Bunn ICB SH Service Manual
Faucet side car relocation instructions
Hide thumbs
Also See for ICB SH:
- Installation & operating manual (17 pages) ,
- Programming manual (36 pages)
Advertisement
Quick Links
ICB SH
ICB SH TWIN
Faucet Side Car Relocation
Instructions
TO BE PERFORMED BY QUALIFIED PERSONNEL
These instructions are intended for relocating the facuet side car on an ICB SH brewer. Ensure all tools are present before
performing the installation.
WARNING: Disconnect the brewer from the power source before performing the procedure. Ensure the
water is drained from the tank and be aware that many internal parts can be extremely hot; allow contents of
tank to cool before proceeding.
Note: If technical assistance is needed, please call 1-800-286-6345
Tools Required:
8/32 socket/wrench
Flat Blade Screwdriver
BUNN-O-MATIC CORPORATION
POST OFFICE BOX 3227
SPRINGFIELD, ILLINOIS 62708-3227
PHONE: (217) 529-6601
FAX: (217) 529-6644
www.bunn.com
55227.0000A 07/18 ©2018 Bunn-O-Matic Corporation
