Seada G4K Quick Start Manual

G4K QUICK START MANUAL
Setup Steps

1. Verify the package contents

2. Set up the G4K

3. Install the software on control PC

4. Connect to Control PC through IP
1. Verify the package contents
Please verify the package contents against the List Below
1 G4K Controller
2 Power Lead
3 Power Adapter
4 Ethernet Cable
5 Quick Start Guide (SD-MA-012)
6 G4K Software & Documentation User CD
If any of the items in packing list is missing, please contact your reseller.
2. Set up the G4K
Power up the G4K controller and connect the input and outputs to correct devices.
3. Install the software on control PC
Install the G4K management software from the disk onto a Windows based control PC. Users will have
the software UI as below.
A
SD-MA-012
1
1
1
1
1
1
Figure 1
V03
