5. Collegamenti
Morsetto di collegamento
Morsetti di
collegamento
DC+
DC-
B
A
Tutte le connessioni dipendono dalla polarità.
CAT dentro
CAT fuori
Alimentazione (polo +)
Alimentazione (massa)
Cavo dati D+ (RS-485)
Cavo dati D- (RS-485)
82 / 124 | IT
Collegare la
schermatura
(attorcigliare)
