Attach the ISOFIX arms (F) to the vehicle ISOFIX connection points in the correct vehicle seat
5
position, according to (1). You will hear a "click" when the ISOFIX arms lock into position.
6 Make sure that the ISOFIX installation indicator (G) shows green.
Extend the front brace (A) towards the vehicle seat by pulling the front base release knob (B)
and pushing the front brace (A) towards the vehicle seat. Make sure to apply as much pressure
7
as possible and that the front brace release knob (B) clicks into position.
Extend the support leg (M) by pulling the support leg knob (K) to extend the support leg so the
support leg foot (N) is in contact with the vehicle floor. Check that the noise from the support
8
leg installation buzzer (O) stops, then the installations is done correctly. Make sure that the
floor of the vehicle is suited for supporting an i-Size car seat. Check the vehicle manual for
information.
IMPORTANT:
Make sure that all installation indicators shows green.
Installing the Axkid Modukid Infant
on the base
When installing an Axkid Modukid Infant to the base, pull the seat release handle (E) to its
9
extended position (see F6) and push the infant carrier to the base. The infant carrier shall click
into the base.
Ensure that the Axkid Modukid Infant is not in contact with any adjacent vehicle seat and that
10
the support leg is firmly clamped to the floor and that the support leg installation buzzer (O) has
stopped buzzing.
Axkid has equipped the Axkid Modukid Infant with a side impact protection system, ASIP
11 (Axkid Side Impact Protection). Push the release button and pull the ASIP towards the door of
the car until it locks into the outermost position that fits your car.
IMPORTANT:
See your Axkid Modukid Infant manual for full instructions on how to install the product and how to
buckle your child in the seat.
