- Page 1 Instruction manual Babyfix Baby seat Approved according to Group 0+ for babies weighing up to 13kg Tested and approved according to ECE R44 / 04...
-
Page 2: Important Information
Important information Thank you for choosing a baby seat from Axon Kids. The team developing Babyfix have more than 30 years of experience in child safety products between us, and we have done our outmost to make this baby seat as safe as possible. The Axon Kids baby seat has of course also been tested and certified according to ECE R44/ 04, the latest European standard for child safety. - Page 3 The baby seat’s parts Handle Release buttons for the handle Belt guiding hook Cradle skids Belt release button Belt adjust release button Belt adjustment strap Sun protective cloth Handle status indicator 10. Push-chair fixing...
-
Page 4: Adjusting The Handle
Adjusting the handle In order to adjust the handle; push both the release buttons located close to the handle’s rotation point. At the same time, push the handle in the direction of the arrow (Pic 1). The handle has five different positions to choose from. Picture 1. - Page 5 Buckle your child in the seat Put the baby seat on a plane surface and then adjust the handle so that it is according to picture 1 on the previous page. Hold down the button for belt adjustment (Pic 6, B) and at the same time pull the shoulder belt (Pic 6, A) until it is fully pulled out.
- Page 6 Adjusting the belt height The height of where the shoulder belt comes out from the baby seat’s back should be just below the child’s shoul- ders. Adjusting is done by moving the belt up or down to the next slit, picture 9, in the baby seat’s back depending on if you are going to increase the height or decreas- ing it.
-
Page 7: Installation In The Car
Installation in the car Start by adjusting the handle of the seat so that it is fixed to a vertical position. Guide the car’s lap belt through the hooks on the baby seat’s front side. Then buckle the belt (Pic 11) Pull the car’s shoulder belt around the seat and fix it in the hooks on the rear side of the seat (facing for-... - Page 8 Warranty and handling If the baby seat cover is replaced; make sure only to use original products from Axon Kids. If not the safety system could be compromised and may lead to death or injury of your child in case of an accident. The baby seat cover can be taken off and washed in the laundry.
