17: Operation Range
• Monobloc • EDLQ011-016AA6V3 Operation range EDLQ011-016AA6V3 only EB(H/L)* Leaving evaporator Water temperature (°C) No heat pump operation, back up heater only E(D/B)L* units include special equipment (insulation, heater sheet, . . . ) to ensure good operation in areas where low ambient temperature can occur together with high humidity conditions. -
Page 18: Hydraulic Performance
• Monobloc • EDLQ011-016AA6V3 Hydraulic performance 11 - 1 Static pressure drop unit EDLQ011-016AA6V3 Flow (l/min) I High speed II medium speed ESP: External static pressure Flow: waterflow through the unit WARNING 1. Selecting a flow outside the curves can cause damage to or malfunction of the unit. See also minimum and maximum allowed water flowrange in the technical specifications.
