Seada SolarWall SW-MV-H Quick Start Manual

SolarWall HD Multiviewers Quick Start Guide

1. Verify the package contents

Please verify the package contents against the List Below
1. Multiviewer Unit
2. Power Cable
3. Ethernet Cable
If any of the items in the packing list is missing, please contact your reseller.

2. Set up the SW Multiviewer

Power up the unit and connect the inputs and outputs to correct devices.
1. Power Socket
2. Power Switcher
3. IP Connection Port
4. RS-232 Connection Port (
5. HDMI Output Port
6. SDI Output Port
7. HDMI Input Ports
8. SDI Input Ports

3. Install the software on control PC

Install the SW-MH management software from the disk. Open the software to obtain the user interface as below
with username: Admin and leave password empty.
A
SD-EN-007
1
1
1
Model: SW-MV-H
7
8
6
Serial Port to Ethernet Adapter Cable
Figure 1
Figure 2
4. Quick Start Guide (SD-EN-007)
5. Serial to Ethernet Cable
6. Software & Documentation User CD
5 4 3
)
1
1
1
2 1
V01
