5. Connections

Connection terminal

Connection

terminals

DC+

DC-

All connections are polarity dependent.

CAT in

CAT out

Power supply (positive pole)

Power supply (ground)

Data line D+ (RS-485)

Data line D- (RS-485)

30 / 124 | EN

Shield

connect

(twist)
