6. Installation
6. Installation
1.
Unpack the LockNode.
2. Check if the LockNode is damaged.
3. Place the LockNode at a maximum distance of 30 cm
from locking cylinders or SmartHandles or approx. 40
cm from SmartRelays.
NOTE
Connection with SREL.ADV
You can also connect the LockNode with
WN.KAB.WIRED-BF directly to the SREL.ADV (no
minimum distance required)
4. If necessary, connect the WN.LN.SENSOR.CABLE.
5. If necessary, connect the WN.LN.SENSOR.CABLE to the
devices to be connected.
6. Connect the power supply or insert the batteries.
LockNode is installed.
9
7. Signalling
LED
flashes red twice
Meaning
Initialization is complete.
31 / 124 | EN
